Operating conditions are as follows: Vin=5V, Vo=3.3V, Load
change from Io=0% to Io=100%, TA=25°C, Cin=0F, Co=µF
.
Temp Rise C
Transient Response
50
40
30
20
10
0
1
2
3
4
5
0.5
1.5
2.5
3.5
4.5
OUTPUT CURRENT - AMPS
Efficiency
100
EFFICIENCY %
95
90
5.5
Operating conditions are as follows: Vin=5V, Vo=3.3V, Load
change from Io=100% to Io=0%, TA=25°C, Cin=0F, Co=µF.
3.3V 25C
85
2.1V 25C
80
75
0.5
1.5
2.5
3.5
4.5
5.5
OUTPUT CURRENT AMPS
V
o
=3.3V, C
out
-Oµf, V
i
=5V, C
in
=100µf
SUPERSIP26 11/99 REV C
6
Page 3
Ordering Information
Typical examples:
SS
26
-
A
-
A
-
A
Standard configuration 5V to 3.3V
with 1.8V-3.6V trim range
SS
26
-
B
-
A
-
A
Power Good
A
= Pin 7A installed for Power
Good option
B
= Pin omitted (industry standard)
Enable
A
= logic1 or open = ON
logic 0 or gnd = OFF
B
= logic 0 or gnd = ON
logic 1 = OFF
Programming (See Table 2)
A
= Standard 3.3V with Pin 8 open
or program per Table 2.
Pin Out
Pin
1
2
3
4
5
6
7
7A
8
9
Function
V
o
V
o
V
o
GND
GND
V
IN
V
IN
P
good
Trim
Enable
Description
Output Voltage
Output Voltage
Output Voltage
Ground
Ground
Input Voltage
Input Voltage
Power Good Option
Output Voltage Adjust
Enable Option
TOLERANCES
+.008” for 3 place decimals
+ .02” for 2 place decimals
+ .002” for pin diameter
2.50 (63.5)
0.30
(7.62)
Mechanical
0.55 (14.0)
1 2
3 4
5 6 7 7A 8 9
0.14
(3.56)
.200 (5.08)
0.100 (2.54)
OPTIONAL
0.025 (64)
SQUARE TIP
.14 (3.56)
.16 (4.06)
0.28 (7.2)
1.900 (48.26)
