Embedded Power for
Business-Critical Continuity
AET Series
25 - 30 Watts
Total Power:
25 - 30 Watts
Input Voltage:
12, 24 or 48 V
# of Outputs:
Single, Dual
Rev.09.29.11_183
AET 25-30 W Series
1 of 2
Special Features
Electrical Specifications
Input
Input range:
Efficiency:
9 to 36 VDC; 18 to 75 VDC
85% @ 12 Vo
2.0%
± 0.5%
± 0.5%
Dual output 4%
All models: 100 mV
Auto-restart
120 - 130% nominal output
300KHz
± 0.02% / °C
1500 VDC min
10Mohm
1000pF
• Encapsulated
• 4:1 input range
• 1.6” x 2” package
• 1500 Vdc I/O isolation
• Single and Dual output
• Remote on/off
• Adjustable output
• Conducted noise: meets
EN55022 class A,
FCC level A
Output
Voltage tolerance:
Line regulation:
Load regulation:
Cross regulation:
Noise/ripple:
Short circuit protection:
Overvoltage protection:
Switching frequency:
Temperature coefficient:
Isolation
I/O isolation:
Insulation resistance:
Insulation capacitance:
Environmental Specifications
Safety
• CE Mark
Operating ambient temperature range:
Storage temperature:
Humidity:
MTBF:
-40 °C to +71 °C
-55 °C to +105 °C
5% to 95% non-condensing
500Khrs calculated
Embedded Power for
Business-Critical Continuity
Ordering Information
Input Voltage
9 - 36 V
9 - 36 V
9 - 36 V
9 - 36 V
9 - 36 V
9 - 36 V
9 - 36 V
18 - 75 V
18 - 75 V
18 - 75 V
18 - 75 V
18 - 75 V
18 - 75 V
18 - 75 V
Americas
Output Voltage 2
Maximum Power
20 W
23 W
30 W
30 W
30 W
30 W
30 W
20 W
23 W
30 W
30 W
30 W
30 W
30 W
Rev.09.29.11_183
AET 25-30 W Series
2 of 2
Output Voltage 1
2.5 V @ 8 A
3.3 V @ 7 A
5 V @ 6A
12 V @ 2.5 A
15 V @ 2 A
12 V @ 1.25 A
15 V @ 1 A
2.5 V @ 8 A
3.3 V @ 7 A
5V@6A
12 V @ 2.5 A
15 V @ 2 A
12 V @ 1.25 A
15 V @ 1 A
Model Number
AET08G18-L
AET07F18-L
AET06A18-L
AET02B18-L
AET02C18-L
AET01BB18-L
AET01CC18-L
AET08G36-L
AET07F36-L
AET06A36-L
AET02B36-L
AET02C36-L
AET01BB36-L
AET01CC36-L
5810 Van Allen Way
Carlsbad, CA 92008
USA
Telephone: +1 760 930 4600
Facsimile: +1 760 930 0698
-12 V @ 1.25 A
-15 V @ 1 A
Europe (UK)
Waterfront Business Park
Merry Hill, Dudley
West Midlands, DY5 1LX
United Kingdom
Telephone: +44 (0) 1384 842 211
Facsimile: +44 (0) 1384 843 355
-12 V @ 1.25 A
-15 V @ 1 A
Asia (HK)
Single Output
40.64
(1.60)
15.24
(0.60)
2.54
(0.10)
+Vout
-Vout
Trim
10.16
(0.40)
10.16
(0.40)
5.08
(0.20)
12.19
(0.48)
14/F, Lu Plaza
2 Wing Yip Street
Kwun Tong, Kowloon
Hong Kong
Telephone: +852 2176 3333
Facsimile: +852 2176 3888
Trim
-Vout
+Vout
Ø1.0
(0.04)
For global contact, visit:
www.Emerson.com/EmbeddedPower
Label
50.80
(2.00)
AET06A18-L
IN=9-36Vdc
OUT=5Vdc/6A
Date Code
Enable
-Vin
+Vin
45.72
(1.80)
Bottom View
techsupport.embeddedpower
@emerson.com
While every precaution has been taken to ensure
accuracy and completeness in this literature, Emerson
Network Power assumes no responsibility, and disclaims
all liability for damages resulting from use of this
information or for any errors or omissions.
Pb
RoHS
+Vin
-Vin
Enable
2.54
(0.10)
Top View
5.08
(0.20)
7.63
(0.30)
5.08
(0.20)
15.23
(0.60)
Units: mm (inch)
Tolerance: xx ± 0.50
(± 0.02)
Emerson Network Power.
The global leader in enabling
business-critical continuity.
AC Power
Connectivity
DC Power
Embedded Computing
Embedded Power
Monitoring
Label
Dual Output
40.64
(1.60)
5.08
(0.20)
2.54
(0.10)
+V out
+Vout
COM
-Vout
Trim
10.16
(0.40)
10.16
(0.40)
10.16
(0.40)
5.08
(0.20)
12.19
(0.48)
T rim
-Vout
COM
Ø1.0
(0.04)
Outside Plant
Power Switching & Controls
Precision Cooling
Racks & Integrated Cabinets
50.80
(2.00)
AET01BB18-L
IN=9-36Vdc
OUT=±12Vdc/±1.25A
Date Code
E nable
-V in
+Vin
45.72
(1.80)
Bottom View
Pb
RoHS
+Vin
-Vin
E nable
Services
Surge Protection
7.63
(0.30)
5.08
(0.20)
2.54
(0.10)
Top View
5.08
(0.20)
EmersonNetworkPower.com
Emerson Network Power and the Emerson
Network Power logo are trademarks and
service marks of Emerson Electric Co.
©2011 Emerson Electric Co.
15.23
(0.60)
Units: mm (inch)
Tolerance: xx ± 0.50
( ± 0.02)
