V15
LDP60 SERIES
60WATT OUTPUT
LED POWER SUPPLY
Features
* 60W Single / Dual outputs
* Universal AC input range 90-305Vac
* Constant Current Design
* Active PFC > 0.9
* Low inrush current < 5A
* Low profile with 25.2mm height and narrow 40mm width
* Low frequency flicker design
* Continuous short circuit protection
* Over temperature protection
* IP 67 Rated
* Fully isolated plastic case
* Dimming function: DALI / PWM / 1~10VDC / Potentiometer
Output
Rated
Voltage
24V
24V
24V
24V
24V
24V
36V
36V
36V
36V
48V
48V
48V
48V
24V
Constant
Current
Region
9-24Vdc
16-24Vdc
9-24Vdc
16-24Vdc
9-24Vdc
16-24Vdc
9-36Vdc
24-36Vdc
9-36Vdc
24-36Vdc
9-48Vdc
32-48Vdc
9-48Vdc
32-48Vdc
9-24Vdc
Ripple and
Noise(Vp-p
max.)
Note1
0.24V
2500mA
LDP60A240-C250B
LDP60A240-C210BR
LDP60A240-C210B
LDP60A240-C175BR
LDP60A240-C175B
LDP60A360-C166BR
LDP60A360-C166B
LDP60A360-C140BR
LDP60A360-C140B
LDP60A480-C125BR
LDP60A480-C125B
LDP60A480-C105BR
LDP60A480-C105B
LDP60B240-C125BR
2.2V
0.24V
2100mA
2.2V
0.24V
1750mA
2.2V
0.36V
1666mA
2.7V
0.36V
1400mA
2.7V
0.48V
1250mA
4.8V
0.48V
1050mA
4.8V
V1 1250mA
0.24V
V2 1250mA
V1 1050mA
LDP60B240-C105BR
24V
9-24Vdc
0.24V
V2 1050mA
V1
LDP60B360-C083BR
36V
9-36Vdc
0.36V
V2
V1
LDP60B360-C070BR
36V
9-36Vdc
0.36V
V2
V1
LDP60B480-C062BR
48V
9-48Vdc
0.48V
V2
625mA
56Vdc
30W
700mA
625mA
43Vdc
56Vdc
25.2W
30W
87%
833mA
700mA
43Vdc
43Vdc
30W
25.2W
84%
833mA
29Vdc
43Vdc
25.2W
30W
85%
29Vdc
29Vdc
30.0W
25.2W
84%
29Vdc
30.0W
85%
56Vdc
50.4W
89%
56Vdc
60.0W
90%
85%
43Vdc
50.5W
88%
86%
43Vdc
60.0W
89%
84%
29Vdc
42.0W
86%
85%
29Vdc
50.4W
87%
84%
29Vdc
60.0W
88%
84%
Output
Rated
Current
No Load Output
Voltage
(max.)
Output
Rated
Power
%EFF
(typ.)
85%
MODEL
LDP60A240-C250BR
Note : Ripple and Noise are measured at 20MHz bandwidth with a 0.1uF ceramic capacitor and 10uF aluminum capacitor.
All specifications are Typical at nominal line, full load and 25˚C unless otherwise noted
1
V15
Order
Information:
Series
LDP
Output(W)
60
O/P: Single/Dual
X
Output Voltage
XXX
Dimming Function
X
Rated Output Current
XXX
250: 2500mA
240：24V
A：Single O/P
with IP67
24V
210: 2100mA
175: 1750mA
360：36V
C：No dimming
D：DALI dimming
P：PWM 1-10V,
Potentiometer
36V
166: 1666mA
140: 1400mA
125: 1250mA
48V
24V
105: 1050mA
125: 1250mA
105: 1050mA
36V
48V
082: 833mA
070: 700mA
062: 625mA
：
B 100-277 Vac
R：1% output
ripple and noise
or
Blank：10% output
ripple and noise
Input Voltage
B
Ripple Nosie
X
480：48V
240：24V
B：Dual O/P
with IP67
360：36V
480：48V
Specifications
INPUT SPECIFICATIONS:
AC Input Voltage …….…………................................. 90~305Vac.
Frequency ………………………………………….……………….. 50/60Hz.
Power Factor………….115Vac/230Vac….……PF≧0.9 at 75%~100%Load.
Inrush Current …………….….. <5A after 100us @240Vac, Cold Start @25℃.
Leakage Current …………………………..….….………..…..…… 0.75mA max.
No load Consumption……………………………………2W typ.(Note 1)
LDP60 Series Derating Curve
OUTPUT SPECIFICATIONS:
Maximum Output Voltage…..………………………………….…… See Table.
Constant Current Accuracy…(note 2)…….…………….……..………±5%max.
Current Line Regulation ……(note 3)………………………..………. ±5%max.
Current Load Regulation …..(note 4)……………………..………. ±5%max.
Start up time…………………………………………..……..….. 0.5 second max.
Over Voltage Protection……………………………………….…..….TVS Clamp.
Short Circuit Protection……………………..….. Hiccup Mode, Auto Recovery
Over Temperature Protection…………………………...…….…105℃ typ.
55W
65W
60W
GENERAL SPECIFICATIONS:
Efficiency………………………………………….………..………...…See Table.
Temperature coefficient………..……....……………….......±0.05%/℃(0~50℃).
Isolation voltage, Input to output…………..…………….……....…….3.75KVac.
8
Isolation resistance, Input to output………………………..……10
Ω
min.
Operating Ambient Temperature ..................-40 ~ 70℃(see derating curve).
Cooling……………………………………………..………….natural convection.
Storage Temperature……...……………………………................... -40 ~ 85℃.
Operating Humidity………...…...….……….20%~95%RH non-condensing.
Operating Altitude…………………………………….Sea Level to 3000m
MTBF,MIL-HDBK-217F (25℃ Ta) ……..……………………...…200K Hrs.
Dimensions.……......…...10.315x1.575x0.992inch (262.00x40.00x25.20mm).
Weight……………………..………………………………………..…………530g.
50W
45W
90VAC
100VAC
115VAC
230VAC
277VAC
305VAC
SAFETY AND EMISSIONS:
Safety……............................................................UL8750, IEC/EN61347-1
IEC/EN61347-2-13
EMI……………………………………............FCC part 15/EN55015 Class B
EMS……….....................................….EN61547,EN61000-4-2,3,4,5,6,8,11
EN61000-3-2 Harmonic Class C,EN61000-3-3
NOTE:
1.No load power consumption 1W will be introduced in Sep. 2014.
2. Current accuracy is set at nominal input voltage and full load.
3. Line regulation is measured from High Line to Low Line with full load.
4. Load regulation is measured minimum to maximum of the constant.
current region
5. Nominal Input Voltage at 230Vac
6. The input/output wires accessibility shall be evaluated during final
system assembly.
All specifications are Typical at nominal line , full load and 25˚C unless otherwise noted
2
V15
Mechanical Specification
Single output
All Dimensions are in inches(mm)
Tolerance:Inches:X.XXX±0.02
Millimeters:X.XX±0.5
11.102[282.00]
10.709[272.00]
10.315[262.00]
11.811[300.00]±0.787[20.00]
0.787[20.00]
0.394[10.00]
0.787[20.00]
Black ACL
INPUT
OUTPUT
UL 2464 16AWG+22AWG
22AWG Blue D+ (Optional)
22AWG White D-
16AWG Red +Vo
16AWG Black -Vo
White ACN
0.394[10.00]
UL 2464 18AWG
11.811[300.00]±0.787[20.00]
0.992[25.20]
1.575[40.00]
1.024[26.00]
0.276[7.00]
Dual Output
All Dimensions are in inches(mm)
Tolerance:Inches:X.XXX±0.02
Millimeters:X.XX±0.5
11.102[282.00]
10.709[272.00]
10.315[262.00]
11.811[300.00]±0.787[20.00]
0.787[20.00]
0.394[10.00]
0.787[20.00]
Black ACL
INPUT
OUTPUT
UL 2464 16AWG+22AWG
22AWG Blue D+
22AWG White D- (Optional)
16AWG Red +Vo
16AWG Black -Vo
Black-Vo
White ACN
0.394[10.00]
UL 2464 18AWG
UL 2464 16AWG
Red +Vo
11.811[300.00]±0.787[20.00]
0.394[10.00]
0.787[20.00]
11.811[300.00]±0.787[20.00]
WIRE CONNECTION
NO
COLOR
DIMMING
0.992[25.20]
1.575[40.00]
PWM
DIMMING
D+
D-
+VO
-VO
DALI
DIMMING
DA
DA
+VO
-VO
BLUE
WHITE
RED
BLACK
(N.A.)
(N.A.)
+VO
-VO
1.024[26.00]
0.276[7.00]
All specifications are Typical at nominal line , full load and 25˚C unless otherwise noted
3
