1. PHYSICAL DIMENSIONS
1.55MAX
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC..........................................10 A RMS MAX
B. @ 250 VAC.........................................10 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.20 mA MAX
B. @ 250 VAC 50Hz.............................0.40 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
1
1
.10
2
2
.15
4
4
.50
10
10
1.0
13
15
5.0
28
25
10
35
30
30
40
40
1-3.
1.575 ± 0.02
1.18MAX
1.99MAX
3
1
1-4.
G
5
2
4
1-5.
Ø0.13
1.97MAX
CUTOUT (MOUNTING FROM FRONT)
R0.098(2X)
0.83MAX
M3
1.20 ±
0.02
0
0.835 ±
0
.012
1-6.
FREQ. MHz
COM. MODE dB
DIF. MODE dB
1-7.
1-8.
1-9.
OPERATING TEMPERATURE.................-25° TO +85° C
SAFETY:
RoHS COMPLIANT
R0.04MAX(2X)
2. ELECTRICAL SCHEMATIC
1.575 ± 0.005
L:
C1:
C2:
R:
0.2mH
0.1uF
2200pF
1MΩ
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
858-10/022
EMI FILTER
UNIT: in
REV. B
Approved / Date
JJH / 09-24-01
Drawn / Date
B.ZHANG
09-24-01
Checked / Date
09-24-01
