BYW36/4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BYW36/4

BYW36/4: DescriptionRectifiers 600 Volt 2.0 Amp 50 Amp IFSM; Categorysemiconductor Discrete semiconductor; File Size121KB，4 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric Compare View All

BYW36/4 Overview

Rectifiers 600 Volt 2.0 Amp 50 Amp IFSM

BYW36/4 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Vishay
Product Category	Rectifiers
RoHS	N
Mounting Style	Through Hole
Package / Case	SOD-57
Vr - Reverse Voltage	600 V
If - Forward Current	2 A
Type	Fast Recovery Rectifiers
Configuration	Single
Vf - Forward Voltage	1.1 V
Max Surge Current	50 A
Ir - Reverse Current	5 uA
Recovery Time	200 ns
Minimum Operating Temperature	- 55 C
Maximum Operating Temperature	+ 175 C
Packaging	Cut Tape
Packaging	Reel
Height	3.6 mm
Length	4.2 mm
Product	Rectifiers
Width	3.6 mm
Factory Pack Quantity	4500
Unit Weight	0.013016 oz

Preview

Download Datasheet

View All

BYW32, BYW33, BYW34, BYW35, BYW36

www.vishay.com

Vishay Semiconductors

Fast Avalanche Sinterglass Diode

FEATURES

• Glass passivated junction

• Hermetically sealed package

• Low reverse current

• Soft recovery characteristics

• Material categorization:

For definitions of compliance please see

www.vishay.com/doc?99912

949539

APPLICATIONS

• Fast rectification an switching diode for example for

TV-line output circuits and switch mode power supply



MECHANICAL DATA

Case:

SOD-57

Terminals:

plated axial leads, solderable per MIL-STD-750,

method 2026

Polarity:

color band denotes cathode end

Mounting position:

any

Weight:

approx. 369 mg

ORDERING INFORMATION

(Example)

DEVICE NAME

BYW36

ORDERING CODE

BYW36-TR

BYW36-TAP

TAPED UNITS

5000 per 10" tape and reel

5000 per ammopack

MINIMUM ORDER QUANTITY

25 000

PARTS TABLE

PART

BYW32

BYW33

BYW34

BYW35

BYW36

TYPE DIFFERENTIATION

= 200 V; I

F(AV)

= 2 A

= 300 V; I

F(AV)

= 2 A

= 400 V; I

F(AV)

= 2 A

= 500 V; I

F(AV)

= 2 A

= 600 V; I

F(AV)

= 2 A

PACKAGE

SOD-57

ABSOLUTE MAXIMUM RATINGS

amb

= 25 °C, unless otherwise specified)

PARAMETER

TEST CONDITION

PART

BYW32

BYW33

Reverse voltage = repetitive peak

reverse voltage

See electrical characteristics

BYW34

BYW35

BYW36

Peak forward surge current

Repetitive peak forward current

Average forward current

Non repetitive reverse avalanche

energy

Junction and storage temperature

range



= 180°

(BR)R

= 0.4 A

= 10 ms, half sine wave

SYMBOL

= V

RRM

= V

RRM

= V

RRM

= V

RRM

= V

RRM

FSM

FRM

F(AV)

= T

stg

VALUE

200

300

400

500

600

- 55 to + 175

UNIT

°C

Rev. 1.8, 11-Sep-12

Document Number: 86048
