HDAS-16, HDAS-8
12-Bit, 50kHz, Complete Data Acquisition Systems
FEATURES
Miniature 62-pin cermanic package
12-Bit resolution, 50kHz throughput
Full-scale input range from 50mV to 10V
Three-state outputs
S.E. or 8 differential input channels
16
Auto-sequencing channel addressing
MIL-STD-883 versions
missing codes
No
Available in SMT or DIP packages
GENERAL DESCRIPTION
Using thin and thick-film hybrid technology, DATEL offers complete low-cost
data acquisition systems with superior performance and reliability.
The HDAS-8 (with 8 differential input channels) and the HDAS-16 (with
16 single-ended input channels) are complete, high-performance, 12-bit
data acquisition systems in 62-pin SMT or DIP packages. Each HDAS may
be expanded up to 32 single-ended or 16 differential channels by adding
externalmultiplexers.
Internal channel address sequencing is automatic after each conversion,
or the user may supply external channel addresses.
OFFSET ADJUST
Internal HDAS circuitry includes:
Analog input multiplexer (16 S.E. or 8 diff.)
Resistor-programmable instrumentation amplifier
Sample-and-hold circuit complete with MOS hold capacitor
Volt buffered reference
10
12-bit A/D converter with three-state outputs and control logic
ANA SIG COM
ANA SIG COM
BIPOLAR INPUT
+10V REF OUT
MUX ENABLE
AMP IN LO
RGAIN LO
AMP IN HI
RGAIN HI
5
49 50
48
47
45
46
39
40 38 36 37
GAIN ADJUST
S/H OUT
CH0 HI /CH0
CH1 HI /CH1
CH2 HI /CH2
CH3 HI /CH3
CH4 HI /CH4
CH5 HI /CH5
CH6 HI /CH6
CH7 HI /CH7
CH0 LO /CH8
CH1 LO /CH9
CH2 LO /CH10
CH3 LO /CH11
CH4 LO /CH12
CH5 LO /CH13
CH6 LO /CH14
CH7 LO /CH15
4
3
2
1
62
61
60
59
58
57
56
55
54
53
52
51
I/A
16 CHANNEL
SINGLE ENDED
OR
8 CHANNEL
DIFFERENTIAL
ANALOG
MULTIPLEXER
S/H
12-BIT
A/D
CONVERTER
THREE
STATE
(HOLD)
(START)
THREE
STATE
CONTROL
LOGIC
MUX
ADDRESS
REGISTER
+5V SUPPLY
12 11 10
9
6
8
19
16 15 1413
20
41
44 42
43 18 17
RDELAY
CLEAR
MUX
ADDRESS OUT
MUX
ADDRESS IN
–15V SUPPLY
ANA PWR COM
ANA SIG COM
+15V SUPPLY
DIG COM
STROBE
LOAD
RA1
RA2
RA4
RA8
A1
A2
A4
A8
Figure 1. Functional Block Diagram
