XC6134 Series
ETR02029-001
Delay capacitor adjustable voltage detectors with sense pin isolation and HYS
external adjustment
■GENERAL
DESCRIPTION
The XC6134 series are ultra-small delay capacitor adjustable type voltage detectors that have high accuracy and sense pin
isolation. High accuracy and a low supply current are achieved by means of a CMOS process, a highly accurate reference
power supply, and laser trimming technology.
The sense pin is isolated from the power input pin to enable monitoring of the voltage of another power supply. Output can be
maintained in the detection state even if the voltage of the power supply that is monitored drops to 0V. The sense pin is also
suitable for detecting high voltages, and the detection and release voltage can be set as desired using external resistors. An
internal delay circuit is also provided. By connecting a capacitor to the Cd/MRB pin, any release delay time and detect delay
time can be set, and the pin can also be used as a manual reset pin. The HYS external adjustment pin can be used to
establish a sufficient hysteresis width.
■APPLICATIONS
●Microcontroller
reset and malfunction monitoring
●Battery
voltage monitoring
●System
power-on reset
●Power
failure detection
■FEATURES
: -40℃½+125℃
: 1.6V½6.0V
: 0.8V½5.0V
: ±18mV(V
DF
＜1.5V)
: ±1.2%(1.5V≦V
DF
≦3.0V)
: ±1.5%(3.1V≦V
DF
≦5.0V)
: ±36mV(V
DF
＜1.5V)
Detect voltage accuracy
: ±2.7%(1.5V≦V
DF
≦3.0V)
(Ta=-40½125℃)
: ±3.0%(3.1V≦V
DF
≦5.0V)
: ±50ppm/℃(TYP.)
Temperature Characteristics
: V
DF
×0.1%(TYP.)
Hysteresis width
Adjustable Pin for Hysteresis Width : Yes
: 1.28μA(TYP.)
Low supply current
V
IN
=1.6V(At detection)
: 1.65μA(TYP.)
V
IN
=6.0V(At release)
: Yes (For details, refer to
Manual reset function
FUNCTION CHART)
: CMOS or Nch open drain
Output type
: H level or L level at detection
Output logic
: Release delay / detection delay
Delay capacitance pin
can be set in 5 time ratio options
(For details, refer to Selection Guide).
: USP-6C,SOT-26
Packages
: EU RoHS compliant, Pb free
Environment friendly
Operating Ambient Temperature
Operating voltage range
Detect voltage range
Detect voltage accuracy
(Ta=25℃)
■TYPICAL
APPLICATION CIRCUIT
■TYPICAL
PERFORMANCE
CHARACTERISTICS
+B
R3
HYS
V
SEN
V
DD
V
IN
=3.3V、V
SEN
=0V→6V→0V
R1=330kΩ
R1
V
IN
Rpull
(*1)
4.0
XC6134C10B
R2
RESET
SW
Cd
Cd/MRB
V
SS
RESET
RESETB
Output Voltage : V
RESET
(V)
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
R3=0Ω
R3=330kΩ
R3=110kΩ
GND
Battery (+B) voltage monitoring: Detects high voltage
by R1/R2 resistance dividing.
A hysteresis width can be added as desired by
connecting R3 between the V
SEN
and HYS pins
(For details, refer to OPERATIONAL DESCRIPTION).
V
SEN
pin Voltage : V
SEN
(V)
1/28
XC6134
Series
■BLOCK
DIAGRAMS (Continued)
(3)XC6134N Series A/B/C/D/L type (RESET OUTPUT: Nch open drain/Active High)
V
SEN
V
IN
R
SEN
=RA+RB+RC
+
HYS
M2
M4
Rp
VREF
RB
M3
Cd/MRB
RC
M1
* Diodes inside the circuit are an ESD protection diode and a parasitic diode.
(4)XC6134N Series E/F/H/K/M type (RESETB OUTPUT: Nch open drain/Active Low)
V
SEN
V
IN
R
SEN
=RA+RB+RC
+
VREF
RB
M3
Cd/MRB
RC
M1
* Diodes inside the circuit are an ESD protection diode and a parasitic diode.
-
RA
-
RA
Rn
DELAY/
MRB
CONTROL
BLOCK
M5
RESET
V
SS
HYS
M2
M4
Rp
Rn
DELAY/
MRB
CONTROL
BLOCK
M5
RESETB
V
SS
3/28
XC6134
Series
■PIN
CONFIGURATION
●A/B/C/D/L
type
Cd/MRB
6
V
SS
5
V
SEN
4
1 HYS
2 RESET
3 V
IN
V
SEN
6
V
SS
5
1
V
IN
2
3
Cd/MRB 4
RESET HYS
SOT-26
(TOP VIEW)
USP-6C
(BOTTOM VIEW)
●E/F/H/K/M
type
Cd/MRB
6
V
SS
5
V
SEN
4
1 HYS
2 RESETB
3 V
IN
V
SEN
6
V
SS
5
1
V
IN
2
3
Cd/MRB 4
RESETB HYS
SOT-26
(TOP VIEW)
USP-6C
(BOTTOM VIEW)
*The dissipation pad for the USP-6C package should be solder-plated in reference mount pattern and metal masking so as to
enhance mounting strength and heat release. If the pad needs to be connected to other pins, it should be connected to V
SS
(No.
5) pin.
■PIN
ASSIGNMENT
PIN NUMBER
SOT-26
1
2
3
4
5
6
(*1)
USP-6C
3
2
1
6
5
4
PIN NAME
V
IN
RESETB
RESET
HYS
V
SEN
V
SS
Cd/MRB
FUNCTION
Power Input
Reset Output (Active Low)
(*1)
Reset Output (Active High)
(*1)
Adjustable Pin for Hysteresis Width
Voltage Sense
Ground
Adjustable Pin for Delay Time/
Manual Reset
Refer to the
④
in Ordering Information table.
5/28
