HV2201FG-G Overview

Analog Switch ICs Lo-Charge 8-Channel Enhanced Hi-Voltage

HV2201FG-G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Microchip
package instruction	1.4 MM HEIGHT, GREEN, TQFP-48
Reach Compliance Code	compliant
Factory Lead Time	5 weeks
Samacsys Description	Analog Switch ICs Lo-Charge 8-Channel Enhanced Hi-Voltage
Other features	IT ALSO REQUIRES VPP (40V TO VNN +200V) AND VNN (-40V TO -160V) SUPPLY
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	S-PQFP-G48
JESD-609 code	e3
length	7 mm
normal position	NO
Number of channels	1
Number of functions	8
Number of terminals	48
Nominal off-state isolation	33 dB
On-state resistance matching specifications	1.35 Ω
Maximum on-state resistance (Ron)	27 Ω
Maximum operating temperature	70 °C
Minimum operating temperature
output	SEPARATE OUTPUT
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP48,.35SQ,20
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)	260
power supply	3.3/5,+-40/+-160 V
Certification status	Not Qualified
Maximum seat height	1.6 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
Maximum disconnect time	5000 ns
Maximum connection time	5000 ns
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Matte Tin (Sn) - annealed
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	40
width	7 mm

Preview

Download Datasheet

View All

Supertex inc.

Low Charge Injection, 8-Channel,

Enhanced, High Voltage Analog Switch

►

HV2201

Features

HVCMOS technology for high performance

8 Channels of high voltage analog switch

3.3 or 5.0V CMOS input logic level

20MHz data shift clock frequency

Very low quiescent power dissipation (-10µA)

Low parasitic capacitance

DC to 50MHz analog signal frequency

-60dB typical off-isolation at 5.0MHz

CMOS logic circuitry for low power

Excellent noise immunity

Cascadable serial data register with latches

Flexible operating supply voltages

General Description

The Supertex HV2201 is a low charge injection, 8-channel, high

voltage analog switch integrated circuit (IC). The device can be

used in applications requiring high voltage switching controlled by

low voltage control signals, such as medical ultrasound imaging,

piezoelectric transducer drivers, and printers. The HV2201 is an

enhanced version of the HV20220.

Input data is shifted into an 8-bit shift register that can then be

retained in an 8-bit latch. To reduce any possible clock feed-

through noise, the latch enable bar should be left high until all

bits are clocked in. Data is clocked in during the rising edge of

the clock. Using HVCMOS technology, this device combines high

voltage bilateral DMOS switches and low power CMOS logic to

provide efficient control of high voltage analog signals.

The device is suitable for various combinations of high voltage

supplies, e.g., V

: +40V/-160V, +100V/-100V, and +160V/-

40V.

►

Applications

Medical ultrasound imaging

NDT metal flaw detection

Piezoelectric transducer drivers

Inkjet printer heads

Optical MEMS modules

Block Diagram

Latches

Level

Shifters

Output

Switches

SW0

CLK

8-Bit

Shift

SW1

DIN

DOUT

SW2

SW6

SW7

VDD

GND

CLR

VNN

VPP

Supertex inc.

1235 Bordeaux Drive, Sunnyvale, CA 94089

Tel: 408-222-8888

www.supertex.com
