Feed-Through Double Level
Altech double level terminals
are the answer to high wiring
density problems posed by cer-
tain unavoidable wiring arrange-
ments. Double level terminals
have the following advantages:
• Double wiring density avail-
able without extension of
mounting rails.
• Interconnection/shorting can
be done at both levels.
• Marking/identification by
marking tags possible at
both levels.
CDL4UN(I.S) internally shorted
double level terminals are useful
for distribution applications by
using shorting links at lower lev-
els.
Now uses larger MT6 tag for
easier visibility.
CDL4UN
CDL4UN(I.S)
NEW
Terminal Width
Height x Length
Stripping Length
Insulation Material
Type of Connection
Approvals
60947-7-1
E220514
NEW
6 mm
54 x 55.5 mm
9 mm
Polyamide 6.6
4 screw clamps & 1 tapped hole for cross connection
60947-7-1
E220514
6 mm
54 x 55.5 mm
9 mm
Polyamide 6.6
4 screw clamps & 2 tapped holes for cross connection
Wire Range
Voltage Rating
Current Rating
Torque
Other Approvals
22-10 AWG
600V
35 A
7 lb-in
0.2-4 sq.mm
800 V
32 A
0.5 Nm
22-10 AWG
600 V
35 A
7 lb-in
22-10 AWG
600 V
35 A
7 lb-in
0.2-4 sq.mm
800 V
32 A
0.5 Nm
22-10 AWG
600 V
35 A
7 lb-in
Cat. No.
Std. Pk.
100
50
100
Cat. No.
Std. Pk.
100
50
100
Terminal Block
End Plate
Separator Plate
DIN Rail
for ordering information
refer to pages 90-91
End Stop
for ordering information
refer to page 92
Internal
Jumper
2 pole
3 pole
4 pole
10 pole
2 pole
3 pole
4 pole
10 pole
2 pole
3 pole
4 pole
10 pole
10 pole (breakable)
100 pole
CDL4UN
EPCDL4UN
SPCDL4U
CDL4UN(I.S)
EPCDL4UN
SPCDL4U
CA702
CA802
CA722/2
CA722/3
CA722/4
CA722/10
CA742/2
CA742/3
CA742/4
CA742/10
CA703/1
CA704/1
CA705/1
CA732/10
CA732/10-A
CA732/100
CA707/S/Q/01
2 pole
3 pole
4 pole
10 pole
CA714/2
CA714/3
CA714/4
CA714/10
MT6
50
50
100
50
50
10
100
50
50
10
100
100
100
100
100
10
100
100
100
50
25
100
CA702
CA802
CA722/2
CA722/3
CA722/4
CA722/10
CA742/2
CA742/3
CA742/4
CA742/10
CA703/1
CA704/1
CA705/1
CA732/10
CA732/10-A
CA732/100
CA607/S/Q
CA714/2
CA714/3
CA714/4
CA714/10
MT6
50
50
100
50
50
10
100
50
50
10
100
100
100
100
100
10
100
100
100
50
25
100
COLOR BLOCKS
(other than standard grey)
Insulated
Internal
Jumper
When ordering please add
color suffix to Cat. No.
Example for color Red:
Cat.No./R
Ordering Suffix
R
Y
BU
G
Consult Altech for availability
:
Orange
O
Beige
BG
Dark Brown DB
Black
BL
White
W
Color
Red
Yellow
Blue
Green
Current
Bars
Shorting Sleeve & Screw
External
Jumper
Marking Tags
