REVISIONS
REV
21.2
Ø3.8
Ø3.0
A1
ECO
-
DESCRIPTION
RELEASE NEW DWG FORMAT
DATE
NOV/07/15
BY
APPR
SULLEN TOMMY
TITLE:
RECEPTACLE, 3 PIN,PCB,BOARD MOUNT
8.60
21.0
3-Ø1.50
5.05
24.4
7.45
5.05
Ø3.30
DWG NO:
3.20
RESERVOIR
7.45
3-Ø1.70
AT04-3P-BMXX
NOTES: UNLESS OTHERWISE SPECIFIED
1. MATERIAL:
HOUSING: THERMOPLASTIC; COLOR: BLACK
CONTACT: COPPER ALLOY
2. MODIFICATIONS: PCB MOUNT
3. SPECIFICATIONS:
3.1 CURRENT RATING: 13 AMPS
3.2 OPERATING TEMPERATURE: -55°C TO +125°C
3.3 DIELECTRIC WITHSTANDING VOLTAGE: LESS THAN 2
MILLIAMPS CURRENT LEAKAGE @ 1500 VOLTS AC.
3.4 INSULATION RESISTANCE: 1000 MEGOHMS MIN @ 25°C.
3.5 MOISTURE RESISTANCE: IP67 ( MATED CONDITION )
3.6 MATING CYCLE DURABILITY: 100 CYCLES
3.7 RoHS COMPLIANT
4. MATING PART: AT06-3S* PLUG
( * = MODIFICATIONS AND COLORS )
5. ALL DIMENSIONS ARE FOR REFERENCE USE ONLY.
CONTACT
PLATING
GOLD
GOLD
NICKEL
NICKEL
4.30
1.7
8.60
RECOMMENDED LAYOUT
VIEW FROM COMPONENTS
SIDE OF PCB
REV:
A1
SH:
1
QUANTITY
SEE PART NUMBER
CHART
DESCRIPTION
PART NUMBER
MATERIALS LIST
SIGNATURES
DRAWN:
CHECKED:
ENGINEER:
APPROVAL:
OF:
ITEM
1
UNLESS OTHERWISE SPECIFIED
1) All dimensions are in metric(mm).
2) Tolerances are as follows:
1 PL DEC
±0.30
Fractions
±1/64
2 PL DEC
±0.15
Angles
±1°
3 PL DEC
±0.08
3) Note reference =
DATE
AT04-3P-BMXX VARIANTS
POTTING OR NOT
IN RESERVOIR
NO POTTING
POTTING
NO POTTING
POTTING
PART NUMBER
AT04-3P-BM01
AT04-3P-BM02
AT04-3P-BM03
AT04-3P-BM04
SULLEN.ZHANG 07/NOV/15
ORION.LI
07/NOV/15
TOMMY.XIE
07/NOV/15
Amphenol
Sine Systems - www.amphenol-sine.com
44724 Morley Drive
Clinton Township, MI 48036
X
MATERIAL SPECIFICATIONS:
CUSTOMER:
THIS DRAWING IS SUPPLIED FOR
INFORMATION ONLY. DESIGN FEATURES,
SPECIFICATIONS AND PERFORMANCE DATA SIZE
SHOWN HEREON ARE THE PROPERTY OF
THE AMPHENOL CORPORATION. NO RIGHTS
OF REPRODUCTION ARE IMPLIED. ALL
DIMENSIONS ARE SUBJECT TO NORMAL
SCALE:
MANUFACTURING VARIATIONS.
RECEPTACLE, 3 PIN,
PCB, BOARD MOUNT
TYPE
DWG NO:
PROCESS SPECIFICATIONS:
REVISION
B C-
NONE
AT04-3P-BMXX
SHEET
A1
1
OF
NEXT ASS'Y:
1
