Chip EMI Filters
Chip EMI Filters
Type:
EXCCET
Discontinued
■
Features
●
Rated current (2 A max.)
●
Eight capacitance values in a wide range, related to
the noise frequency
●
Suitable for narrow pitch insertion
●
Suitable for applications requiring thin design
●
RoHS compliant
■
Recommended Applications
●
Digital equipment such as PCs, word processors,
printers, HDD, PPC and communication equipment.
●
Digital audio and video equipment.
●
AC adapters and switching power supplies.
●
Electronic musical instruments and other digital
equipment.
■
Explanation of Part Numbers
1
2
3
4
5
6
7
8
9
10
Product Code
Type
Circuit
Nominal
Capacitance Value
Form
Noise Filter
Chip type
T-circuit
EMI filter
The first two digits are
significant figures of
capacitance value and the
third one denotes the number
of zeros following.
Code
U
Packing
Embossed Carrier Taping
■
Construction
Ferrite core
■
Dimensions in mm (not to scale)
0.5±0.2
4.5±0.4
Adhesive
1.0±0.2
0.5±0.2
1.8±0.2
Chip capacitor
Electrode
Size : 1807 inch
Mass (Weight) : 92.5 mg/pc.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Nov. 2012
2.7±0.3
Chip EMI Filters
■
Ratings
Part Number
EXCCET220U
EXCCET470U
EXCCET101U
EXCCET271U
EXCCET471U
EXCCET102U
EXCCET222U
EXCCET103U
Discontinued
Rated
Voltage
(V DC)
50
50
50
50
50
50
50
50
(1)
Capacitance
(pF)
22
47
100
270
470
1000
2200
10000
Toler-
ance
(%)
±20
±20
±20
±20
±20
±20
±20
±20
Rated
DC
25 dB Attenuate 15 dB Attenuate
Frequency
Current Resistance
Frequency
Characteristics
(MHz)
(A DC)
(mΩ)
(MHz)
(2)
YB
YB
YB
YB
YB
YB
YB
YB
2
2
2
2
2
2
2
2
50 max.
50 max.
50 max.
50 max.
50 max.
50 max.
50 max.
50 max.
800 to 1000
450 to 550
300 to 450
200 to 300
100 to 220
65 to 200
35 to 180
15 to 120
600 to 1000
350 to 1000
200 to 900
80 to 700
50 to 700
30 to 700
15 to 700
15 to 700
(1) Please inquire to us about the particular capacitance value, on a range of 22 to 10000 pF.
(2) Characteristics YB: Maximum capacitance is ±10 % over the temperature range of –25 °C to +85 °C in reference to +20 °C.
●
Category Temperature Range –40 °C to +85 °C
■
Attenuation Characteristics (Reference Data)
0
Attenuation(dB)
10
20
30
40
222 102
50
60
1M
10M
Frequency (Hz)
100M
1G
103
101
471271
470
220
50
Sample
Measurement Circuit
~
50
■
Packaging Methods (Taping)
●
Standard Quantity
Part Number
EXCCET□□□U
Kind of Taping
Embossed Carrier Taping
Pitch (P
1
)
4 mm
Quantity
1000 pcs./reel
●
Embossed Carrier Taping
●
Taping Reel
T
Sprocket hole
fD
0
A
B
Compartment
E
f
C
F
W
f
B
W
f
D
P
1
P
2
P
0
Tape running direction
t
2
Chip component
f
A
A
Dimensions
(mm)
B
4.9
±0.2
P
0
4.0
±0.1
W
F
P
1
4.0
±0.1
Dimensions
(mm)
0A
0
180.0
–3.0
0B
60.0±1.0
W
0C
13.0±0.5
T
0D
21.0±0.8
2.2
±0.2
P
2
12.0
±0.2
5.50
±0.05
0D
0
t
2
E
Dimensions
(mm)
Dimensions
(mm)
2.0
±0.1
1.5
±0.1
3.5 max.
2.0±0.5
13.0±1.0 16.5 max.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Nov. 2012
Chip EMI Filters
■
Recommended Land Pattern Design(mm)
●
For Single Mounting
Resist
1.15
0.2
1.0
1.15
Copper foil
Discontinued
●
For High Density Mounting
0.2
Resist
1.0
Copper foil
1.4
2.54
Resist
5.4
Using the land pattern which we do not recommend,
or mounting by the solder under 180μm, verify the
performance, reliability, etc. thoroughly.
1.3
5.4
1.3
■
Recommended Soldering Conditions
Recommendations and precautions are described below.
●
Recommended soldering conditions for reflow
· Reflow soldering shall be performed a maximum of
two times.
· Please contact us for additional information when
used in conditions other than those specified.
· Please measure the temperature of the terminals
and study every kind of solder and printed circuit
board for solderability before actual use.
Peak
Temperature
Preheating
Heating
For soldering (Example : Sn-37Pb)
Preheating
Main heating
Peak
Temperature
140 °C to 160 °C
Above 200 °C
235 ± 10 °C
Time
60 s to 120 s
30 s to 40 s
max. 10 s
For lead-free soldering (Example : Sn/3Ag/0.5Cu)
Temperature
Time
Preheating
150 °C to 170 °C
60 s to 120 s
Main heating
Above 230 °C
30 s to 40 s
Peak
max. 260 °C
max. 10 s
Time
●
Flow soldering
· Chip EMI Filters cannot be mounted on a printed circuit board by flow soldering.
Mount them by reflow soldering.
<Repair with hand soldering>
●
Preheat with a blast of hot air or similar method. Use a soldering iron with a tip temperature of 350 °C or less. Solder
each electrode for 3 seconds or less.
●
Never touch this product with the tip of a soldering iron.
Safety Precautions
The following are precautions for individual products. Please also refer to the common precautions for Noise Suppression
Device shown on this catalog.
1. Use rosin-based flux or halogen-free flux.
2. For cleaning, use an alcohol-based cleaning agent. Before using any other type, consult with our sales person
in advance.
3. Do not apply shock to Chip EMI Filters (hereafter called the filters) or pinch them with a hard tool (e.g. pliers and
tweezers). Otherwise, their bodies may be chipped, affecting their performance. Excessive mechanical stress
may damage the filters. Handle with care.
4. Avoid applying static electricity to the filters.
5. The performance of the filters deteriorates in a circuit that is susceptible to surges or other abnormal voltages.
Carefully check the circuit operations before use.
6. Store the filters in a location with a temperature ranging from – 5 °C to +40 °C and a relative humidity of 40 % to 60 %,
where there are no rapid changes in temperature or humidity.
7. Use the filters within a year after the date of the outgoing inspection indicated on the packages.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Nov. 2012
1.4
1.3
1.3
1.4
