(2/13)
E M C
C o m p o n e n t s
REMINDERS FOR USING THESE PRODUCTS
Before using these products, be sure to request the delivery specifications.
SAFETY REMINDERS
Please pay sufficient attention to the warnings for safe designing when using these products.
REMINDERS
The storage period is less than 6 months. Be sure to follow the storage conditions (Temperature: 5 to 40°C, Humidity: 10 to 75% RH or
less).
The case may crack when it is handled below freezing point or when it experiences a fall or other mechanical shock, as it is made of
plastic; please exercise caution when handling the case.
Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.).
In a case where the product is attached to a cable larger than the product's internal diameter, the ferrite core may be damaged.
Please confirm compatibility with the cable before use.
Dropping or forcible engagement may cause damage to the product.
Please handle the product with care when engaging.
Do not detach and reuse a product that has been engaged; this may damage the engaged portion.
Do not expose the products to magnets or magnetic fields.
Do not use for a purpose outside of the contents regulated in the delivery specifications.
The products listed on this catalog are intended for use in general electronic equipment (AV equipment, telecommunications
equipment, home appliances, amusement equipment, computer equipment, personal equipment, office equipment, measurement
equipment, industrial robots) under a normal operation and use condition.
The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or
quality require a more stringent level of safety or reliability, or whose failure, malfunction or trouble could cause serious damage to
society, person or property.
If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or conditions
set forth in the each catalog, please contact us.
(1) Aerospace/Aviation equipment
(2) Transportation equipment (cars, electric trains, ships, etc.)
(3) Medical equipment
(4) Power-generation control equipment
(5) Atomic energy-related equipment
(6) Seabed equipment
(7) Transportation control equipment
(8) Public information-processing equipment
(9) Military equipment
(10) Electric heating apparatus, burning equipment
(11) Disaster prevention/crime prevention equipment
(12) Safety equipment
(13) Other applications that are not considered general-purpose
applications
When designing your equipment even for general-purpose applications, you are kindly requested to take into consideration securing
protection circuit/device or providing backup circuits in your equipment.
001-01 / 20130723 / e9a15_zcat.fm
(3/13)
E M C
C o m p o n e n t s
Product compatible with RoHS directive
Halogen-free
Clamp Filters (Ferrite Core with Case)
For cable
Overview of the ZCAT Series
FEATURES
Using TDK's unique structure where the ferrite core is mounted and integrated in a plastic case, it is possible to attach them to interface
cables and power cables with one touch without having to cut the cables.
Have excellent absorption of high-frequency noise using the high-frequency absorption characteristics of the ferrite core.
Effective for common mode noise, so can be implemented as a noise countermeasure without influencing signal quality.
Series are according to the outer diameter of the cable in order to be compatible with various cable sizes.
APPLICATION
PCs, word processors, monitors, HDDs, digital telephones, audio equipment, electronic musical instruments, video games, copiers, and
facsimiles
PART NUMBER CONSTRUCTION
ZCAT
Series
name
24
Outer
dimensions
(mm)
36
Length
dimensions
(mm)
-
13
Inner
dimensions
(mm)
30
Core
material
code
A
B
D
DT
Non code
A
Fixing type code
Fixed cable type
(Cable is clamped inside the main body)
Chassis fixed type
Flat cable type
Flat cable type
(Double-sided tape fixed type)
Band fixed type
(Cable is secured to the main body by a nylon band)
BK
Outer color
code
BK
Black
Non code
Gray
OPERATING TEMPERATURE RANGE, PACKAGE QUANTITY, PRODUCT WEIGHT
Temperature range
Operating
Storage condition after
Type
temperature
engagement
（°C）
（°C）
ZCAT3035
–40 to +85
–40 to +85
ZCAT2017-B
–40 to +85
–40 to +85
ZCAT2235
–40 to +85
–40 to +85
ZCAT2436
–40 to +85
–40 to +85
ZCAT2032
–40 to +85
–40 to +85
ZCAT2035
–40 to +85
–40 to +85
ZCAT2132
–40 to +85
–40 to +85
ZCAT1730
–40 to +85
–40 to +85
ZCAT2017
–40 to +85
–40 to +85
ZCAT1325
–40 to +85
–40 to +85
ZCAT1518
–40 to +85
–40 to +85
ZCAT3618-D
–40 to +85
–40 to +85
ZCAT4625-D
–40 to +85
–40 to +85
ZCAT6819-D
–40 to +85
–40 to +85
ZCAT10D
–40 to +85
–40 to +85
ZCAT13D
–40 to +85
–40 to +85
ZCAT20D
–40 to +85
–40 to +85
Operating temperature range includes self-temperature rise.
Temperature range for
engagement work
（°C）
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
0 to +50
Package quantity
（pieces/box）
200
350
400
400
420
480
480
840
640
1,344
896
480
240
160
770
450
280
Individual weight
（g）
64.8
11.5
26.0
29.0
22.7
21.2
21.6
11.6
11.0
6.37
6.1
15.6
32.5
58.4
5.6
14.8
46.3
RoHS Directive Compliant Product: See the following for more details related to RoHS Directive compliant products. http://www.tdk.co.jp/rohs/
Halogen-free: Indicates that Cl content is less than 900ppm, Br content is less than 900ppm, and that the total Cl and Br content is less than 1500ppm.
• All specifications are subject to change without notice.
001-01 / 20130723 / e9a15_zcat.fm
