1.5SMC75CABKTIN/LEAD datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> 1.5SMC75CABKTIN/LEAD

1.5SMC75CABKTIN/LEAD: DescriptionTrans Voltage Suppressor Diode, 64.1V V(RWM), Bidirectional,; CategoryDiscrete semiconductor diode; File Size878KB，3 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

1.5SMC75CABKTIN/LEAD Overview

Trans Voltage Suppressor Diode, 64.1V V(RWM), Bidirectional,

1.5SMC75CABKTIN/LEAD Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
ECCN code	EAR99
Breakdown voltage nominal value	75 V
Maximum clamping voltage	103 V
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
polarity	BIDIRECTIONAL
Maximum repetitive peak reverse voltage	64.1 V
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

1.5SMC6.8CA

THRU

1.5SMC220CA

SURFACE MOUNT SILICON

BI-DIRECTIONAL

GLASS PASSIVATED JUNCTION

TRANSIENT VOLTAGE SUPPRESSORS

1500 WATT, 6.8 THRU 220 VOLT

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR 1.5SMC6.8CA

series devices are surface mount bi-directional glass

passivated junction Transient Voltage Suppressors

designed to protect voltage sensitive components from

high voltage transients.

THIS DEVICE IS MANUFACTURED WITH A GLASS

PASSIVATED CHIP FOR OPTIMUM RELIABILITY.

Note: For uni-directional devices, please refer to the

1.5SMC6.8A series data sheet.

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SMC CASE

• This series is UL listed, UL file number E130224

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Peak Power Dissipation (Note 1)

Operating and Storage Junction Temperature

SYMBOL

PPK

TJ, Tstg

1500

-65 to +150

UNITS

°C

ELECTRICAL CHARACTERISTICS:

(TA=25°C unless otherwise noted)

BREAKDOWN

VOLTAGE

TYPE

MIN

1.5SMC6.8CA

1.5SMC7.5CA

1.5SMC8.2CA

1.5SMC9.1CA

1.5SMC10CA

1.5SMC11CA

1.5SMC12CA

1.5SMC13CA

1.5SMC15CA

1.5SMC16CA

1.5SMC18CA

1.5SMC20CA

1.5SMC22CA

1.5SMC24CA

1.5SMC27CA

1.5SMC30CA

1.5SMC33CA

1.5SMC36CA

1.5SMC39CA

6.45

7.13

7.79

8.65

9.5

10.5

11.4

12.4

14.3

15.2

17.1

19.0

20.9

22.8

25.7

28.5

31.4

34.2

37.1

VBR @ IT

NOM

6.8

7.5

8.2

9.1

MAX

7.14

7.88

8.61

9.55

10.5

11.6

12.6

13.7

15.8

16.8

18.9

21.0

23.1

25.2

28.4

31.5

34.7

37.8

WORKING

TEST

PEAK

CURRENT REVERSE

VOLTAGE

VRWM

1.0

5.8

6.4

7.02

7.78

8.55

9.4

10.2

11.1

12.8

13.6

15.3

17.1

18.8

20.5

23.1

25.6

28.2

30.8

33.3

MAXIMUM

REVERSE

LEAKAGE

CURRENT

IR @ VRWM

μA

2000

1000

400

100

5.0

MAXIMUM

CLAMPING

VOLTAGE

VC @ IPP

10.5

11.3

12.1

13.4

14.5

15.6

16.7

18.2

21.2

22.5

25.2

27.7

30.6

33.2

37.5

41.4

45.7

49.9

53.9

PEAK

PULSE

CURRENT

(Note 1)

IPP

143

132

124

112

103

59.5

MAXIMUM

TEMPERATURE

COEFFICIENT

ΘV

% / °C

0.057

0.061

0.065

0.068

0.073

0.075

0.078

0.081

0.084

0.086

0.088

0.090

0.092

0.094

0.096

0.097

0.098

0.099

0.100

C6V8C

C7V5C

C8V2C

C9V1C

C10C

C11C

C12C

C13C

C15C

C16C

C18C

C20C

C22C

C24C

C27C

C30C

C33C

C36C

C39C

MARKING

CODE

Notes: (1) Non-repetitive 10x1,000μs pulse.
