HY62256A-(I) Series
32Kx8bit CMOS SRAM
Description
Features
The
Fully static operation and
HY62256A/HY62256A-I
Tri-state outputs
is a high-speed, low
TTL compatible inputs
power and 32,786 x 8-bits
and outputs
CMOS Static Random
Low power consumption
Access Memory
-2.0V(min.) data
fabricated using
retention
Hyundai's high
Standard pin
performance CMOS
configuration
process technology. The
-28 pin 600 mil PDIP
HY62256A/HY62256A-I
-28 pin 330 mil SOP
has a data retention mode
-28 pin 8x13.4 mm
that guarantees data to
TSOP-1
remain valid at the
(standard and reversed)
minimum power supply
voltage of 2.0 volt. Using
the CMOS technology,
supply voltages from 2.0
to 5.5 volt has little effect
on supply current in the
data retention mode. The
HY62256A/HY62256A-I
is suitable for use in low
voltage operation and
battery back-up
application.
·
·
·
·
1 of 2
22/10/97 12:30
Data Sheet-sram/62256ald1
http://www.hea.com/hean2/sram/62256ald1.htm
Voltage Speed
Product No.
(V)
(ns)
HY62256A
5.0
Standby
Operation Current(uA) Temperature
Current(mA)
(°C)
L LL
1mA 100 25 0-70(Normal)
1mA 100 -
-40-85(E.T.)
55/70/85 50
55/70/85 50
HY62256A-I 5.0
Note
1. E T. Extended Temperature, Normal: Normal Temperature
2. Current value is max.
Features
|
Pins
|
Ratings
|
Timing
|
Package
|
Ordering
3101 North First Street, San Jose, CA 95134
Phone: 408-232-8000 URL:
http://www.hea.com/
SRAM Data Sheets
|
Memory Products
|
email: DRAMSRAMmemory@hea.com
Copyright © 1997 Hyundai Electronics America.
2 of 2
22/10/97 12:30
-sram/62256alp1
http://www.hea.com/hean2/sram/62256alp1.htm
HYUNDAI ELECTRONICS AMERICA
HY62256A-(I) Series
32Kx8bit CMOS SRAM
PIN CONNECTION
PIN INFORMATION
BLOCK DIAGRAM
PIN DESCRIPTION
Pin Name
/CS
/WE
/OE
A0-A14
I/O1-I/O8
Vcc
Vss
Chip Select
Write Enable
Output Enable
Address Inputs
Data Input/Output
Power(+5.0V)
Ground
Features
|
Pins
|
Ratings
|
Timing
|
Package
|
Ordering
1 of 2
Pin Function
3101 North First Street, San Jose, CA 95134
22/10/97 12:32
-sram/62256alp1
http://www.hea.com/hean2/sram/62256alp1.htm
Phone: 408-232-8000 URL:
http://www.hea.com/
SRAM Data Sheets
|
Memory Products
|
email: DRAMSRAMmemory@hea.com
Copyright © 1997 Hyundai Electronics America.
2 of 2
22/10/97 12:32
-sram/62256ala1
http://www.hea.com/hean2/sram/62256ala1.htm
HYUNDAI ELECTRONICS AMERICA
HY62256A-(I) Series
32Kx8bit CMOS SRAM
ABSOLUTE MAXIMUM RATING (1)
Symbol
V
CC
V
IN
V
OUT
T
A
T
STG
P
D
I
OUT
T
SOLDER
Note
Parameter
RATINGS INFORMATION
Rating
Unit
Remark
Power Supply Input/Output
-0.5 to 7.0 V
Voltage
Operating Temperature
Storage Temperature
Power Dissipation
Data OutPut Current
0 to 70
-40 to 85
1.0
50
°C
°C
W
mA
°C / sec
HY62256A
HY62256A-I
-65 to 150 °C
Lead Soldering Temperature
260 /10
& Time
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS
may cause permanent damage to the device. This is stress rating only and the
functional operation of the device under these or any other conditions above
those indicated in the operation of this specification is not implied. Exposure to
the absolute maximum rating conditions for extended period may affect
reliability.
RECOMMENDED DC OPERATING CONDITIONS
T
A
=0°C to 70°C / T
A
= -40°C to 85°C (E.T.)
Symbol
V
CC
V
IH
V
IL
Parameter
Power Supply Voltage
Input High Voltage
Input Low Voltage
Min
4.5
2.2
-0.5
(1)
-
-
Typ
5.0
5.5
V
CC
+0.5
0.8
Max
Unit
V
V
V
Note
1. V
IL
= -3.0V for pulse width less than 30ns
1 of 4
22/10/97 12:33
