Liquid Tight Flexible Conduit, Tubing & Fittings
Heyco Nylon Conduit Fittings
®
Flexilok
For Flexible, Corrugated Nylon Conduit/Tubing
FITS
CONDUIT
SIZE
PART NO.
Black
DESCRIPTION
THREAD
SIZE
PART DIMENSIONS
A
B
C
D
Thread
Max
Max O.A. Clearance
Length Diameter Length
Hole
in. mm. in. mm. in. mm. in. mm.
.39
.39
.39
.39
.39
.43
.39
.43
.47
.47
.45
.45
.55
.55
.55
.59
.59
.63
10,0
10,0
10,0
10,0
10,0
11,0
10,0
11,0
12,0
12,0
11,5
11,5
14,0
14,0
14,0
15,0
15,0
16,0
.80
.90
.80
.90
.90
1.12
.90
1.12
1.43
1.69
.80
.90
.80
.90
1.12
1.28
1.43
1.69
20,4
22,9
20,4
22,9
22,9
28,5
22,9
28,5
36,3
43,0
20,4
22,9
20,4
22,9
28,5
32,6
36,3
43,0
1.59
1.65
1.59
1.65
1.65
1.76
1.71
1.81
1.99
2.11
1.65
1.72
1.75
1.81
1.92
2.06
2.12
2.26
40,5
42,0
40,5
42,0
42,0
44,6
43,4
46,0
50,6
53,6
42,0
43,6
44,5
46,0
48,7
52,3
53,8
57,5
.60
.73
.60
.73
.80
.89
.80
.89
1.12
1.47
15,2
18,5
15,2
18,5
20,3
22,6
20,3
22,6
28,5
37,3
PG Hubs
13 mm
16 mm
13 mm
16 mm
16 mm
21 mm
16 mm
21 mm
28 mm
34 mm
F8772
F8774
F8776
F8778
F8780
F8782
F8784
F8786
F8788
F8790
F8802
F8804
F8806
F8808
F8812
F8814
F8816
F8818
PG9 13mm FLK13-PG9
PG9 16mm FLK16-PG9
PG11 13mm FLK13-PG11
PG11 16mm FLK16-PG11
PG13 16mm FLK16-PG13
PG13 21mm FLK21-PG13
PG16 16mm FLK16-PG16
PG16 21mm FLK21-PG16
PG21 28mm FLK28-PG21
PG29 34mm FLK34-PG29
M16 13mm FLKN13-M16
M16 16mm FLKN16-M16
M20 13mm FLKN13-M20
M20 16mm FLKN16-M20
M20 21mm FLKN21-M20
M25 25mm FLKN25-M25
M25 28mm FLKN28-M25
M32 34mm FLKN34-M32
PG9
PG9
PG11
PG11
PG13,5
PG13,5
PG16
PG16
PG21
PG29
M16 x 1,5
M16 x 1,5
M20 x 1,5
M20 x 1,5
M20 x 1,5
M25 x 1,5
M25 x 1,5
M32 x 1,5
Metric Hubs
13 mm
16 mm
13 mm
16 mm
21 mm
25 mm
28 mm
34 mm
.63 16,0
.79 20,1
.63 16,0
.79 20,1
.99 25,2
1.26 32,0
•
One piece fast fit allows for
quick installation.
•
Slim-line design is a space saver.
•
No threading of the conduit/tubing is
required to install.
•
For use with Heyco Nylon Corrugated
Conduit/Tubing. See pages 2-19 and 2-20.
•
Low fire hazard. Halogen, sulfur, and
phosphorus free.
•
IP 66 rating–protection against dust
and water penetration.
•
Suitable for use with both coarse
and/or fine pitch conduit/tubing.
•
All nylon construction resists salt
water, weak acids, gasoline, alcohol,
oil, grease, and common solvents.
(This feature is not assessed by UL
certification or testing.)
•
UV Resistant.
Material
Certifications
Temperature Rating
IP Rating
Nylon 6/6
Approved as per EN61386
-58°F (-50°C) to 275°F (135°C)
IP 66
Quick
Specs
2-22
