Printed-circuit board connector - ZEC 1,5/ 4-ST-7,5 C1 R1,4
BDAU - 1757044
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Direct connector, Nominal current: 10 A, Number of positions: 4, Pitch: 7.5 mm, Connection method: Spring-
cage connection, Color: green, Contact surface: Gold, Mounting: Direct plug-in method
Why buy this product
Gold-plated contacts ensure transfer quality remains stable over the long term
Defined contact force ensures that contact remains stable over the long term
Inexpensive direct plug-in connection with just one component
Clamping space opened by means of fixed screwdriver enables convenient conductor connection
Plug-in direction parallel to the PCB
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4046356339780
85366990
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Pitch
Dimension a
7.50 mm
22.5 mm
General
Range of articles
Type of contact
Number of positions
Connection method
Rated voltage (III/3)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
ZEC 1,5/..-ST
Female connector
4
Spring-cage connection
400 V
EN-VDE
10 A
1.5 mm²
Connection data
11/14/2016 Page 1 / 2
https://www.phoenixcontact.com/hq/products/1757044
Printed-circuit board connector - ZEC 1,5/ 4-ST-7,5 C1 R1,4
BDAU - 1757044
Technical data
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
0.2 mm²
1.5 mm²
0.2 mm²
1.5 mm²
0.25 mm²
0.25 mm²
1.5 mm²
24
16
0.5 mm²
0.5 mm²
Conductor cross section flexible, with ferrule without plastic sleeve max. 1.5 mm²
Standards and Regulations
Connection in acc. with standard
EN-VDE
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Approvals
Approvals
Approvals
EAC
Ex Approvals
Approval details
EAC B.01742
