TM3
www.vishay.com
Vishay Sprague
Solid Tantalum Surface Mount Chip Capacitors
T
ANTAMOUNT
™, Molded Case, for Medical Instruments
FEATURES
•
For non-life support medical applications
• High reliability
• Weibull grading options
• DC leakage at 0.005 CV
• 100 % surge current tested (B, C, D, E cases)
• Terminations: 100 % matte tin and tin / lead
• Standard EIA 535BAAC case sizes (A through E)
Available
Available
Available
PERFORMANCE / ELECTRICAL
CHARACTERISTICS
www.vishay.com/doc?40209
Operating Temperature:
-55 °C to +125 °C
(above 85 °C, voltage derating is required)
Capacitance Range:
1 μF to 220 μF
Capacitance Tolerance:
± 10 %, ± 20 % standard
Voltage Rating:
4 V
DC
to 20 V
DC
• Manufacturing location is certified to medical standard
ISO 13485
• Compliant terminations
• Dry pack as per IPC / JEDEC
®
J-STD-033 standard
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
ORDERING INFORMATION
TM3
TYPE
C
CASE
CODE
See
Ratings
and Case
Codes
table.
226
CAPACITANCE
This is
expressed
in picofarads.
The first two
digits are
the significant
figures.
The third is the
number of
zeros to follow.
K
CAPACITANCE
TOLERANCE
K = ± 10 %
M = ± 20 %
6R3
DC VOLTAGE
RATING AT +85 °C
This is expressed
in volts. To
complete the
three-digit block,
zeros precede
the voltage rating.
A decimal point is
indicated by an “R”
(6R3 = 6.3 V).
C
TERMINATION
AND PACKAGING
Matte tin
C
= 7" (178 mm) reel
H
= 7" (178 mm) ½ reel
V
= 7" (178 mm) reel,
dry pack
Tin / lead
E
= 7" (178 mm) reel
L
= 7" (178 mm) ½ reel
T
= 7" (178 mm) reel,
dry pack
B
RELIABILITY
LEVEL
B = 0.1 %
Weibull FRL
S = hi-rel std.
(40 h burn-in)
Z = non-
established
reliability
A
SURGE
CURRENT
A = 10 cycles at
+25 °C, 1.1 RV
Z = no surge
(for A case only)
Note
• Dry pack as specified in J-STD-033 for MSL3. Applicable for D and E cases only
Revision: 22-Jun-17
Document Number: 40166
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM3
www.vishay.com
Vishay Sprague
DIMENSIONS
in inches (millimeters)
L
W
T
H
(MIN.)
Glue
Pad
H
Glue
Pad
P
T
W
CASE CODE
A
B
C
D
E
EIA SIZE
3216-18
3528-21
6032-28
7343-31
7343-43
L
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
W
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.169 ± 0.012
[4.3 ± 0.30]
0.169 ± 0.012
[4.3 ± 0.30
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
0.157 ± 0.012
[4.0 ± 0.30]
P
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
T
W
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.094 ± 0.004
[2.4 ± 0.10]
0.094 ± 0.004
[2.4 ± 0.10]
T
H
(MIN.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
0.039
[1.0]
Note
• Glue pad (non-conductive, part of molded case) is dedicated for glue attachment (as user option)
RATINGS AND CASE CODES
μF
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
4V
6.3 V
10 V
A
A
A
A/B
B
A/B
B/C
B/C
B/C/D
C/D
D
D
E
16 V
A
A
A/B
A/B
A/B
B
B/C
B/C
B/C/D
D
C/D
D
D/E
20 V
A
A
B
A/B
A/B/C
B
B/C/D
D
D
D
D/E
B
B
C
B/C
C
C/D
D
E
B
D
D
D/E
MARKING
“A” CASE VOLTAGE CODE
Indicates TM3
series
Capacitance code, pF
Date code
designation
VOLTS
4.0
6.3
10
16
20
25
35
50
CODE
G
J
A
C
D
E
V
T
Polarity
band (+)
Indicates TM3
series
Capacitance μF
Voltage
J 225M
22
XX
M10
2
Vishay marking
Polarity band (+)
A Case
Voltage code
Date code
B, C, D, E Cases
Marking
Capacitor marking includes an anode (+) polarity band, capacitance in microfarads and the voltage rating. “A” case capacitors use a letter
code for the voltage and EIA capacitance code.
The Vishay identification is included if space permits. Capacitors rated at 6.3 V are marked 6 V.
A manufacturing date code is marked on all capacitors, for details see FAQ:
www.vishay.com/doc?40110.
Call the factory for further explanation.
Revision: 22-Jun-17
Document Number: 40166
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM3
www.vishay.com
Vishay Sprague
MAX. DF
AT +25 °C
120 Hz
(%)
6
6
8
8
8
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
8
8
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
MAX. ESR
AT +25 °C
100 kHz
(Ω)
1.90
0.70
0.60
0.60
0.50
7.60
6.30
3.40
3.40
2.90
2.90
2.00
1.80
1.90
1.90
1.40
0.80
0.70
0.14
0.60
0.60
0.50
8.00
6.30
5.50
5.00
3.40
2.90
3.40
2.50
2.00
1.80
1.90
0.35
1.90
1.40
0.80
1.10
0.70
0.70
0.60
0.50
MAX. RIPPLE
100 kHz
I
RMS
(A)
0.21
0.46
0.50
0.50
0.57
0.10
0.11
0.16
0.15
0.17
0.16
0.21
0.25
0.21
0.21
0.28
0.43
0.46
1.04
0.50
0.50
0.57
0.10
0.11
0.12
0.12
0.16
0.17
0.15
0.18
0.21
0.25
0.21
0.56
0.21
0.28
0.43
0.32
0.46
0.46
0.50
0.57
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
4 V
DC
AT +85 °C; 2.7 V
DC
AT +125 °C
68
100
150
220
220
2.2
3.3
6.8
10
10
22
22
22
33
47
47
47
68
100
150
220
220
1.5
2.2
3.3
4.7
4.7
6.8
10
10
15
15
22
22
33
33
33
47
47
68
100
220
B
D
D
D
E
A
A
B
A
B
A
B
C
B
B
C
D
D
D
D
D
E
A
A
A
A
B
B
A
B
B
C
B
C
B
C
D
C
D
D
D
E
TM3B686(1)004(2)(3)A
TM3D107(1)004(4)(3)A
TM3D157(1)004(4)(3)A
TM3D227(1)004(4)(3)A
TM3E227(1)004(4)(3)A
TM3A225(1)6R3(2)(3)Z
TM3A335(1)6R3(2)(3)Z
TM3B685(1)6R3(2)(3)A
TM3A106(1)6R3(2)(3)Z
TM3B106(1)6R3(2)(3)A
TM3A226(1)6R3(2)(3)Z
TM3B226(1)6R3(2)(3)A
TM3C226(1)6R3(2)(3)A
TM3B336(1)6R3(2)(3)A
TM3B476(1)6R3(2)(3)A
TM3C476(1)6R3(2)(3)A
TM3D476(1)6R3(4)(3)A
TM3D686(1)6R3(4)(3)A
TM3D107(1)6R3(4)(3)A
TM3D157(1)6R3(4)(3)A
TM3D227(1)6R3(4)(3)A
TM3E227(1)6R3(4)(3)A
TM3A155(1)010(2)(3)Z
TM3A225(1)010(2)(3)Z
TM3A335(1)010(2)(3)Z
TM3A475(1)010(2)(3)Z
TM3B475(1)010(2)(3)A
TM3B685(1)010(2)(3)A
TM3A106(1)010(2)(3)Z
TM3B106(1)010(2)(3)A
TM3B156(1)010(2)(3)A
TM3C156(1)010(2)(3)A
TM3B226(1)010(2)(3)A
TM3C226(1)010(2)(3)A
TM3B336(1)010(2)(3)A
TM3C336(1)010(2)(3)A
TM3D336(1)010(4)(3)A
TM3C476(1)010(2)(3)A
TM3D476(1)010(4)(3)A
TM3D686(1)010(4)(3)A
TM3D107(1)010(4)(3)A
TM3E227(1)010(4)(3)A
1.36
2.00
3.00
4.40
4.40
0.25
0.25
0.25
0.32
0.30
0.66
0.69
0.66
0.99
1.41
1.41
1.41
2.04
3.00
4.50
6.60
6.60
0.25
0.25
0.25
0.25
0.25
0.34
0.50
0.50
0.75
0.75
1.10
1.10
1.65
1.65
1.65
2.35
2.35
3.40
5.00
11.00
6.3 V
DC
AT +85 °C; 4 V
DC
AT +125 °C
10 V
DC
AT +85 °C; 7 V
DC
AT +125 °C
Note
• Part number definitions:
(1) Capacitance tolerance: K, M
(2) Termination and packaging: C, E, H, L
(3) Reliability level: B, S, Z
(4) Termination and packaging: C, E, H, L, V, T
Revision: 22-Jun-17
Document Number: 40166
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM3
www.vishay.com
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
120 Hz
(%)
4
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
8
8
6
6
6
6
6
6
6
6
6
6
MAX. ESR
AT +25 °C
100 kHz
(Ω)
9.30
6.70
4.00
4.60
3.50
3.50
5.00
2.90
2.50
2.00
1.80
2.00
0.40
1.90
1.40
0.80
0.70
1.00
0.70
0.60
0.60
0.60
3.50
3.00
2.30
2.50
1.90
1.70
1.10
0.70
0.70
0.60
MAX. RIPPLE
100 kHz
I
RMS
(A)
0.09
0.11
11.00
0.14
0.15
0.16
0.12
0.17
0.18
0.21
0.25
0.21
0.52
0.21
0.28
0.43
0.46
0.33
0.46
0.50
0.50
0.52
0.16
0.17
0.22
0.18
0.24
0.25
0.32
0.46
0.46
0.52
Vishay Sprague
16 V
DC
AT +85 °C; 10 V
DC
AT +125 °C
1.0
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
10
10
15
15
22
22
22
33
47
47
68
100
100
2.2
3.3
4.7
6.8
6.8
10
22
22
33
47
A
A
A
B
A
B
A
B
B
B
C
B
C
B
C
D
D
C
D
D
D
E
B
B
C
B
C
C
C
D
D
E
TM3A105(1)016(2)(3)Z
TM3A155(1)016(2)(3)Z
TM3A225(1)016(2)(3)Z
TM3B225(1)016(2)(3)A
TM3A335(1)016(2)(3)Z
TM3B335(1)016(2)(3)A
TM3A475(1)016(2)(3)Z
TM3B475(1)016(2)(3)A
TM3B685(1)016(2)(3)A
TM3B106(1)016(2)(3)A
TM3C106(1)016(2)(3)A
TM3B156(1)016(2)(3)A
TM3C156(1)016(2)(3)A
TM3B226(1)016(2)(3)A
TM3C226(1)016(2)(3)A
TM3D226(1)016(4)(3)A
TM3D336(1)016(4)(3)A
TM3C476(1)016(2)(3)A
TM3D476(1)016(4)(3)A
TM3D686(1)016(4)(3)A
TM3D107(1)016(4)(3)A
TM3E107(1)016(4)(3)A
TM3B225(1)020(2)(3)A
TM3B335(1)020(2)(3)A
TM3C475(1)020(2)(3)A
TM3B685(1)020(2)(3)A
TM3C685(1)020(2)(3)A
TM3C106(1)020(2)(3)A
TM3C226(1)020(2)(3)A
TM3D226(1)020(4)(3)A
TM3D336(1)020(4)(3)A
TM3E476(1)020(4)(3)A
0.25
0.25
0.25
0.25
0.26
0.26
0.38
0.38
0.54
0.80
0.80
1.20
1.20
1.76
1.76
1.76
2.64
3.76
3.76
5.44
8.00
8.00
0.25
0.33
0.47
0.68
0.68
1.00
2.20
2.20
3.30
4.70
20 V
DC
AT +85 °C; 13 V
DC
AT +125 °C
Note
• Part number definitions:
(1) Capacitance tolerance: K, M
(2) Termination and packaging: C, E, H, L
(3) Reliability level: B, S, Z
(4) Termination and packaging: C, E, H, L, V, T
Revision: 22-Jun-17
Document Number: 40166
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TM3
www.vishay.com
Vishay Sprague
POWER DISSIPATION
CASE CODE
A
B
C
D
E
MAXIMUM PERMISSIBLE POWER DISSIPATION AT +25 °C (W) IN FREE AIR
0.075
0.085
0.110
0.150
0.165
STANDARD PACKAGING QUANTITY
CASE CODE
A
B
C
D
E
UNITS PER REEL
7" FULL REEL
2000
2000
500
500
400
7" HALF REEL
1000
1000
250
250
200
PRODUCT INFORMATION
Guide for Molded Tantalum Capacitors
Pad Dimensions
Packaging Dimensions
Moisture Sensitivity
SELECTOR GUIDES
Solid Tantalum Selector Guide
Solid Tantalum Chip Capacitors
FAQ
Frequently Asked Questions
www.vishay.com/doc?40110
www.vishay.com/doc?49053
www.vishay.com/doc?40091
www.vishay.com/doc?40135
www.vishay.com/doc?40074
Revision: 22-Jun-17
Document Number: 40166
5
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
MCU
京公网安备 11010802033920号
EEWORLD
