Electrical / Environmental
ISDN Isolation Transformers
• Insulation Resistance, 100 Mohms minimum
• Isolation voltage levels available for domestic and international
safety standard
• Standard Operating Temperature Range
0°C to +85°C
Specifications
BI P/N
RoHS
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
HM80-10001
HM80-20014
HM80-30008
HM80-40010
HM80-50004
HM80-60002
HM80-70004
HM80-80005
HM80-90009
HM80-10011
HM80-11004
HM80-12007
HM80-13006
HM80-14003
HM80-15013
HM80-16012
HM80-17006
HM80-18007
Notes:
Interface
S/T
S/T
U
U
S/T
S/T
S/T
S/T
S/T
S/T
S/T
S/T
U
U
U
U
U
U
Turns Ratio
1CT:1CT
1CT:1.32CT
1.5CS
0.6CS
1CT:1.8CT
1CS:2CS
1CT:2CT
1CT:2CT
1CS:2
1CT:2CT
1CT:2.5CT
1.25:1CS
1.32CS:1
1.5CS:1CS
1.6CS:1CS
2CS:1CT
1.6CS:1
1.25CS:1CT
Lp (mH)
22
7
12.3
2.7
22
22
20
20
11.5
22
22
72
7.9
27
13.3
22.5
14.5
27.8
Packaging
Style
8-pin TH/EP-10
10-pin TH/DS-23/11
10-pin TH/DS-23/11
10-pin SMD/ER-11/5
6-pin TH/RM-6
10-pin TH/EP-13
6-pin TH/RM-6
8-pin TH/RM-6
10-pin TH/EF-20
10-pin SMD/ER-14.5/6
6-pin TH/RM-6
10-pin TH/10-pin TH/DS 23/11
8-pin TH/RM-8
8-pin TH/EP-17
8-pin TH/RM-6
8-pin TH/RM-8
8-pin TH/RM-8
10-pin TH/DS-23/11
Hi-Pot
(Vrms)
1500
1100
1100
500
1500
1500
1500
1500
2000
1500
1500
1100
2000
2000
2000
1100
2000
2000
(1) Add a “LF” suffix to the Part Number for RoHS compliant parts
(2) Contact BI Technologies for RoHS compliant part availability.
