Electrical / Environmental
oH
li
S
nt
R
mp a
Co
High Current Toroidal Inductors
• Operating Temperature Range
• Temperature Rise, Maximum
• Insulation System
-40°C to +155°C
50°C
Class F, 155°C
Specifications
Inductance
100 kHz, 0.1 V
@ 0 Adc
@ I
sat
µH
±10%
µH Typ.
0.42
0.42
0.41
0.41
0.51
0.51
0.60
0.60
0.86
0.86
0.86
0.86
0.38
0.38
0.35
0.35
0.42
0.42
0.50
0.50
0.61
0.61
0.71
0.71
Part
Number
HM54-44R42VLF
HM54-44R42HLF
HM54-45R41VLF
HM54-45R41HLF
HM54-5BR51VLF
HM54-5BR51HLF
HM54-50R60VLF
HM54-50R60HLF
HM54-50R86VLF
HM54-50R86HLF
HM54-60R86VLF
HM54-60R86HLF
Notes:
Heating
(1)
I
sat (2)
Current
(Adc)
(Adc)
32
32
33
33
32
32
31
31
27
27
35
35
32
32
33
33
42
42
32
32
27
27
41
41
DCR
(3)
m
Ω
Max.
1.15
1.15
0.70
0.70
0.75
0.75
1.1
1.1
1.6
1.6
1.1
1.1
Dim. A
(Inch/mm)
.099/2.5
.099/2.5
.099/2.5
.099/2.5
.126/3.2
.126/3.2
.114/2.9
.114/2.9
.099/2.5
.099/2.5
.126/3.2
.126/3.2
Dim. P
(Inch/mm)
.284/7.2
.228/5.8
.335/8.5
.256/6.5
.386/9.8
.284/7.2
.370/9.4
.322/8.2
.370/9.4
.322/8.2
.386/9.8
.362/9.2
Fig.
1
2
1
2
1
2
1
2
1
2
1
2
(1) The heating current is the DC current which causes the component temperature to increase by approximately 50°C.
This current is determined by soldering the component on a typical application PCB, and then apply the current to the component for 30 minutes.
(2) I
sat
is the saturation current at which inductance rolls off approximately 30% from its initial value.
(3) DC resistance is measured at 25°C.
Outline Dimensions (Inch/mm)
Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
.142±.020
3.6±0.5
P± .020
0.5
Body
Style
Vertical Mount
Horizontal Mount
Fig.
1
1
1
1
1
44
45
50
5B
60
L
.570
14.48
.610
15.50
.640
16.25
.690
17.53
.760
19.30
W
.260
6.61
.295
7.50
.300
7.61
.380
9.65
.360
9.14
Ht
.510
12.95
.510
12.95
.570
14.48
.590
14.98
.680
17.27
Fig.
2
2
2
2
2
L
.570
14.48
.610
15.50
.640
16.25
.690
17.53
.760
19.30
W
.570
14.48
.610
15.50
.640
16.25
.690
17.53
.760
19.30
Ht
.260
6.61
.295
7.50
.300
7.61
.380
9.65
.360
9.14
.142±.020
3.6±0.5
P± .020
0.5
Refer to Specifications table for ‘A’ & ‘P’ dimensions of each model.
28
MAGNETIC COMPONENTS SELECTOR GUIDE 2007/08 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
Electrical Characteristics @ 25°C
2007/08 EDITION MAGNETIC COMPONENTS SELECTOR GUIDE
www.bitechnologies.com
We reserve the right to change specifications without prior notice
29
Packaging
Standard:
Vacuum Tray
Body Style
44 Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
45 Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
50 Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
5B Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
60 Figure 1 (Vertical Mount)
Figure 2 (Horizontal Mount)
Capacity Per Tray
(Units)
50
40
50
40
40
40
44
50
30
50
Capacity Per Carton
(Units)
800
560
800
560
560
560
660
500
450
500
Ordering Information
Model Series
Body Style
HM54
44
R42
V
LF
Lead-Free
Inductance Code:
First 2 digits are significant. Last digit denotes
the number of trailing zeros. For values below
10µH, ”R” denotes the decimal point.
Mounting Style
V= Vertical Mounting
H= Horizontal Mounting
30
MAGNETIC COMPONENTS SELECTOR GUIDE 2007/08 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
