MWDL Low Profile Plastic Shell Micro-D
Insulated Wire Termination
MWDL connectors are supplied with stranded mil spec hookup wire. Contacts
are crimped to wire and potted with epoxy. Pin contacts are gold-plated high
performance TwistPin type and are recessed into insulator to prevent damage.
Socket contacts are gold plated, machined copper alloy. Glass-filled high
temperature thermoplastic connector body. M22759/11 standard wire, or
M22959/33 lightweight, high strength space grade wire. Meets performance
requirements of MIL-DTL-83513, Class P. Available with 9 to 51 contacts. 3 A., 600
Vac, -55°C to +150°C.
How To Order Stranded Wire Connector
Sample Part Number
Series
Contact Layout
Contact Type
Wire Gage (AWG)
MWDL
- Low Profile Plastic Shell Micro-D
9, 15, 21, 25, 31, 37, 51
(See Table II)
P
- Pin Contacts
S
- Socket Contacts
4
- #24
6
- #26
8
- #28
0
- #30 (See Table II)
K
- Standard Wire
Extruded PTFE per M22759/11, Silver-Plated Conductors (#30 AWG not available)
J
- Space Grade Wire
High Strength, Lightweight, Crosslinked Modified ETFE per M22759/33, Silver-Plated
Conductors
1
- White
5
- Color-Coded per MIL-STD-681.
7
- 10 Color Repeat Wires are solid color per MIL-STD-681 color code system.
18
= 18 inches
B, M, M1, S, S1, P
(See Table I)
MWDL
-37
P
-6
K
5
-18
M
Wire Type
Wire Color Code
Wire Length (Inches)
Mounting Hardware
Table I: Mounting Hardware
B
P
M
M1
S
S1
M
Thru-Hole
Jackpost
#2-56
Hex Head Jackscrew
#2-56
Hex Head
Jackscrew, Extended
#2-56
Slot Head Jackscrew
#2-56
Slot Head Jackscrew,
Extended
#2-56
Q
© 2013 Glenair, Inc.
High Performance Micro-D Connectors and Cables
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-17
E-Mail: sales@glenair.com
INDEX
Micro-D Double
and Triple Row
A
B
C
D
E
F
G
H
J
K
L
N
P
Micro-D Double
and Triple Row
MWDL Low Profile Plastic Shell Micro-D
Insulated Wire Termination
Table II: Dimensions
A
B
C
D
.096/.088 (2.43/2.23) DIA.
.100/.088
(2.54/2.24)
E
F
J
PIN CONNECTOR
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
INDEX
© 2013 Glenair, Inc.
Layout
9P
9S
15P
15S
21P
21S
25P
25S
31P
31S
37P
37S
51P
51S
J
D
SOCKET CONNECTOR
LENGTH + 1.0/-0.0
(+25.4/-0.0)
H
LENGTH + 1.0/-0.0
(+25.4/-0.0)
H
G
A Max.
In.
.788
.788
.938
.938
1.088
mm.
20.02
20.02
23.83
23.83
27.64
B
In .
mm.
± .003 ± 0.08
.565
.565
.715
.715
.865
14.35
14.35
18.16
18.16
21.97
C Max.
In.
.292
.380
.442
.530
.592
.680
.692
.780
.842
.930
.992
1.080
mm.
7.42
9.65
11.23
13.46
15.04
17.27
17.58
19.81
21.39
23.62
25.20
27.43
D Max.
In.
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.218
.260
.260
mm.
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
5.54
6.60
6.60
E Max.
In.
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
.202
.185
mm.
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
5.13
4.70
F Max.
In.
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
.395
.375
mm.
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
10.03
9.53
G Max.
In.
.408
.408
.558
.558
.708
.708
.808
.808
.958
.958
1.108
1.108
1.058
1.058
mm.
10.36
10.36
14.17
14.17
17.98
17.98
20.52
20.52
24.33
24.33
28.14
28.14
26.87
26.87
H Max.
In.
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.173
.220
.220
mm.
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
4.39
5.59
5.59
J Max.
In.
.134
.218
.134
.218
.134
.218
.134
.218
.134
.218
.134
.218
.177
.260
mm.
3.40
5.54
3.40
5.64
3.40
5.64
3.40
5.64
3.40
5.64
3.40
5.64
4.50
6.60
1.080 27.64
1.188 30.18
1.185 30.18
1.338 33.99
1.338
1.488
1.488
33.99
37.80
37.80
.865 21.97
.965 24.51
.965 24.51
1.115 28.32
1.115
1.265
1.265
28.32
32.13
32.13
1.438 36.53 1.215 30.86
1.438 36.53 1.215 30.86
.942 23.93
1.030 26.16
Performance Specifications
Current Rating
DWV
Insulation Resistance
Contact Resistance
Operating Temperature
Shock, Vibration
Mating Force
3 AMP
600 VAC Sea level
5000 Megohms Minimum
8 Milliohms Maximum
-55° C. to +150° C.
50 g., 20g.
(10 Ounces) X (# of Contacts)
Insulator
Pin Contact
Socket Contact
Hardware
Encapsulant
Materials and Finishes
Liquid Crystal Polymer (LCP)/
Polyphenylene Sulfide(PPS)
Beryllium Copper, Gold Over Nickel Plating
Copper Alloy, Gold Over Nickel Plating
300 Series Stainless Steel
Epoxy
