Technical specification:
42
Rated voltage:
IEC 61076-2-101
Current rating:
IEC 61076-2-101
4pos
250 V
5pos
60 V
7,5 A at 40°C, with 1,5mm²
n
20
Insulation resistance:
IEC 60512
Pollution degree:
IEC 60664-1
>=100 M
3/2
IP 67, in mated
condition
-30°C ... +85°C
>=100
max. AWG16 / max. 1,50 mm²
(incl. sleeve)
~28,5
Width across
flats 18
Degree of protection:
IEC 60529
Temperature range:
Mating cycles:
IEC 60512-9a
n
20
max. external cable
diameter see table
Wire cross section:
Materials:
A-coding
Contact:
Contact plating:
Contact carrier:
CuZn
Au over Ni
PA6, UL 94
Elastomere
FPM / NBR
GD-Zn, Ni plated
PA6 GF, UL 94
Housing in angled version
is mountable in 90° angular
degree positions
5
4
4pos / 5pos
Cable seal:
O-Ring:
Coupling nut:
1
Housing:
Installation specification:
Recommended
torque:
Conec
installation tooling:
0,6 Nm
Torque wrench:
36-000200
Insert across flats 18:
36-000240
3
2
Recommended torque,
screw termination
contact:
0,3 Nm
Part no:
43-00096
43-00098
DO NOT ALTER CAD DRAWING BY HAND
Description:
SAL - 12 - RKWC4 - S / 150
SAL - 12 - RKWC5 - S / 150
Pos:
4
5
Cable-
n
:
4 - 8 mm
4 - 8 mm
Directive 2002/95/EC RoHS compliant
Index: d 17.03.14 BS Ä5133
data sheet a. description modified
date
drawn
appd.
dim. in mm
name
title:
19.01.09
19.01.09
Burschik
Schmidt
R
Female connector M12x1,
field attachable, angled,
screw connection
43K1A835
dwg no:
general tolerance:
0
0,0
0,00
± 0,50mm
± 0,25mm
± 0,10mm
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED IN ANY WAY, AND
MAY NOT BE PASSED ON TO A THIRD PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
part no:
see table
