This document was generated on 05/21/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0366380004
Active
CMC and CMX Sealed, Hybrid, Modular Connectors
2.50mm, 3.50mm CMC Header, Right Angle, 48 Position, 1 Port, Black, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-36638-001-001 (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Physical
(p)ower-(s)ignal Configuration
Breakaway
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Capable
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Mated Height
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Electrical
Packaging Specification PK-36638-001 (PDF)
Packaging Specification PK-36638-003 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
PCB Headers
36638
Power, Wire-to-Board
Carton Box Packing
CMC and CMX Sealed, Hybrid, Modular Connectors
CMC
822350925983
8p - 40s
No
48
48
8 x 1.5mm & 40 x 0.635mm terminals
Black
20
Yes
No
Yes
Yes
No
6.70mm
Brass
Tin
Tin
Polyester
49.111/g
4
Right Angle
2.90mm
No
None
2.00mm
Carton
2.50mm, 3.50mm, 3.70mm
4.064µm
4.064µm
Yes
Yes
Closed Ends
No
No
-40°C to +100°C
Solder or Weld
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
36638 Series
Mates With
CMC Connectors 64320-1311 , 64320-3311
Use With
CMC Connectors 64320-1311 , 64320-3311
, CMC CP Terminals 64322 , 64323 , CMC
Blind Plug for CP Terminal 64325 , Wire Cap
64319-1201
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
6.0A
14V DC
N/A
PK-36638-001, PK-36638-003
PS-36638-001-001
SD-36638-002
