CRYSTAL CLOCK OSCILLATORS
Differential Positive ECL (DPECL)
Data Sheet 0447H
Rev. D
SK-B29B0 Series
Description
The
SK-B29B0 Series
of quartz crystal oscillators provide DPECL Fast Edge compatible signals. This
device is to operate using positive voltage and uses multiple ground pins for improved signal integrity. This
device is intended to operate on positive voltage for PECL applications.
Features
• Wide frequency range - 350.0MHz to 1.7GHz
• User specified tolerance available
• Case at electrical ground
• Will withstand SMD reflow temperatures of 253°C
for 4 minutes maximum
• All metal, resistance weld, hermetically sealed
package
• High shock resistance, to 1500g
Electrical Connection
Pin
1
2
6
7
8
9
13
14
Connection
V
CC
V
EE
Case
V
EE
Case
Output
/Output
V
EE
Case
V
EE
Case
Enable/Disable
• Low Jitter - Wavecrest jitter characterization
available
• High Reliability - NEL HALT/HASS qualified for
crystal oscillator start-up conditions
• High Q Crystal actively tuned oscillator circuit
• Power supply decoupling internal
• High frequencies due to proprietary design
• RoHS compliant, Lead-free construction
All other pins are
No Connect
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
SK-B29B0 Series
Continued
Differential Positive ECL (DPECL)
Operating Conditions and Output Characteristics
Electrical Characteristics
Parameter
Frequency
Duty Cycle
Logic 0
(1)
Logic 1
(1)
Rise & Fall Time
Jitter, RMS
(4)
Enable Voltage
(2)
Disable Voltage
Frequency Stability
(3)
Symbol
Conditions
Min
-----
-----
350.0MHz
-----
@ 50% points
45/55%
V
OL
-----
V
CC
-1.810V
V
OH
-----
V
CC
-1.025V
tr,tf 20-80%V
O
with 50 ohm load to V
CC
-2V -----
-----
-----
-----
----
with V
EE
=0V
0V
-----
with V
EE
=0V
2.0V
dF/F
Overall conditions including:
-100ppm
voltage, calibration, temp.,
10 yr aging, shock, vibration
Data Sheet 0447H
Rev. D
Typical
-----
-----
-----
-----
350 psec
0.3 psec
-----
-----
-----
Max
1.7GHz
55/45%
V
CC
-1.620V
V
CC
-0.880V
600 psec
0.5 psec
0.8V
V
CC
+100ppm
General Characteristics
Parameter
Supply Voltage
Supply Current
Symbol
V
CC
I
CC
Conditions
2.5V±5%
50 ohm termination
To 2.00V below V
CC
Low level Output Current
------
-----
Min
2.375V
0.0 mA
Typical
2.5V
-----
-----
-----
-----
-----
2 ms
Max
2.625V
160 mA
±50.0 mA
70°C
125°C
300°C
10 ms
Output current
I
O
0.0 mA
0°C
Operating temperature
T
A
Storage temperature
T
S
-55°C
Input: Logic High (ECL) - Disables
V
EE
or Open - Enables
Lead temperature
T
L
Soldering, 10 sec.
-----
Load
50 Ohm to V
CC
-2V or Thevenin Equivalent, Bias Required
-----
-----
Start-up time
t
S
Environmental and Mechanical Characteristics
Mechanical Shock
Thermal Shock
Vibration
Soldering Condition
Hermetic Seal
Per MIL-STD-202, Method 213, Condition E
Per MIL-STD-833, Method 1011, Condition A
0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz
300°C for 10 seconds
Leak rate less than 1 x 10
-8
atm.cc/sec of helium
Footnotes:
1) V
OL
, V
OH
, referenced to ground
2) Open to Enable pin also enables the output.
3) Standard frequency stability (others available)
4) Jitter performance is frequency dependent. Please contact factory for full Aeroflex characterization.
RMS jitter bandwidth of 12kHz to 20MHz.
Creating a Part Number
SK - B29BX - FREQ
Package Code
HK Leaded 8 pin (14 pin)
SK 8 pin (14 pin) SMD Gull
Wing
Input Voltage
Code Specification
A
3.3V
B
2.5V
Tolerance/Performance
0 ±100ppm 0-70°C
1 ±50ppm 0-70°C
7 ±25ppm 0-70°C
9 Customer Specific
A ±20ppm 0-70°C
B ±50ppm -40 to +85°C
C ±100ppm -40 to +85°C
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
