1704695 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> terminals> 1704695

1704695: DescriptionFixed Terminal Blocks TVFKCL 1,5/ 3- ST CP13BD:-A1 SO; CategoryThe connector terminals; File Size66KB，2 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com; Environmental Compliance

Download Datasheet Parametric View All

1704695 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1704695	-	-	View	Buy Now

1704695 Overview

Fixed Terminal Blocks TVFKCL 1,5/ 3- ST CP13BD:-A1 SO

1704695 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
Is Samacsys	N
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK
Base Number Matches	1

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1704695

TVFKCL 1,5/ 3-ST CP13BD:-A1 SO - 1704695

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Plug component, Nominal current: 10 A, Number of positions: 3, Pitch: 5 mm, Connection method: Push-in

spring connection, Color: green, Contact surface: Tin

Key Commercial Data

Packing unit

GTIN

Custom tariff number

Note

4046356733793

85366990

Made to Order (non-returnable)

50 STK

Technical data

Dimensions

Pitch

Dimension a

5.00 mm

10 mm

General

Range of articles

Type of contact

Number of positions

Connection method

Rated voltage (III/3)

Connection in acc. with standard

Nominal current I

Nominal cross section

TVFKC 1,5/..-ST

Female connector

Push-in spring connection

250 V

EN-VDE

10 A

1.5 mm²

Connection data

Conductor cross section solid min.

Conductor cross section solid max.

Conductor cross section flexible min.

Conductor cross section flexible max.

Conductor cross section flexible, with ferrule without plastic sleeve min.

Conductor cross section flexible, with ferrule with plastic sleeve min.

Conductor cross section flexible, with ferrule with plastic sleeve max.

0.2 mm²

1.5 mm²

0.2 mm²

1.5 mm²

0.25 mm²

1.5 mm²

11/14/2016 Page 1 / 2

Conductor cross section flexible, with ferrule without plastic sleeve max. 1.5 mm²
