AS85049/3 Style 1
Straight Environmental Backshell
Finish
X
= Nickel Fluorocarbon Polymer
Z
= Zinc Nickel
B
AS85049
CONNECTOR DESIGNATOR:
C
MIL-DTL-22992 Classes C, J and R
A
= Black Anodize
W
= Cadmium, Olive Drab
Y
= Pure Dense
Electrodeposited Aluminum
TABLE II: Cable Range
Dash
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
Shell
Size
12
12
14
16
16
16
18
18
18
18
20
20
22
22
22
24
24
24
24
28
28
28
32
32
32
36
36
44
44
Cable Range
Min
Max
.281 (7.1)
.188 (4.8)
.344 (8.7)
.511 (13.0)
.436 (11.1)
.311 (7.9)
.531 (13.5)
.605 (15.4)
.406 (10.3)
.361 (9.2)
.715 (18.2)
.449 (11.4)
.637 (16.2)
.787 (20.0)
.692 (17.6)
.930 (23.6)
.675 (17.1)
.984 (25.0)
.755 (19.2)
1.055 (26.8)
1.105 (28.1)
1.185 (30.1)
1.320 (33.5)
1.406 (35.7)
1.250 (31.8)
1.531 (38.9)
1.437 (36.5)
2.105 (53.5)
2.025 (51.4)
.375
.281
(9.5)
(7.1)
M85049/3
Basic
Part Number
W
10
A
Type
A
or
B
1
Style 1
.438 (11.1)
.605 (15.4)
.530 (13.5)
.405 (10.3)
.625 (15.9)
.699 (17.8)
.500 (12.7)
.455 (11.6)
.828 (21.0)
.562 (14.3)
.750 (19.1)
.900 (22.9)
.805 (20.4)
1.055 (26.8)
1.000 (25.4)
1.109 (28.2)
.880 (22.4)
1.180 (30.0)
1.230 (31.2)
1.310 (33.3)
1.455 (37.0)
1.531 (38.9)
1.375 (34.9)
1.656 (42.1)
1.562 (39.7)
2.250 (57.2)
2.170 (55.1)
Dash Number
(Table II)
TABLE I : Shell Size and Dimensions
Shell
Size
A Thread
Class 2B-LH
.7500 - 20 UNEF
B Dia
±.015 (0.4)
E
Max
G Dia
Max
H
Max
J Thread (Plated)
Class 2 (A or B)
APPLICATION NOTES
1.
2.
3.
For complete dimensions see the
applicable Military Specification.
Metric dimensions (mm) are in
parentheses.
Cable Range is defined as the
accommodation range for the wire
bundle or cable. Dimensions shown
are not intended for inspection
criteria.
Approximate chain lengths: Dash
No. 01-12 = 5.0 (127.0); Dash No.
13-29 = 6.0 (152.4).
12
14
16
18
20
22
24
28
32
36
44
.933 (23.7) 3.365 (85.5) 1.094 (27.8) .765 (19.4) 0.875-0.1P-0.2L-DS
.8750 - 20 UNEF 1.057 (26.8) 3.678 (93.4) 1.219 (31.0) .765 (19.4) 1.000-0.1P-0.2L-DS
1.0000 - 20 UNEF 1.183 (30.0) 4.177 (106.1) 1.344 (34.1) .980 (24.9) 1.125-0.1P-0.2L-DS
1.1250 - 18 UNEF 1.307 (33.2) 4.489 (114.0) 1.469 (37.3) .980 (24.9) 1.250-0.1P-0.2L-DS
1.2500 - 18 UNEF 1.433 (36.4) 4.615 (117.2) 1.562 (39.7) .980 (24.9) 1.375-0.1P-0.2L-DS
1.3750 - 18 UNEF 1.557 (39.5) 4.647 (118.0) 1.608 (40.8) .980 (24.9) 1.500-0.1P-0.2L-DS
1.6250 - 18 UNEF 1.807 (45.9) 4.896 (124.4) 1.938 (49.2) .980 (24.9) 1.750-0.1P-0.2L-DS
1.8750 - 16 UN 2.057 (52.2) 4.959 (126.0) 2.219 (56.4) .980 (24.9) 2.000-0.1P-0.2L-DS
2.0625 - 16 UNS 2.307 (58.6) 5.021 (127.5) 2.469 (62.7) .980 (24.9) 2.250-0.1P-0.2L-DS
2.3125 - 16 UNS 2.557 (64.9) 5.083 (129.1) 2.719 (69.1) .980 (24.9) 2.500-0.1P-0.2L-DS
2.8750 - 16 UN 3.120 (79.2) 6.471 (164.4) 2.969 (75.4) .980 (24.9) 3.000-0.1P-0.2L-DS
4.
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-4
