UC3804X: DescriptionT-1 SINGLE COLOR LED, BLUE, 3 mm; CategoryLED optoelectronic/LED; File Size308KB，24 Pages; ManufacturerETC

Download Datasheet Parametric Compare View All

UC3804X Overview

T-1 SINGLE COLOR LED, BLUE, 3 mm

UC3804X Parametric

Parameter Name	Attribute value
Maximum operating temperature	85 Cel
Minimum operating temperature	-40 Cel
Number of functions	1
Number of terminals	2
Viewing angle	56 deg
Processing package description	ROHS COMPLIANT PACKAGE-2
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
terminal coating	NOT SPECIFIED
structure	SINGLE
Optoelectronic device type	SINGLE COLOR LED
color	BLUE
Maximum continuous forward current	25 mA
LED height	5.2 mm
lead gap	2.5 mm
Lens type	WATER CLEAR
light intensity	672.0
Installation features	RADIAL MOUNT
peak wavelength	465
shape	ROUND
size	3 mm
T code	T-1

Preview

Download Datasheet

View All

U□38□4X Series

Single Color

φ3

Flush Mount Round Shape Type

Features

Package

φ3

Round shape type,

UB,UC,UG

: Water Clear epoxy

: Pale Yellow Clear epoxy

: Pale Red Clear epoxy

・Outer

Dimension

φ3

Round shape type

・Operation

temperature range.

Storage Temperature

:-40℃∼100℃

Operating Temperature

:-40℃∼85℃

・No

lead package and lead–free soldering compatible

Product features

Dominant wavelength

Blue

Blue Green

Green

Yellow

Red

470nm (UB)

505nm (UC)

525nm (UG)

590nm (UY)

626nm (UR)

Half Intensity Angle

UB,UC,UG

UY,UR

: 56 deg.

: 66 deg.

Die materials

Rank grouping parameter

Soldering methods

ESD

Packing

UB,UC,UG : InGaN, UY,UR : AlGaInP

Sorted by luminous intensity per rank taping

TTW (Through The Wave) soldering and manual soldering

InGaN : Less than 1kV(HBM),

Bulk : 200pcs(MIN.)

AlGaInP : More than 2kV(HBM)

Recommended Applications

Amusement Equipment, Electric Household Appliances, OA/FA, Other General Applications

2004.10.29

Page 1

UC3804X Related Products

	UC3804X	UB3804X	UG3804X	UR3864X	UY3864X
Description	T-1 SINGLE COLOR LED, BLUE, 3 mm	T-1 SINGLE COLOR LED, BLUE, 3 mm	T-1 SINGLE COLOR LED, BLUE, 3 mm	T-1 SINGLE COLOR LED, BLUE, 3 mm	T-1 SINGLE COLOR LED, BLUE, 3 mm
Maximum operating temperature	85 Cel	85 Cel	85 Cel	85 Cel	85 Cel
Minimum operating temperature	-40 Cel	-40 Cel	-40 Cel	-40 Cel	-40 Cel
Number of functions	1	1	1	1	1
Number of terminals	2	2	2	2	2
Viewing angle	56 deg	56 deg	56 deg	56 deg	56 deg
Processing package description	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2	ROHS COMPLIANT PACKAGE-2
Lead-free	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
terminal coating	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
structure	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Optoelectronic device type	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED	SINGLE COLOR LED
color	BLUE	BLUE	BLUE	BLUE	BLUE
Maximum continuous forward current	25 mA	25 mA	25 mA	25 mA	25 mA
LED height	5.2 mm	5.2 mm	5.2 mm	5.2 mm	5.2 mm
lead gap	2.5 mm	2.5 mm	2.5 mm	2.5 mm	2.5 mm
Lens type	WATER CLEAR	WATER CLEAR	WATER CLEAR	WATER CLEAR	WATER CLEAR
light intensity	672.0	672.0	672.0	672.0	672.0
Installation features	RADIAL MOUNT	RADIAL MOUNT	RADIAL MOUNT	RADIAL MOUNT	RADIAL MOUNT
peak wavelength	465	465	465	465	465
shape	ROUND	ROUND	ROUND	ROUND	ROUND
size	3 mm	3 mm	3 mm	3 mm	3 mm
T code	T-1	T-1	T-1	T-1	T-1
