0603R-15NG datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 0603R-15NG

0603R-15NG: DescriptionFixed Inductors; CategoryPassive components inductor; File Size1MB，1 Pages; ManufacturerAPI Delevan; Websitehttp://www.delevan.com/; Environmental Compliance

Download Datasheet Parametric View All

0603R-15NG Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	0603R-15NG	-	-	View	Buy Now

0603R-15NG Overview

Fixed Inductors

0603R-15NG Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	API Delevan
package instruction	0603
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
uppercase and lowercase codes	0603
structure	Open Core
core material	CERAMIC
DC Resistance	0.17 Ω
Nominal inductance(L)	0.015 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Manufacturer's serial number	0603R
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	1.02 mm
Package length	1.8 mm
Package form	SMT
Package width	1.14 mm
method of packing	TR, 7 Inch
Minimum quality factor (at nominal inductance)	35
Maximum rated current	0.7 A
self resonant frequency	4000 MHz
series	0603R
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Tin (Sn)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	2%
Base Number Matches	1

Preview

Download Datasheet

View All

±1

TI )

RA A

T (m

EN UM

RR IM

CU AX

AN )

ST S

SI HM

RE M (O

DC MU

)

TE )

Q z

& (MH

CE CY

AN N

CT UE

DU EQ

IN FR

SERIES

0603R

Actual Size (Max.)

Open Construction

Wirewound Surface Mount Inductors

Physical Parameters

Inches

Millimeters

0.071 Max.

1.80 Max.

0.045 Max.

1.14 Max.

0.040 Max.

1.02 Max.

0.030 (Ref. only)

0.76 (Ref. only)

0.018 (Ref. only)

0.44 (Ref. only)

0.040 (Ref. only)

1.03 (Ref. only)

0.040

1.03

0.025

0.64

0.025

0.64

Operating Temperature Range

–40°C to +125°C

Inductance and Q

tested on HP4291A using HP16193A

test ﬁxture, or equivalent

Packaging

Tape & reel (8mm): 7" reel, 4000 pieces max.

-1N6K

-1N8K

-3N3K

-3N6K

-3N9K

-4N3K

-4N7K

-5N1K

-5N6K

-6N8K

-7N5K

-8N2K

-8N7K

-9N5K

-10NK

-11NK

-12NK

-15NK

-16NK

-18NK

-22NK

-24NK

-27NK

-30NK

-33NK

-36NK

-39NK

-43NK

-47NK

-56NK

-68NK

-72NK

-82NK

-101K

-111K

-121K

-151K

-181K

-221K

-271K

-331K

-391K

1.6

1.8

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.8

7.5

8.2

8.7

9.5

100

110

120

150

180

220

270

330

390

SERIES 0603R CERAMIC CORE

250

6000

250

6000

250

6000

250

5800

250

6000

250

5800

250

5800

250

5800

250

5800

250

5800

250

4800

250

4800

250

4800

250

4800

250

4800

250

4000

250

4000

250

4000

250

3300

250

3100

250

3000

250

2800

250

2800

250

2800

250

2300

250

2300

250

2200

200

2000

200

2000

200

1900

200

1700

150

1700

150

1700

150

1400

150

1350

150

1300

100

1300

100

1200

100

1200

100

900

100

900

100

900

0.040

0.045

0.080

0.063

0.080

0.063

0.120

0.160

0.170

0.110

0.130

0.086

0.130

0.170

0.110

0.170

0.190

0.130

0.220

0.150

0.220

0.250

0.280

0.310

0.340

0.490

0.540

0.580

0.610

0.650

0.950

1.400

1.600

2.100

3.800

4.350

700

600

400

300

280

250

200

100

Optional Tolerances: 9.5nH & Lower J = 5%

All Other Values: J = 5% G = 2%

*Complete part # must include series # PLUS the dash #

For surface ﬁnish information, refer to www.delevanﬁnishes.com

270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com

1/2009
