SAW Components
BAW Bluetooth/WLAN Filter
Datasheet
Application
s
Low-loss BAW RF single filter for Bluetooth/WLAN
s
s
s
s
s
s
s
B8328
2442.0 MHz
with LTE Band 7 / Band 40 / Band 41 coexistence
Usable passband 79.0 MHz
Unbalanced to unbalanced operation
Excellent insertion loss
High out of band selectivity
Filter impedance 50
Ω
Excellent B7 attenuation
Superior 2nd harmonic suppression
0.45 max.
s
s
s
s
s
s
s
s
Package size 1.4 x 1.1 mm
2
Package height 0.45 mm max
RoHS compatible
Approximate weight 0.0012 g
Package for
Surface Mount Technology
(SMT)
Ni, gold-plated terminals
Electrostatic Sensitive Device
(ESD)
Moisture Sensitivity Level
3 (MSL
3)
0.325
2
3
1
0.575
Features
0.25
bottom view
5
0.5
0.5
4
side view
1.4
5
4
1.1
1
top view
2
3
Pin configuration
s
1
s
4
s
2,3,5
Input (unbalanced)
Output (unbalanced)
To be grounded
Please read
cautions and warnings and
important notes
at the end of this document.
2
December 01, 2014
SAW Components
BAW Bluetooth/WLAN Filter
Datasheet
Characteristics of Filter
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –20 ˚C to +85 ˚C
Z
S
=
50
Ω
shunt coil 6.8 nH
Z
L
=
50
Ω
shunt coil 6.8 nH
B8328
typ.
@ 25 ˚C
2442.0
B8328
2442.0 MHz
Characteristics
Center frequency
f
C
min.
max.
MHz
Maximum insertion attenuation - WLAN
1)
α
max
2403.1 ... 2420.9 MHz (channel 1)
1)
2408.1 ... 2425.9 MHz (channel 2)
1)
2413.1 ... 2470.9 MHz (channel 3-11)
1)
2458.1 ... 2475.9 MHz (channel 12)
1)
2463.1 ... 2480.9 MHz (channel 13)
1)
Maximum insertion attenuation - BT
2)
2401.5 ... 2480.5 MHz
VSWR (Input and Output)
2403.1 ... 2475.9
2463.1 ... 2480.9
Attenuation
100.0...1805.0MHz
1805.0...2170.0MHz
2300.0...2360.0MHz
3)
2360.0...2365.0MHz
3)
2365.0...2370.0MHz
3)
2500.0...2505.0MHz
3)
2505.0...2570.0MHz
3)
2570.0...2620.0MHz
3)
2620.0...2690.0MHz
3)
4800.0...5805.0MHz
2nd Harmonics
CW tone at input, 2442 MHz, 22 dBm
1)
2)
3)
4)
1.4
1.25
1.1
1.3
1.65
2.1
1.8
1.7
2.2
2.9
dB
dB
dB
dB
dB
α
max
1.3
2)
2.0
2)
dB
MHz
MHz
α
34
35
34
40
40
43
4)
42
40
40
18
1.7
1.85
2.4
37
38
41
46
48
62
49
45
45
31
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
-63
dBc
Averaged values within each WiFi channel width of 17.8 MHz
Averaged values over whole passband due to frequency hopping in Bluetooth mode
Averaged value of linear S-parameter over 5 MHz
+25˚C to +85˚C
Please read
cautions and warnings and
important notes
at the end of this document.
3
December 01, 2014
SAW Components
BAW Bluetooth/WLAN Filter
Datasheet
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
ESD voltage
T
T
stg
V
DC
V
ESD
–30/+85
–40/+90
5
1)
50
2)
300
3)
600
4)
26
˚C
˚C
V
V
V
V
dBm
B8328
2442.0 MHz
Input power at PIN1
channel 1 to channel 13
1)
2)
3)
4)
Machine Model
Human Body Model
Charged Device Model
20M MHz OFDM signal, 65˚C,
5000 hr
168h Damp Heat Steady State acc. to IEC60068-2-67 Cy
acc. to JESD22-A115B (MM - Machine Model), 10 negative and 10 positive pulses
acc. to JESD22-A114F (HBM - Human Body Model), 1 negative and 1 positive pulses
acc. to JESD22-C101C (CDM - Field Induced Charged Device Model), 3 negative and 3 positive pulses
Matching network
s
L
in
= 6.8 nH
s
L
out
= 6.8 nH
s
Recommendation to use TDK MLG0603 P-series
Input
Port 1
L
in
L
out
Antenna
Port 4
Please read
cautions and warnings and
important notes
at the end of this document.
4
December 01, 2014
SAW Components
BAW Bluetooth/WLAN Filter
Datasheet
Transfer function
