Venting Solutions
Heyco Vent Plugs and
Thick Panel Vent Plugs
®
Mounting Hole Diameter Range: .500˝ (12,7 mm) to 4.000˝ (101,6 mm)
•
Permit the passage of air for
ventilation and heat dissipation.
•
Quick and easy installation with only
fingertip pressure.
•
Convex, matte finish head tapers
to a thin edge.
•
VP-500 through VP-875 have .094˝
(2,4 mm) diameter vent holes. All
other sizes have .125˝ (3,2 mm)
diameter vents.
•
Lock firmly into panel up to .250˝
(6,4 mm) thick.
•
Locking fingers in fractional
increments up to the maximum
panel thickness.
•
Multiple sizes for use in .500˝
(12,7 mm) to 4.000˝ (101,6 mm)
diameter holes.
•
Approximate Head Thickness:
.062˝ (1,6 mm). Thickness may vary.
•
Heyco Louvered Plugs available, see
page 5-3.
MOUNTING
HOLE
DIAMETER
PART NO.
mm.
12,7
14,3
15,9
19,1
20,6
22,2
25,4
27,8 -
28,6
30,1
31,7
34,9
38,1
44,5
50,8
12,7
15,9
19,1
22,2
25,4
27,8 -
28,6
30,1
31,7
34,9
38,1
44,5
50,8
63,5
76,2
88,9
101,6
Black
White
DESCRIPTION
No. of
Vent Holes
PART DIMENSIONS
A
B
Head Diameter
Overall Height
in.
mm.
in.
mm.
.56
.66
.73
.91
.89
1.02
1.20
1.22
1.31
1.38
1.50
1.67
1.91
2.14
.58
.73
.91
1.02
1.20
1.22
1.31
1.38
1.50
1.67
1.91
2.14
2.72
3.15
3.66
4.16
14,2
16,7
18,7
23,0
22,6
25,8
30,6
30,9
33,3
34,9
38,1
42,4
48,4
54,4
14,7
18,7
23,0
25,8
30,6
30,9
33,3
34,9
38,1
42,4
48,4
54,4
69,0
80,0
92,9
105,6
.58
.75
.74
.75
14,7
19,1
18,8
19,1
.56
14,3
.47
11,9
.45
11,5
in.
Multiple Locking Steps for Panel Thickness up to .125˝ (3,2 mm)
.500
.562
.625
.750
.812
.875
1.000
1.093 -
1.125
1.187
1.250
1.375
1.500
1.750
2.000
.500
.625
.750
.875
1.000
1.093 -
1.125
2637
2647
2657
2677
2688
2697
2707
2726
2736
2743
2797
2756
2766
2776
2786
3010
3013
2426
3152
3154
3032
3160
3034
3036
3156
3038
3158
2793
2458
2467
2476
2638
-
2658
2678
2689
2698
2708
2727
2737
2744
-
2757
2767
2777
2787
3011
3014
2427
3153
3155
3033
3161
3035
3037
3157
3039
3159
2794
2459
2468
2477
VP 500
VP 562
VP 625
VP 750
VP 812
VP 875
VP 1000
VP 1093
VP 1187
VP 1250
SVP 1250-4
VP 1375
VP 1500
VP 1750
VP 2000
VPT 500
VPT 625
VPT 750
VPT 875
VPT 1000
VPT 1093
VPT 1187
VPT 1250
VPT 1375
VPT 1500
VPT 1750
VPT 2000
VP 2.5
VP 3.0
VP 3.5
VP 4.0
4
4
5
8
8
9
9
9
10
10
4
11
13
13
19
4
5
8
9
9
9
10
10
11
13
13
19
19
26
38
48
.41
10,3
Multiple Locking Steps for Panel Thickness up to .250˝ (6,4 mm)
A
B
1.187
1.250
1.375
1.500
1.750
2.000
2.500
3.000
3.500
4.000
Standard color black. Consult Heyco for other colors.
Quick
Specs
5-1
Material
Certifications
Flammability Rating
Temperature Range
Nylon 6/6
Recognized under the Component Program of Underwriters’ Laboratories,
File E51579
Certified by Canadian Standards Association, File 8919
94V-2
-40°F (-40°C) to 221°F (105°C)
