for EMI Shielding Applications
Product Series
Dash Number
Nickel Plated Copper
Specify number of feet
on purchase order.
I.D.
Lanyard
(Synthetic Fiber)
100-003 A 203 L
A
= 36 AWG (Table I)
B
= 34 AWG (Table II)
Lanyard
(Omit for None)
Minimum Order Length
is 100 Feet (30.5M)
Current
Rating Amps
7.0
11.0
16.0
19.0
25.0
40.0
32.0
33.0
46.0
53.0
53.0
62.0
73.0
85.0
88.0
65.0
90.0
Lbs./100 Ft.
(Kg/30.5M)
.20
.40
.60
.83
1.03
2.09
1.43
1.63
2.80
3.45
3.95
4.77
5.00
5.94
7.35
5.83
7.50
(.09)
(.18)
(.27)
(.38)
(.47)
(.95)
(.65)
(.74)
(1.27)
(1.56)
(1.79)
(2.16)
(2.27)
(2.69)
(3.33)
(2.64)
(3.40)
TABLE I: (36 AWG)
Dash
No.
031
062
078
109
125
156
171
188
203
250
375
500
562
625
781
937
1000
1250
1375
1500
2000
2500
Fractional
Equivalent
1/32
1/16
5/64
7/64
1/8
5/32
11/64
3/16
13/64
1/4
3/8
1/2
9/16
5/8
25/32
15/16
1
1 1/4
1 3/8
1 1/2
2
2 1/2
Nominal
I.D.
.031
.062
.078
.109
.125
.156
.171
.188
.203
.250
.375
.500
.562
.625
.781
.937
1.000
1.250
1.375
1.500
2.000
2.500
(0.8)
(1.6)
(2.0)
(2.8)
(3.2)
(4.0)
(4.3)
(4.8)
(5.2)
(6.4)
(9.5)
(12.7)
(14.3)
(15.9)
(19.8)
(23.8)
(25.4)
(31.8)
(34.9)
(38.1)
(50.8)
(63.5)
No. of
Carriers
24
24
24
24
24
24
24
24
24
24
48
48
48
48
48
64
64
72
72
72
96
96
No. of
Ends
24
48
72
96
120
240
168
192
312
384
384
528
624
720
864
640
768
792
864
936
1152
1248
TABLE II: (34 AWG)
Dash
No.
062
109
125
171
203
375
437
500
781
1000
1250
Fractional
Equivalent
1/16
7/64
1/8
11/64
13/64
3/8
7/16
1/2
25/32
1
1 1/4
Nominal
I.D.
.062 (1.6)
.109 (2.8)
.125 (3.2)
.171 (4.3)
.203 (5.2)
.375 (9.5)
.437 (11.1)
.500 (12.7)
.781 (19.8)
1.000 (25.4)
1.250 (31.8)
No. of
Carriers
16
16
24
24
24
48
48
48
48
64
72
No. of
Ends
32
64
72
120
192
240
288
336
528
576
648
Current
Rating Amps
11.0
19.0
19.0
36.0
46.0
53.0
44.2
62.0
88.0
150.0
Lbs./100 Ft.
(Kg/30.5M)
.43 (.20)
.82 (.37)
.92 (.42)
1.56 (.71)
2.79 (1.27)
3.27 (1.48)
3.93 (1.78)
4.77 (2.16)
7.14 (3.24)
7.33 (3.33)
APPLICATION NOTES
1.
Direct current ratings are given for information only. Values shown are for uninsulated
braid in free air at 86°F (30°C). Actual values will depend on permissible temperature
rise, voltage drop and other conditions of service. Values should be de-rated if the braid is
insulated or in close contact with other components.
2.
3.
Consult factory for sizes not shown
Metric dimensions (mm) are indicated in parentheses.
© 2010 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
H-31
Connector
Accessories
100-003
Tubular Metal Braid ASTM B355 Class 4 OFHC
