RSO
www.vishay.com
Vishay Sfernice
Wirewound Resistor, Industrial High Power,
Enamelled Corrugated Tape, Tubular
FEATURES
• 160 W to 1 kW at 25 °C
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
The remarkable dissipation power of this series is the result of an original winding method using corrugated edge-wound tape,
thus forming a very active radiator. The enameling follows the contour of the resistive element and provides effective insulation
and support for the winding.
The tubular core is of special ceramic, capable of withstanding high thermal shock and overload of short duration.
NF F 16101, 10/1988 and 16102, 04/1992: Not applicable (our parts are made of metallic and refractory materials).
DIMENSIONS
in millimeters
SCREWED STAINLESS STEEL 304 l “AN” TYPE 1
A
Z
F
ØC
ØC
ØC
R
ØB
26
P
ØQ
G
H
15
L
E
D
ØB
M
J
K
SCREWED STAINLESS STEEL 304 l “CS” TYPE 1
A
SCREWED STAINLESS STEEL 304 l “CS” TYPE 2
A
ØC
23
3
ØB
58
G
H
15
L
J
K
M
Revision: 16-Mar-16
Document Number: 50018
1
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RSO
www.vishay.com
Vishay Sfernice
F
+ 0.5
+0
9
9
13
18
18
R
28.5 ± 1
28.5 ± 1
31 ± 1
45 ± 1.5
51 ± 1.5
DIMENSIONS
in millimeters
RSO
SERIES
25 x 138
25 x 168
30 x 250
40 x 370
50 x 373
RSO
SERIES
25 x 138
25 x 168
30 x 250
40 x 370
50 x 373
CONNECTIONS
AN type 1 CS type 1
AN type 1 CS type 1
AN type 1 CS type 1
AN type 2 CS type 2
AN type 2 CS type 2
CONNECTIONS
AN type 1 CS type 1
AN type 1 CS type 1
AN type 1 CS type 1
AN type 2 CS type 2
AN type 2 CS type 2
A±2
138
168
250
370
373
K
27 ± 1
27 ± 1
30 ± 1
45 ± 1.5
45 ± 1.5
ØB
MAX.
39
39
44
54.5
65
L + 0.5
6.5
6.5
9
9
9
ØC
MIN.
12.6
12.6
17.4
22.3
27.1
M ± 0.5
24
24
25
30
30
D
MAX.
54
54
62
85.5
97
P
117 ± 2
147 ± 2
227 ± 2.5
332 ± 3
332 ± 3
E
33.5 ± 1
33.5 ± 1
36 ± 1
57 ± 1.5
63 ± 1.5
Q
5.7
5.7
5.7
9.2
9.2
G
-4/+0
199
229
317
432
432
Z
6
6
5
10
11.5
H
-4/+0
169
199
287
405
405
J
50 ± 1.5
50 ± 1.5
60 ± 1.5
73.8
79
AVERAGE UNIT
WEIGHT IN g
AN
160
190
350
960
1375
CS
205
235
400
1040
1455
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
RSO 25 x 138
RSO 25 x 168
RSO 30 x 250
RSO 40 x 370
RSO 50 x 373
SIZE
25138
25168
30250
40370
50373
RESISTANCE RANGE
0.068 to 12
0.10 to 18
0.22 to 33
0.33 to 56
0.39 to 68
RATED POWER
P
25 °C
W
160
200
350
700
1000
TOLERANCE
±%
10
10
10
10
10
MECHANICAL SPECIFICATIONS
Mechanical Protection
Resistive Element
Connections
Average Unit Weight
Enamel
Ni-Cr wire
AN CS supporting collars
160 g to 1455 g
TECHNICAL SPECIFICATIONS
Resistance Range
Standard Resistance Tolerance
Power Rating
0.068
to 68
(E12 preferred series)
R
n
1
± 5 %
R
n
< 1
± 10 %
160 W to 1 kW at 25 °C
ENVIRONMENTAL SPECIFICATIONS
Temperature Range
Climatic Category
-55 °C, +450 °C
-55 °C / +200 °C / 56 days
PERFORMANCE
TESTS
Short Time Overload
Thermal Shock
Climatic Sequence
Load Life
CONDITIONS
10
P
r
during 5 s
Load at
P
r
followed by cold
temp. exposure at -55 °C / 15 s
Phase A: +200°
Phase C: -55°
Phase D: 5 cycles
90' / 30' cycle
1000 h at
P
r
25 °C
REQUIREMENTS
2 % or 0.05
2 % or 0.05
3 % or 0.05
5%
TYPICAL VALUES AND DRIFTS
1%
1%
1%
2%
RECOMMENDATIONS FOR USE
OVERLOAD:
The RSO resistors are capable of withstanding overloads of about 10
P
r
for a maximum period of 5 s; they can resist
momentarily even greater overloads.
Particular requirements should be submitted to Vishay Sfernice.
Revision: 16-Mar-16
Document Number: 50018
2
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
RSO
www.vishay.com
POWER RATING
125
Vishay Sfernice
TEMPERATURE RISE
HOT SPOT TEMPERATURE IN °C
100
450
400
RATED POWER IN %
75
300
50
200
25
0
0
100
200
300
400
450
100
0
10
100
AMBIENT TEMPERATURE IN °C
RATED POWER IN W
MARKING
Vishay Sfernice trademark, model, style, nominal resistance
(in
),
tolerance (in %), manufacturing date.
PACKAGING
Box: Fixed quantity depending on size and collars
ORDERING INFORMATION
RSO
MODEL
25 x 168
STYLE
XXX
SPECIAL
DESIGN
Method N°
Optional
CS
CONNECTIONS
U82
OHMIC VALUE
Custom items are
subject to
extra-charge and
min. order.
Please see price list.
± 10 %
TOLERANCE
B02NA
PACKAGING
e
LEAD
(Pb)-FREE
SAP PART NUMBERING GUIDELINES
RSO
MODEL
25168
STYLE
C
CONNECTIONS
R820
OHMIC VALUE
K
TOLERANCE
N
PACKAGING
RELATED DOCUMENTS
APPLICATION NOTES
Packaging Information
Accessories
www.vishay.com/doc?50033
www.vishay.com/doc?50021
Revision: 16-Mar-16
Document Number: 50018
3
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
O
RS
25 x
13
O
8
25
x1
68
RS
O
30
x2
RS
50
RS
O
O
50
4
x
37
0 x
37
3
0
RS
1000
