ISC-1210
www.vishay.com
Vishay Dale
Wirewound, Surface Mount, Molded, Shielded Inductors
FEATURES
• Molded construction provides superior strength
and moisture resistance
• Tape and reel packaging for automatic handling,
2000/reel, EIA-481
• Compatible with vapor phase, infrared and wave
soldering methodsfio
• Shielded construction minimizes coupling to
other components
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(μH)
TEST
FREQ.
(MHz)
Q
L & Q MIN.
50
50
50
50
50
50
50
50
50
45
50
45
50
45
50
40
50
40
50
40
50
40
50
38
50
36
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
25.2
40
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
7.96
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
2.52
30
0.796
30
SRF
MIN.
(MHz)
DCR
MAX.
()
RATED DC
CURRENT
(mA)
(1)
TOL.
0.010 ± 20 %
1000
0.10
810
0.012 ± 20 %
1000
0.11
750
0.015 ± 20 %
1000
0.12
720
0.018 ± 20 %
1000
0.13
690
0.022 ± 20 %
1000
0.15
640
0.027 ± 20 %
1000
0.17
610
0.033 ± 20 %
1000
0.18
585
0.039 ± 20 %
1000
0.24
530
0.047 ± 20 %
1000
0.26
495
0.056 ± 20 %
1000
0.28
485
0.068 ± 20 %
1000
0.35
475
0.082 ± 20 %
900
0.45
460
0.10
± 20 %
700
0.50
450
0.12
± 20 %
500
0.20
630
0.15
± 20 %
470
0.20
600
0.18
± 20 %
400
0.24
580
0.22
± 20 %
330
0.30
565
0.27
± 20 %
310
0.33
500
0.33
± 20 %
280
0.36
475
0.39
± 20 %
230
0.40
465
0.47
± 20 %
220
0.44
460
0.56
± 20 %
200
0.46
455
0.68
± 20 %
180
0.48
450
0.82
± 20 %
160
0.50
450
1.0
± 10 %
120
0.60
400
1.2
± 10 %
110
0.65
390
1.5
± 10 %
90.0
0.75
370
1.8
± 10 %
85.0
0.85
350
2.2
± 10 %
65.0
0.90
320
2.7
± 10 %
60.0
1.00
290
3.3
± 10 %
60.0
1.10
270
3.9
± 10 %
58.0
1.20
250
4.7
± 10 %
52.0
1.25
220
5.6
± 10 %
50.0
1.40
210
6.8
± 10 %
40.0
1.60
205
8.2
± 10 %
35.0
1.65
195
10.0
± 10 %
30.0
2.00
185
12.0
± 10 %
24.0
2.30
175
15.0
± 10 %
20.0
2.50
165
18.0
± 10 %
17.0
2.70.
155
22.0
± 10 %
16.0
3.10
150
27.0
± 10 %
14.5
3.30
125
33.0
± 10 %
14.5
5.10
115
39.0
± 10 %
14.0
5.90
105
47.0
± 10 %
13.0
8.00
100
56.0
± 10 %
11.5
10.0
95
68.0
± 10 %
11.0
10.0
90
82.0
± 10 %
11.0
11.0
85
100.0 ± 10 %
6.0
12.0
80
Note
(1)
Rated DC current based on the maximum temperature rise, not
to exceed 40 °C at +85 °C ambient
ELECTRICAL SPECIFICATIONS
Inductance range:
0.01 μH to 100 μH
Special tolerances available upon request
Operating temperature:
-55 °C to +125 °C
Coilform material:
Non-magnetic for 0.01 μH to 0.10 μH;
powdered iron for 0.12 μH to 100 μH
TEST EQUIPMENT
• H/P 4342A Q meter with Vishay Dale test fixture or equivalent
• H/P 4191A RF impedance analyzer (for SRF measurements)
• Wheatstone bridge
DIMENSIONS
in inches [millimeters]
0.087 ± 0.008
[2.21 ± 0.203]
0.126 ± 0.008
[3.20 ± 0.203]
0.098 ± 0.008
[2.49 ± 0.203]
0.030 [0.762]
Typ.
0.006 [0.152]
Ref. Typ.
0.028 ± 0.004
[0.711 ± 0.102]
Typ.
0.040
[1.02]
0.118
[3.0]
0.073 [1.85]
Ref.
0.138
[3.5]
0.118
0.020
(1)
[3.0]
[0.508]
0.039
[1.0]
0.070 [1.8]
Guidelines for
Parallel Component
Printed Circuit
Mounting Pads on
ISC-1210 Chip
Inductors
0.039
[1.0]
Note
(1)
Recommended minimum spacing between components
PART MARKING
- Vishay Dale
- Inductance value
- Date code
DESCRIPTION
ISC-1210
MODEL
10 μH
INDUCTANCE VALUE
± 10 %
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e3
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
S
PRODUCT
FAMILY
Revision: 02-Jun-15
C
1
2
SIZE
1
0
E
R
1
0
INDUCTANCE
VALUE
0
K
TOL.
PACKAGE
CODE
Document Number: 34060
