SPECIFICATION FOR APPROVAL
REF : 20111014-D
PROD.
NAME
ABC'S DWG NO.
SR0805□□□□L□-□□□
PAGE: 1
SMD POWER INDUCTOR
ABC'S ITEM NO.
Ⅰ﹒CONFIGURATION
& DIMENSIONS：
A
: 7.5±0.3
: 2.6 ref.
: 8.0 ref.
: 7.8 ref.
: 2.4 ref.
m/m
m/m
m/m
m/m
m/m
m/m
Marking
Dot is the
Inductance code
reading marking
101
A
B : 5.0±0.3
A
C
D
E
F
B
C
D
( PCB Pattern )
Ⅱ﹒SCHEMATIC
DIAGRAM：
a
b
Ⅲ﹒MATERIALS：
a﹒Core：Ferrite DR core
b﹒Wire
：Enamelled
copper wire ( class F & H )
Peak Temp：250℃ max.
c﹒Terminal：Ag/Ni/Sn
Max. Peak Temp - 5℃：30sec max.
Max time above 217℃
：60sec~150sec
max.
d﹒Remark：Products comply with RoHS'
Temperature
Rising Area
Preheat Area
requirements
+4.0
℃
/ sec max.
150 ~ 200
℃
/ 60 ~ 120sec
F
E
c
Reflow Area
Forced Cooling Area
+3.0
℃
/ sec max. -(1.0 ~ 5.0)
℃
/ sec max.
Peak Temperature:
250℃
217℃
250
Ⅳ﹒GENERAL
SPECIFICATION：
Temperature (
℃
)
200
150
60sec~120sec
60sec~150sec
60sec max.
a﹒Temp. rise
：40℃
max.
b﹒Rated current：Base on temp. rise
&
△
L / L0A=10% max.
c﹒Storage temp.：-40℃ ----+125℃
d﹒Operating temp.：-40℃----+105℃
e﹒Resistance to solder heat：250℃.10 secs.
AR-001A
100
50
0
50
100
150
Time ( seconds )
200
250
SPECIFICATION FOR APPROVAL
REF : 20111014-D
PROD.
NAME
ABC'S DWG NO.
SR0805□□□□L□-□□□
PAGE: 2
SMD POWER INDUCTOR
ABC'S ITEM NO.
Ⅴ﹒ELECTRICAL
CHARACTERISTICS：
DWG No.
SR08051R5ML□ -□□□
SR08052R5ML□ -□□□
SR08053R3ML□ -□□□
SR08053R9ML□ -□□□
SR08054R7ML□ -□□□
SR08055R6ML□ -□□□
SR08056R8ML□ -□□□
SR08058R2ML□ -□□□
SR0805100ML□ -□□□
SR0805120ML□ -□□□
SR0805150ML□ -□□□
SR0805180ML□ -□□□
SR0805220ML□ -□□□
SR0805270ML□ -□□□
SR0805330KL□ -□□□
SR0805390KL□ -□□□
SR0805470KL□ -□□□
SR0805560KL□ -□□□
SR0805680KL□ -□□□
SR0805820KL□ -□□□
SR0805101KL□ -□□□
SR0805121KL□ -□□□
SR0805151KL□ -□□□
SR0805181KL□ -□□□
SR0805221KL□ -□□□
SR0805271KL□ -□□□
SR0805331KL□ -□□□
SR0805391KL□ -□□□
SR0805471KL□ -□□□
SR0805561KL□ -□□□
SR0805681KL□ -□□□
SR0805821KL□ -□□□
SR0805102KL□ -□□□
SR0805122KL□ -□□□
SR0805152KL□ -□□□
SR0805182KL□ -□□□
SR0805222KL□ -□□□
SR0805272KL□ -□□□
SR0805332KL□ -□□□
SR0805392KL□ -□□□
SR0805472KL□ -□□□
Inductance
(
μH
)
1.5±20%
2.5±20%
3.3±20%
3.9±20%
4.7±20%
5.6±20%
6.8±20%
8.2±20%
10.0±20%
12.0±20%
15.0±20%
18.0±20%
22.0±20%
27.0±20%
33.0±10%
39.0±10%
47.0±10%
56.0±10%
68.0±10%
82.0±10%
100.0±10%
120.0±10%
150.0±10%
180.0±10%
220.0±10%
270.0±10%
330.0±10%
390.0±10%
470.0±10%
560.0±10%
680.0±10%
820.0±10%
1000.0±10%
1200.0±10%
1500.0±10%
1800.0±10%
2200.0±10%
2700.0±10%
3300.0±10%
3900.0±10%
4700.0±10%
Q
ref.
32
32
32
32
31
31
30
29
25
25
25
20
20
20
15
15
15
15
15
12
12
12
12
12
12
12
12
12
12
30
29
28
27
28
27
30
29
31
28
28
30
Test Freq. ( Hz )
L
Q
1K
7.960M
1K
7.960M
1K
7.960M
1K
7.960M
1K
7.960M
1K
7.960M
1K
7.960M
1K
7.960M
1K
2.520M
1K
2.520M
1K
2.520M
2.520M
1K
1K
2.520M
1K
2.520M
1K
2.520M
1K
2.520M
1K
2.520M
1K
2.520M
1K
2.520M
1K
2.520M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
0.796M
1K
0.796M
1K
0.796M
1K
0.796M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
0.252M
1K
SRF
( MHz )
nom.
120.0
70.0
55.0
45.0
38.0
34.0
33.0
30.0
22.0
20.0
16.0
15.0
13.0
12.0
10.0
9.5
9.0
8.5
8.0
7.0
6.5
5.6
5.5
5.0
4.8
4.5
4.3
4.0
3.8
3.7
3.5
3.2
3.0
2.6
2.4
1.6
1.5
1.4
1.2
1.1
1.0
RDC
(
Ω
)
max.
0.015
0.020
0.022
0.024
0.033
0.035
0.040
0.050
0.070
0.080
0.090
0.100
0.110
0.120
0.140
0.160
0.200
0.240
0.300
0.370
0.450
0.480
0.680
0.770
0.960
1.110
1.260
1.770
1.960
2.500
2.800
4.000
4.500
6.800
8.000
9.200
10.000
11.800
16.500
18.000
21.000
IDC
(A)
max.
6.00
5.00
4.60
4.40
3.70
3.50
3.20
2.80
2.30
2.00
1.80
1.60
1.50
1.30
1.20
1.10
1.00
0.94
0.85
0.78
0.72
0.66
0.58
0.51
0.49
0.42
0.40
0.36
0.34
0.30
0.28
0.23
0.21
0.17
0.15
0.14
0.13
0.12
0.10
0.09
0.08
1).
□：Packaging
information… A：Bulk B：Taping Reel
2)."-
":Reference code
3). IDC base on temp. rise 40
℃
max. &
△
L/L0A=10% max.
□□□
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20111014-D
PROD.
NAME
ABC'S DWG NO.
SR0805□□□□L□-□□□
PAGE: 3
SMD POWER INDUCTOR
ABC'S ITEM NO.
Ⅵ﹒INDUCTANCE
VS. DC CURRENT CURVE：
104
7
5
3
2
103
7
5
3
2
102
7
5
3
2
101
7
5
3
2
100
101
101
332
Inductance（uH）
561
330
100
3R3
2 3
5 7 102
2 3
5 7 103 2 3
5 7 104
DC Current (mA)
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20111014-D
PROD.
NAME
ABC'S DWG NO.
SR0805□□□□L□-□□□
PAGE: 4
SMD POWER INDUCTOR
ABC'S ITEM NO.
Ⅶ﹒PACKAGING
INFORMATION：
( 1 ) Configuration
T
Cover tape
2.0±0.5
A
∮
C
∮
C
N
B
G
D
Embossed carrier
※
Carrier tape width : D
P:12 m/m
End
4 m/m
Start
101
101
101
101
101
101
Leader
no component
200 m/m min.
Components
User direction of feed
Trailer
no component
400 m/m min.
( 2 ) Dimensions
Style
13 - 16
A
330
B
21±0.8
C
13±0.5
D
16
G
18
+0
N
50
-0
Unit:m/m
T
22.4
( 3 ) Q'TY & G.W. Per package
Inner : Reel
Series
SR0805
SR0805
Q'TY (pcs)
G.W. (gw)
Style
Q'TY (pcs)
Outer : Carton
G.W. (Kg)
SIZE (cm)
1,000
500
1,300
650
13 - 16
13 - 16
6,000
3,000
10.5
5.25
38 x 37 x 22
38 x 37 x 22
AR-001A
SPECIFICATION FOR APPROVAL
REF : 20111014-D
PROD.
NAME
ABC'S DWG NO.
SR0805□□□□L□-□□□
PAGE: 5
SMD POWER INDUCTOR
ABC'S ITEM NO.
Ⅷ﹒DWGING
NUMBER EXPRESSION：
S
R
0
8
0
5
Reference code
Appendix code 2 : Package
Appendix code 1 : Classification
Tolerance code
Electrical code
Dimension code
Type code
Appendix code 1：Product Classification
L：Lead Free Standard products comply with RoHS' requirements
1 ~ 9：Lead Free Special products comply with RoHS' requirements
Appendix code 2：Package Information
Code
A
B
C
D
Inner package
T.B.D.
T / R ( Reel package )
T / R ( Reel package )
T / R ( Reel package )
Inner package Q'TY
T.B.D.
1000
1000
500
pcs
pcs
pcs
Remark
AR-001A
