CER0367A
2.450 GHz BPF
Rev 1 – Origin Date: February 17, 2006 – Revision Date: March 31, 2006
Features
• High Rejection
• Low ripple, Low Loss
• Small Size
Description
Surface mount, silver (Ag) coated barium
ceramic filter.
Weight: 0.7 grams typical
Material: Filter is composed of a ceramic
block plated with Ag.
Filter complies with RoHS standards.
Electrical Specifications
Frequency
MHz
2400 - 2500
2400 - 2500
2400 - 2500
2400 - 2500
2100
2800
Typical
@ 25ºC
-0.85
0.25
-13.50
-13.50
-45.00
-33.00
180 MHz
Specification
@ 25ºC
-1.00
0.40
-12.00
-12.00
-40.00
-30.00
Parameter
Passband Iloss
Passband Ripple
Passband Return Loss @ TX
Passband Return Loss @ Ant
Attneuation
3 dB Bandwidth
Spec over
-40ºC to +85ºC
-1.20
0.50
-12.00
-12.00
-40.00
-30.00
Power into any port
1 Watt max
Note: Supplier shall test each filter to the critical electrical specifications of the above table. Any subsequent audits may deviate from in value due to
measurement repeatability among different test systems. Such deviations shall not exceed the following limits:
Specification Allowance
Insertion Loss
0.1 dB
Return Loss
1.0 dB
Stopbands
1.0 dB
•“This product is covered by one or more of the following U.S. and foreign patents including: US 4,692,726;US 4,742,562; US 4,800,348;US 4,829,274;US 5,146,193;EP 0573597;DE 0573597;FR 0573597;JP 508149/92;KR 142171;US
5,162,760;US 5,218,329;US 5,250,916;US 5,327,109;US 5,488,335;CA 2114029;FR 9306297;GB 2273393;JP 3205337;KR 115113;CN 93106228.4;US 5,512,866;EP 0706719;DE 0706719;FR 0706719;GB 0706719;CN 95190359.4;US
5,602,518;US 5,721,520;US 5,745,018;EP 0910875;DE 0910875;DK 0910875;FR 0910875;GB 0910875;IE 0910875;JP 505182/98;KR 10 -323013;US 5,994,978;US 6,462,629;CN 00810420.4;US 6,559,735;US 6 ,650,202;US 6,834,429.Other
US and foreign patents pending.
•CTS Corporation 2006 reserves all copyrights in the layout, desi gn and configuration of the patterns on this product.”
