ALUMINUM ELECTROLYTIC CAPACITORS
LGY
Snap-in Terminal Type, 105°C Long Life Assurance
Long life assurance series withstanding 5000 hours application of ripple current at 105
°C.
Suited for use in industrial power supplies applications where high reliability and dependable
performance are the most important.
Suited for ballast application.
Compliant to the RoHS directive (2011/65/EU).
LGR
Long Life
LGY
Smaller
Long Life
LGU
LGX
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
–
40 to +105°C
Performance Characteristics
16 to 100V
560 to 47000µF
3
CV
± 20% at 120Hz, 20°C
I
3 CV
(µA) (After 5 minutes' application of rated voltage) [C : Rated Capacitance (µF) V : Voltage (V)]
3 CV
Rated voltage(V)
tan
δ
(MAX.)
Measurement frequency : 120Hz at 20°C
16
0.50
25
0.40
35
0.35
50
0.30
63
0.25
80
100
0.20
Stability at Low Temperature
Measurement frequency : 120Hz
16 to 100
Rated voltage(V)
4
Z
–
25°C/ Z+20°C
Impedance ratio
20
Z
–
40°C/ Z+20°C
ZT/Z20 (MAX.)
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20
°C
after D.C. bias plus rated ripple
current is applied for 5000 hours at 105
°C
, the peak voltage
shall not exceed the rated voltage.
After storing the capacitors under no load at 105°C
for 1000 hours and then performing voltage treatment
based on JIS C 5101-4 clause 4.1 at 20°C,
they shall meet the requirements listed at right.
Printed with white color letter on black sleeve.
Capacitance change
tan
δ
Leakage current
Capacitance change
tan
δ
Leakage current
Within ±25% of the initial capacitance value
250% or less than the initial specified value
Less than or equal to the initial specified value
Within ±15% of the initial capacitance value
150% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
Drawing
Polarity bar
Sleeve (P.E.T.)
Polarity bar
Sleeve (P.E.T.)
Type numbering system (Example : 100V 680
µ
F)
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10 11
12
13 14
φD
+1MAX.
φD
+1MAX.
L G Y 2 A 6 8 1 M E L Z
10 11 12
3 0
13 14
Configuration
Case height code
Case dia. code
Case height code
φD
Code
22Case dia. code
Z
25
φD
30
22
35
25
30
35
A
Code
BZ
CA
B
C
L G Y 2 A 6 8 1 M E L Z
10
L
±
2
3 0
Capacitance tolerance (±20%)
Configuration
Rated capacitance (680µF)
Capacitance tolerance (±20%)
Rated voltage (100V)
4.0±0.5
L
Pressure relief vent
±
2
4.0±0.5
0.8
(1
0)
+0.2
-0.1
10
±
Pressure relief
.
vent
0
1
0
4.0±0.5
4.0±0.5
2.5
(2.5)
0.8
+0.2
-0.1
.2
+0 .1
.8
-0
Rated capacitance nameF)
Series (680
Rated voltage Type
(100V)
.2
+0 .1
-0
10
±
0.1
0.8
Series name
Type
2- 2
φ ±
0.1
(PC board hole dimensions)
2-2
φ ±
0.1
(PC board hole dimensions)
1.5
-0.1
+0.2
(Terminal dimensions)
1.5
-0.1
(Terminal dimensions)
+0.2
The other terminal is also available upon request.
Please refer page 332 for schematic of dimensions.
Frequency coefficient of rated ripple current
Frequency (Hz)
16 to 100V
50
0.88
60
0.90
120
1.00
300
1.07
1k
1.15
10k
1.15
50k or more
1.15
Minimum order quantity : 50pcs.
Dimension table in next page.
312
