LPS6235-683MLB

Description
Fixed Inductors Power Inductor SEE PART COMMENT TAB
CategoryPassive components    inductor
File Size208KB，2 Pages
ManufacturerCOILCRAFT
Websitehttp://www.coilcraft.com/
Environmental Compliance
Download Datasheet Parametric View All

LPS6235-683MLB Online Shopping

Suppliers Part Number Price MOQ In stock
LPS6235-683MLB - - View Buy Now

LPS6235-683MLB Overview

Fixed Inductors Power Inductor SEE PART COMMENT TAB

LPS6235-683MLB Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instruction6262-35M
Reach Compliance Codecompliant
ECCN codeEAR99
uppercase and lowercase codes6262-35M
structureShielded
core materialFERRITE
DC Resistance0.345 Ω
Nominal inductance(L)68 µH
Inductor ApplicationsPOWER INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial numberLPS6235
Number of functions1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package height3.5 mm
Package length6 mm
Package formSMT
Package width6 mm
method of packingTR
Maximum rated current0.96 A
self resonant frequency10.8 MHz
seriesLPS6235
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldYES
surface mountYES
Terminal surfaceSilver/Palladium/Platinum - with Glass frit
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency0.1 MHz
Tolerance20%
Base Number Matches1

Preview

Download Datasheet
Web
page
Sample
& buy
Tools &
software
Support
& FAQ
Document 587-1
Shielded Power Inductors – LPS6235
• Low DCR; high current; shielded construction
• Perfect for backlight applications
Designer’s Kit C345
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See
www.coilcraft.com/coreloss
Environmental
RoHS compliant, halogen free
Terminations
RoHS compliant matte tin over nickel over silver.
Other terminations available at additional cost.
Weight
460 – 480 mg
Ambient temperature
–40°C to +85°C with (40°C rise)
Irms
current.
Maximum part temperature
+125°C (ambient + temp rise).
Derating.
Storage temperature
Component: –40°C to +125°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
350/7″ reel; 1500/13″ reel Plastic tape: 16 mm wide,
0.3 mm thick, 12 mm pocket spacing, 3.68 mm pocket depth
Recommended pick and place nozzle
OD: 6.2 mm; ID:
≤
3.1 mm
PCB washing
Tested to MIL-STD-202 Method 215 plus an additional
aqueous wash. See
Doc787_PCB_Washing.pdf.
Part number
1
Isat
(A)
5
DCR
SRF
Inductance
2
max
3
typ
4
10% 20% 30%
±20% (µH) (Ohms) (MHz) drop drop drop
0.075
0.095
0.100
0.110
0.125
0.140
0.145
0.180
0.245
0.280
0.345
0.315
0.375
0.435
0.535
0.820
1.20
1.60
2.00
2.20
2.70
3.40
4.60
5.42
6.70
9.50
14.5
16.4
21.4
24.5
29.5
55
48
37
29
25
24
24
16
13
12
10.8
10.0
9.0
8.3
7.3
5.6
4.4
3.6
3.1
2.8
2.5
2.2
1.9
1.7
1.5
1.1
0.94
0.86
0.80
0.70
0.61
2.6
2.5
2.3
1.9
1.9
1.7
1.6
1.3
1.1
1.0
0.90
0.46
0.46
0.44
0.37
0.31
0.26
0.22
0.20
0.17
0.16
0.14
0.12
0.11
0.090
0.080
0.070
0.060
0.057
0.052
0.050
2.7
2.6
2.4
2.2
2.0
1.8
1.7
1.4
1.2
1.0
0.94
0.52
0.52
0.48
0.43
0.36
0.29
0.25
0.22
0.19
0.18
0.17
0.13
0.12
0.11
0.090
0.077
0.070
0.065
0.060
0.055
2.8
2.7
2.5
2.3
2.0
1.9
1.7
1.5
1.2
1.1
0.96
0.55
0.54
0.51
0.45
0.37
0.30
0.26
0.23
0.21
0.19
0.18
0.14
0.13
0.11
0.10
0.084
0.080
0.069
0.067
0.060
Irms
(A)
6
20°C 40°C
rise rise
1.30
1.30
1.28
1.25
1.22
1.20
1.10
1.00
0.80
0.75
0.73
0.72
0.70
0.60
0.53
0.45
0.40
0.32
0.29
0.28
0.26
0.24
0.19
0.18
0.16
0.14
0.11
0.10
0.090
0.085
0.075
1.90
1.85
1.80
1.75
1.70
1.65
1.60
1.30
1.15
1.07
1.00
0.95
0.90
0.80
0.73
0.64
0.50
0.43
0.38
0.37
0.33
0.30
0.26
0.23
0.22
0.180
0.150
0.130
0.120
0.115
0.095
1. Please specify
termination
and
packaging
codes:
LPS6235-106MRC
Termination: R
= RoHS compliant matte tin over
nickel over silver.
Special order, added cost:
Q
= RoHS tin-silver-copper (95.5/4/0.5)
or
P
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481
embossed plastic tape (350 parts
per full reel).
B
= Less than full reel. In tape, but not
machine ready. To have a leader and
trailer added ($25 charge), use code
letter C instead.
D
= 13″ machine-ready reel. EIA-481
embossed plastic tape. Factory
order only, not stocked (1500 parts
per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc using an
Agilent/HP 4192A.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 8753ES or equivalent.
5. DC current at 25°C that causes the specified induc-
tance drop from its value without current.
Click for temperature derating information.
6. Current that causes the specified temperature rise from
25°C ambient. This information is for reference only and
does not represent absolute maximum ratings.
Click for temperature derating information.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components”
before soldering.
LPS6235-682MR_
6.8
LPS6235-822MR_
8.2
LPS6235-103MR_
10.0
LPS6235-123MR_
12.0
LPS6235-153MR_
15.0
LPS6235-183MR_
18.0
LPS6235-223MR_
22.0
LPS6235-333MR_
33.0
LPS6235-473MR_
47.0
LPS6235-563MR_
56.0
LPS6235-683MR_
68.0
LPS6235-823MR_
82.0
LPS6235-104MR_
100.0
LPS6235-124MR_
120.0
LPS6235-154MR_
150.0
LPS6235-224MR_
220.0
LPS6235-334MR_
330.0
LPS6235-474MR_
470.0
LPS6235-564MR_
560.0
LPS6235-684MR_
680.0
LPS6235-824MR_
820.0
LPS6235-105MR_ 1000.0
LPS6235-155MR_ 1500.0
LPS6235-185MR_ 1800.0
LPS6235-225MR_ 2200.0
LPS6235-335MR_ 3300.0
LPS6235-475MR_ 4700.0
LPS6235-565MR_ 5600.0
LPS6235-685MR_ 6800.0
LPS6235-825MR_ 8200.0
LPS6235-106MR_ 10000.0
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 587-1
Revised 09/02/15
© Coilcraft Inc. 2017
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
