VY1 Series
www.vishay.com
Vishay BCcomponents
AC Line Rated Ceramic Disc Capacitors
Class X1, 760 V
AC
, Class Y1, 500 V
AC
FEATURES
•
•
•
•
•
Complying with IEC 60384-14 4
th
edition
High reliability
Vertical (inline) kinked or straight leads
Singlelayer AC disc safety capacitors
Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
•
•
•
•
VALUE
1
U2J
500
10
22
Radial
U2J
760
2
Y5S, Y5U, Y5S, Y5U,
Y5V
Y5V
500
33
4700
760
QUICK REFERENCE DATA
DESCRIPTION
Ceramic Class
Ceramic Dielectric
Voltage (V
AC
)
Min. Capacitance (pF)
Max. Capacitance (pF)
Mounting
X1, Y1 according to IEC 60384-14.4
Across-the-line
Line by-pass
Antenna coupling
DESIGN
The capacitor consists of a ceramic disc which is silver
plated on both sides. Connection leads are made of tinned
copper clad steel having a diameter of 0.6 mm.
The capacitors may be supplied with vertical (inline) kinked
leads having a lead spacing of 10.0 mm, or 12.5 mm.
Encapsulation is made of flame retardant epoxy resin
in accordance with UL 94 V-0.
OPERATING TEMPERATURE RANGE
-40 °C to +125 °C
CAPACITANCE RANGE
10 pF to 4700 pF
TEMPERATURE CHARACTERISTICS
Class 1: N750 (U2J)
Class 2: Y5S, Y5U, Y5V
RATED VOLTAGE U
R
IEC 60384-14.4:
(X1): 760 V
AC,
50 Hz
(Y1): 500 V
AC
, 50 Hz
1500 V
DC
SECTIONAL SPECIFICATIONS
Climatic category (according to EN 60058-1)
Class 1 and class 2: 40/125/21
TEST VOLTAGE
Component test (100 %):
4000 V
AC
, 50 Hz, 2 s
Random sampling test (destructive test):
4000 V
AC
, 50 Hz, 60 s
Voltage proof of coating (destructive test):
4000 V
AC
, 50 Hz, 60 s
COATING
According to UL 94 V-0
Epoxy resin, isolating, flame retardant
Halogen-free available
Reinforced insulation
APPROVALS
IEC 60384-14.4
UL 60384-14
DIN EN 60384-14
CSA E60384-1:03, CSA E60384-14:09
CQC11-471112-2009
INSULATION RESISTANCE
10 000 M
CAPACITANCE TOLERANCE
± 20 % (code M); ± 10 % (code K)
DISSIPATION FACTOR
Class 1: max. 0.5 % (1 MHz)
Class 2: max. 2.5 % (1 kHz)
PACKAGING
Bulk, tape and reel, taped ammopack
Revision: 12-Feb-18
Document Number: 28537
1
For technical questions, contact:
cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VY1 Series
www.vishay.com
Vishay BCcomponents
DIMENSIONS
in millimeters
F
e = 3.0 max.
SH
= 4.0 max.
Ø 0.6 ± 0.05
D
max.
T
max.
L = 30.0 ± 5.0
Capacitors with 10.0 mm or 12.5 mm lead
spacing
TECHNICAL DATA
CAPACITANCE
C (pF)
U2J (N750)
10
15
22
Y5S (2C3)
33
47
68
100
150
220
330
Y5U (2E3)
470
680
1000
1500
2200
3300
3900
4700
Y5V (2F3) MINI SIZE SERIES
1000
1500
2200
3300
3900
4700
± 20
7.5
8.5
9.5
11.0
12.0
13.0
5.5
10.0 or 12.5
VY1102M29Y5VQ6###
VY1152M33Y5VQ6###
VY1222M37Y5VQ6###
VY1332M43Y5VQ6###
VY1392M47Y5VQ6###
VY1472M51Y5VQ6###
± 20
(1)
8.0
9.0
10.5
12.0
15.0
15.5
16.0
5.0
10.0 or 12.5
VY1471#31Y5UQ6###
VY1681#31Y5UQ6###
VY1102#35Y5UQ6###
VY1152#41Y5UQ6###
VY1222#47Y5UQ6###
VY1332#59Y5UQ6###
VY1392#61Y5UQ6###
VY1472#63Y5UQ6###
± 10
8.0
5.0
10.0 or 12.5
VY1330K31Y5SQ6###
VY1470K31Y5SQ6###
VY1680K31Y5SQ6###
VY1101K31Y5SQ6###
VY1151K31Y5SQ6###
VY1221K31Y5SQ6###
VY1331K31Y5SQ6###
± 10
8.0
5.0
10.0 or 12.5
VY1100K31U2JQ6###
VY1150K31U2JQ6###
VY1220K31U2JQ6###
CAPACITANCE
TOLERANCE
(%)
BODY
DIAMETER
D
max.
(mm)
BODY
THICKNESS
T
max.
(mm)
LEAD SPACING
F (mm) ± 1 mm
PART NUMBER
MISSING DIGITS SEE
ORDERING CODE BELOW
Notes
• Straight leads available on request
• Coating extension DR valid for straight leads only
(1)
± 10 % available on request
Revision: 12-Feb-18
Document Number: 28537
2
For technical questions, contact:
cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VY1 Series
www.vishay.com
Vishay BCcomponents
Capacitance tolerance
Lead configuration
K
31
Y5S
Temperature
coefficient
Tolerance Size code
code
± 10 % = K, ± 20 % = M
Available configurations see below
Q
Rated
voltage
Q=
X1/Y1
500 V (AC)
6
T
V
Lead
style
L=
straight
V = inline
kinked
0
Lead
spacing
0 = 10.0
X = 12.5
Lead wire Packaging /
diameter lead length
3 = bulk
T = tape
and reel
U=
ammopack
ORDERING CODE
#
###
Example
7
th
digit
15
th
to 17
th
digit
VY1
Series
101
Capacitance
value
PACKAGING
SIZE CODE
31 to 47
51 to 63
BODY DIAMETER
D
max.
(mm)
12.0
16.0
BULK
1000
500
PACKAGING QUANTITIES
REEL
500
500
AMMO
750
750
Note
• The capacitors are supplied in bulk packaging (cardboard boxes), in tape on reel or in ammopack
STRAIGHT LEADS
D
max.
T
max.
coating
extension
e
3.0 max.
30 mm to 3.0 mm (ΔR)
F
d = 0.6 mm
P
D
ΔP
P
2
ΔP
Δh
T
Δh
F
Ød
L
W
1
W
0
W
L
1
A
W
2
H
0
H
1
P
0
P
1
F
D
0
t
detail A
t
1
The sprocket hole pitch (P
0
) is 12.7 mm for lead spacing 10.0 mm and 12.5 mm
Revision: 12-Feb-18
Document Number: 28537
3
For technical questions, contact:
cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VY1 Series
www.vishay.com
Vishay BCcomponents
DIMENSIONS
(mm)
16.0 max.
0.6 ± 0.05
25.4 ± 1
12.7 ± 0.3
7.7 or 6.4 ± 1.0
12.7 ± 1.5
10.0 or 12.5 + 0.6/- 0.4
± 1.0 max.
± 1.0 max.
18.0 + 1/- 0.5
5.0 min.
9.0 + 0.75/- 0.5
3.0 max.
40.0
16.0 ± 0.5
20.0 ± 0.5
11.0 max.
1.0 max.
4.0 ± 0.2
0.9 max.
t+d
DIMENSIONS OF TAPE
SYMBOL
D
(1)
d
P
P
0 (2)
P
1
(3)
PARAMETER
Body diameter
Lead diameter
Pitch of component
Pitch of sprocket hole
Distance, hole center to lead
Distance, hole to center of component
Lead spacing
Average deviation across tape
Average deviation in direction of reeling
Carrier tape width
Hold-down tape width
Position of sprocket hole
Distance of hold-down tape
Maximum component height
Height to seating plane (for kinked leads)
Height to seating plane (for straight leads)
Length of cut leads
Length of lead protrusion
Diameter of sprocket hole
Total tape thickness
Total tape thickness with lead wire
P
2 (3)
F
h
P
W
W
0
W
1
W
2
H
1
H
0
H
0
L
L
1
D
0
t
t
1
Notes
(1)
See “Technical Data” table
(2)
Cumulative pitch error: ± 1 mm/20 pitches
(3)
Obliquity maximum 3°
REEL AND TAPE DATA
in millimeters
51 max.
355.6 ± 2.0
330
28 ± 1.5
45 max.
8.0
360
55
Reel with capacitors on tape
Ammopack with capacitors on tape
Revision: 12-Feb-18
Document Number: 28537
4
For technical questions, contact:
cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
VY1 Series
www.vishay.com
Vishay BCcomponents
APPROVALS
IEC 60384-14.4 - Safety tests
This approval together with CB test certificate substitutes all national approvals.
CB Certificate
Y1-capacitor: CB test certificate:
X1-capacitor: CB test certificate:
US-26561-UL
US-26561-UL
10 pF to 4.7 nF
10 pF to 4.7 nF
500 V
AC
760 V
AC
VDE
Y1-capacitor: VDE marks approval:
X1-capacitor: VDE marks approval:
DIN EN 60384-14 VDE 0565-1-1:2006-04 - Safety tests
Underwriters Laboratories Inc./Canadian Standards Association
Y1-capacitor: CSA test certificate:
X1-capacitor: CSA test certificate:
UL 60384-14, CSA E60384-1:03, CSA E60384-14:09
Fixed capacitors for electromagnetic interference suppression and connection to the supply mains.
CQC
Y1-capacitor: CQC test certificate:
X1-capacitor: CQC test certificate:
CQC05001015032
CQC05001015032
10 pF to 4.7 nF
10 pF to 4.7 nF
500 V
AC
760 V
AC
E183844
E183844
10 pF to 4.7 nF
10 pF to 4.7 nF
500 V
AC
760 V
AC
40012673
40012673
10 pF to 4.7 nF
10 pF to 4.7 nF
500 V
AC
760 V
AC
MARKING
Sample
(2 sides)
10
VY1 472M
Y1 500~
X1 760~
xxxx
250~
4 digit date code
(year/week; add
suffix
“V” for mini
size series)
Revision: 12-Feb-18
Document Number: 28537
5
For technical questions, contact:
cdc@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
