Printed-circuit board connector - MCVU 1,5/ 2-GFD-3,81
GYAU - 1744002
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Plug component, Nominal current: 8 A, Number of positions: 2, Pitch: 3.81 mm, Connection method: Screw
connection with tension sleeve, Color: gray, Contact surface: Gold
Why buy this product
Gold-plated contacts ensure transfer quality remains stable over the long term
Screwable flange for superior mechanical stability
Laterally mounted flange for screw connection in the housing or on the mounting plate
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4046356304337
85366990
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Pitch
Dimension a
Constructional height
3.81 mm
3.81 mm
13 mm
General
Range of articles
Rated voltage (III/3)
Connection in acc. with standard
Nominal current I
N
Color
Number of positions
MCVU 1,5/..-GFD
160 V
EN-VDE
8A
gray
2
Standards and Regulations
Connection in acc. with standard
EN-VDE
Environmental Product Compliance
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1744002
Printed-circuit board connector - MCVU 1,5/ 2-GFD-3,81
GYAU - 1744002
Technical data
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Approvals
Approvals
Approvals
VDE Gutachten mit Fertigungsüberwachung / IECEE CB Scheme / CCA / EAC
Ex Approvals
Approval details
VDE Gutachten mit Fertigungsüberwachung
Search.aspx 40011723
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://www.vde.com/en/Institute/OnlineService/VDE-approved-products/Pages/Online-
0.2-1.5
8A
160 V
IECEE CB Scheme
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://www.iecee.org/ DE1-56063-B1B2
0.2-1.5
8A
160 V
CCA CCA/ DE1 34219
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
0.2-1.5
8A
160 V
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1744002
Printed-circuit board connector - MCVU 1,5/ 2-GFD-3,81
GYAU - 1744002
Approvals
EAC B.01742
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
11/14/2016 Page 3 / 3
