This document was generated on 03/01/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
1510482210
Active
CP Wire-to-Board and Wire-to-Wire Connector Systems
CP-6.5 Header, 6.50mm Pitch, Dual Row, Vertical, Polarized, Positive Lock, Tube
Packaging, 2 Circuits, Mint
Documents:
3D Model
Drawing (PDF)
Product Specification PS-151048-0001-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Capable
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Plating min - Mating
Plating min - Termination
Polarized to Mating Part
Polarized to PCB
Temperature Range - Operating
Termination Interface: Style
Electrical
Packaging Specification PK-151048-0001-001 (PDF)
Packaging Specification PK-151048-0002-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
E29179
PCB Headers
151048
Wire-to-Board
See Product Specification for maximum current rating by
circuit size and wire AWG
CP Wire-to-Board and Wire-to-Wire Connector Systems
CP-6.5
889056067300
No
2
2
Mint
30
No
94V-0
No
No
Yes
Yes
Copper Alloy
Matte Tin
Matte Tin
Polyamide
1.725/g
2
Vertical
3.80mm
Yes
Yes
1.60mm
Tube
6.50mm
1.270µm
1.270µm
Yes
Yes
-40°C to +105°C
Through Hole
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per
-ED/01/2018 (15
January 2018)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
151048 Series
Mates With
CP-6.5 Receptacle Housing 151049-2210
Current - Maximum per Contact
Voltage - Maximum
Solder Process Data
Lead-freeProcess Capability
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
10.0A
600V
WAVE
PK-151048-0001-001, PK-151048-0002-001
PS-151048-0001-001
SD-151048-0001-001
This document was generated on 03/01/2018
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
