52207-0833: DescriptionFFC & FPC Connectors 1.0 FPC ZIF 8Ckt Sn-Ag-Bi; CategoryThe connector The connector; File Size25KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric Compare View All

52207-0833 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	52207-0833	-	-	View	Buy Now

52207-0833 Overview

FFC & FPC Connectors 1.0 FPC ZIF 8Ckt Sn-Ag-Bi

52207-0833 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Molex
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Samacsys Description	MOLEX - 52207-0833 - CONNECTOR, FFC/FPC, 8POS, 1ROW, 1MM
Other features	POLARIZED, EASY-ON
body width	0.106 inch
subject depth	0.299 inch
body length	0.5 inch
Body/casing type	RECEPTACLE
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	SILVER
Contact completed and terminated	SILVER
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	BELLOWED TYPE
DIN compliance	NO
Dielectric withstand voltage	250VAC V
Durability	30 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	ZIF N
Insulation resistance	100000000 Ω
Insulator color	NATURAL
insulator material	GLASS FILLED POLYAMIDE
JESD-609 code	e4
MIL compliance	NO
Plug contact pitch	0.039 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	39u inch
Rated current (signal)	1 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal pitch	1 mm
Termination type	SURFACE MOUNT
Total number of contacts	8
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 02/27/2018

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0522070833

Active

FFC-FPC (SMT)

1.00mm Pitch Easy-On FFC/FPC Connector, Right-Angle, Surface Mount, ZIF, Top

Contact Style Receptacle, 8 Circuits, High Barrier Packaging

Documents:

3D Model

Drawing (PDF)

Product Specification PS-52207-009-001 (PDF)

Agency Certification

CSA

General

Product Family

Series

Overview

Product Name

Type

UPC

Physical

Circuits (Loaded)

Color - Resin

Contact Position

Durability (mating cycles max)

Entry Angle

Flammability

Mated Height

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Net Weight

Number of Rows

Orientation

PC Tail Length

PCB Locator

PCB Retention

Packaging Type

Pitch - Mating Interface

Pitch - Termination Interface

Polarized to PCB

Stackable

Temperature Range - Operating

Termination Interface: Style

Wire/Cable Type

Electrical

Current - Maximum per Contact

Voltage - Maximum

Material Info

Reference - Drawing Numbers

Packaging Specification

Packaging Specification SPK-52207-002-001 (PDF)

RoHS Certificate of Compliance (PDF)

Series image - Reference only

LR19980

E29179

FFC/FPC Connectors

52207

FFC-FPC (SMT)

Easy-On

Slider

887191276397

Natural

Top

90° Angle

94V-0

2.70mm

Phosphor Bronze

Silver, Tin-Bismuth

Nylon

370.600/mg

Right Angle

2.00mm

Yes

Embossed Tape on Reel

1.00mm

Yes

-40°C to +85°C

Surface Mount

FFC/FPC

1.0A

125V

EU ELV

Not Relevant

EU RoHS

China RoHS

Compliant

REACH SVHC

Not Contained Per -

ED/30/2017 (7 July

2017)

Halogen-Free

Status

Not Low-Halogen

Need more information on product

environmental compliance?

Email productcompliance@molex.com

Please visit the Contact Us section for any

non-product compliance questions.

China ROHS

ELV

RoHS Phthalates

Green Image

Not Relevant

Not Contained

Search Parts in this Series

52207 Series

Mates With

<a href="http://www.molex.com/product/

premoflex_ffc-fpc.html">Molex Premo-Flex

FFC</a>. Be sure to match like plating

SPK-52207-002-001

52207-0833 Related Products

	52207-0833	0522070833
Description	FFC & FPC Connectors 1.0 FPC ZIF 8Ckt Sn-Ag-Bi	Card Edge Connector, 8 Contact(s), 1 Row(s), Female, Right Angle, Surface Mount Terminal, Receptacle, ROHS AND REACH COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	ROHS COMPLIANT	ROHS AND REACH COMPLIANT
Reach Compliance Code	compliant	compliant
Other features	POLARIZED, EASY-ON	POLARIZED, EASY-ON
Body/casing type	RECEPTACLE	RECEPTACLE
Connector type	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR
Contact to complete cooperation	SILVER	NOT SPECIFIED
Contact completed and terminated	SILVER	NOT APPLICABLE
Contact point gender	FEMALE	FEMALE
Contact material	PHOSPHOR BRONZE	NOT SPECIFIED
DIN compliance	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
MIL compliance	NO	NO
Mixed contacts	NO	NO
Installation method	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD
Number of rows loaded	1	1
Options	GENERAL PURPOSE	GENERAL PURPOSE
Terminal pitch	1 mm	1 mm
Termination type	SURFACE MOUNT	SURFACE MOUNT
Total number of contacts	8	8
UL Flammability Code	94V-0	94V-0
