3M
™
Polarized Boardmount Socket
.100” × .100” Centerbump Polarization with Right Angle Solder Tails
•
•
•
•
•
5100 Series
Centerbump polarization
Mates with standard low profile shrouded headers
Part number on each piece
Optional keying plug
RoHS Compliant. See the Regulatory Information
Appendix (RIA) in the “RoHS Compliance” section of
www.3Mconnectors.com for compliance information (RIA
E1 and C1 apply).
Date Modified: October 14, 2013
TS0414-D
Sheet 1 of 2
Physical
Insulation:
Material: Glass Filled Polyester (PBT)
Flammability: UL 94V-0
Color: Gray
Contact:
Material:
Copper Alloy
Plating:
Underplating: 2 μm [ 79 μ” ] Nickel
Wiping Area: 0.3 μm [ 12 μ” ] Gold
Solder Tails: Gold Flash
Marking:
3M Logo, Part Identification Number and Orientation Triangle
Electrical
Current Rating:
1 A
Insulation Resistance:
> 1 × 10
9
Ω
at 500 V
DC
Withstanding Voltage:
1,000 V
RMS
at Sea Level
Environmental
Temperature Rating:
-55°C to +105°C
Process Rating:
Maximum insulator temperature 191°C (Solder Wave Process Only)
UL File No.: E68080
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnectors.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
Polarized Boardmount Socket
.100” × .100” Centerbump Polarization with Right Angle Solder Tails
A
B
5100 Series
Dimensions
B
20.3 [ 0.80 ]
33.0 [ 1.30 ]
40.6 [ 1.60 ]
45.7 [ 1.80 ]
50.8 [ 2.00 ]
58.4 [ 2.30 ]
71.1 [ 2.80 ]
83.8 [ 3.30 ]
88.9 [ 3.50 ]
C
17.3 [ 0.68 ]
30.0 [ 1.18 ]
37.6 [ 1.48 ]
42.7 [ 1.68 ]
47.7 [ 1.88 ]
55.4 [ 2.18 ]
68.1 [ 2.68 ]
80.8 [ 3.18 ]
85.8 [ 3.38 ]
8.4
[ .33 ]
6.4
[ .25 ]
Contact
Quantity
2X
∅
2.54
[ .100 ]
A
25.4 [ 1.00 ]
38.1 [ 1.50 ]
45.7 [ 1.80 ]
50.8 [ 2.00 ]
55.9 [ 2.20 ]
63.5 [ 2.50 ]
76.2 [ 3.00 ]
88.9 [ 3.50 ]
93.9 [ 3.70 ]
14.6
[ .57 ]
10
20
26
30
34
40
50
60
64
1.0
Centerbump (Standard)
[ .04 ]
11.3
[ .44 ]
7.6
[ .30 ]
Triangle
Indicate
Position 1
3.4
[ .13 ]
51XX 3M
8.9
[ .35 ]
2.54
[ .100 ]
Position 1
3.6
[ .14 ]
Position 2
0.70 x 0.32
[ .028 x .013 ]
2.54 Typ
[ .100 ]
C
6.1
[ .24 ]
4.44
[ .175 ]
0.45
[ .018 ]
2.6
[.102 ]
2.54 Ref
[ .100 ]
3.7
[ .146 ]
0.7
[ .028 ]
2.54
±
.076
[ .100 ]
Position 1
2X
∅
2.54
[ .100 ]
2.54
±
.076
[ .100 ]
8.3
[ .327 ]
2.9
[ .114 ]
Position 2
∅
0.90
±
.076 Typ
[ .035 ]
6.1
[ .24 ]
0.81
[ .032 ]
Breakaway
Tab
3435
B
Tolerance Unless Noted
.0
mm
±
.3
.00
±
.15
mm
(Inch)
Recommended Mounting Hole Pattern
(Shown for top side of PC board)
.000
0.66
[ .026 ]
1.30
[ .051 ]
[ ] Dimensions for
Reference only
Note:
1. Recommended to be mated to the 2.54 [.100] × 2.54 [.100] low profile header and the 4600
series plug connector. note the ejector latches cannot be used with the 4600 series
(Optional: Order Separately)
3435-0
Keying Plug
Ordering Information
Sockets
51XX-B7A2PL
RIA (E1 & C1 Apply)
Contact Quantity:
See Table
TS-0414-D
Sheet 2 of 2
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnectors.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
