Description
Body
Pin
Insulation
Nut
Washer
Material
Brass
Brass
PTFE
Brass
Brass
Finish
Nickel
Gold
N/A
Nickel
Nickel
REVISIONS
REV
DESCRIPTION
Add Pin Diameter; add flat area to barrel; change nut threads: 2A to 2B
DATE
8/21/09
29-JUN-12
17-OCT-12
APPV
CJ
SAH
SAH
C
D
E
0.768
[19.50]
0.449
[11.40]
0.031
[0.80]
FLAT 0.228
[5.80]
Updated footprint and dimensions; Added new title block
Added pin to PCB dimension
4x-S0.039
[1.00]
4x-S0.057
[1.45]
S0.276
[7.00]
Ø0.244
[6.20]
0.547
[13.90] 0.047
[1.20]
1/4-36UNS-2A
THREADS
0.260
[6.60]
BOTTOM VIEW
0.154
[3.90]
1/4-36UNS-2B
THREADS
H0.315
[8.00]
Ø0.402
[10.20]
Ø0.049
[1.25]
0.100
[2.55]
0.100
[2.55]
SIDE VIEW
0.065
[1.65]
0.020
[0.50]
0.201
[5.10]
Ø0.055
[1.40]
4-Ø0.060
[1.50]
MATERIAL:
THAT IS THE SOLE PROPERTY OF LINX TECHNOLOGIES, AND SHALL BE
TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS
DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE
EXPRESS WRITTEN PERMISSION OF LINX TECHNOLOGIES OR ITS
DESIGNATED AGENTS.
NUT
WASHER
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. ALL DIMENSIONS ARE IN INCHES [mm]. 3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE.
4. SAFETY BREAK ALL SHARP CORNERS AND EDGES .02 MAXIMUM.
2. DIMENSIONS APPLY AFTER FINISHING.
:
THIS DRAWING CONTAINS PROPRIETARY INFORMATION
159 ORT LANE
TITLE:
MERLIN, OR 97532
RECOMMENDED FOOTPRINT
FINISH:
PROJECTION:
TOLERANCES:
.020 [0.50]-.200 [5.00]= .008 [0.20]
.200 [5.00]-1.200 [30.00]= .016 [0.40]
1.20 [30.0]-4.75 [120.0]= .024 [0.60]
4.75 [120.0]-12.40 [315.0]= .040 [1.0]
ANGLES: 1
RP-SMA FEMALE RIGHT ANGLE
PCB MOUNT, EXTENDED
SIZE
DWG. NO.
REV
DRAWN: B.MURPHY DT:
29-JUN-12
SCALE: 2:1
ENGR:
DT:
CONREVSMA002-L
DO NOT SCALE DRAWING
E
SHEET 1 OF 1
