Unshielded Surface Mount Inductors
-94K
-96K
-00K
-02K
-04K
-06K
-08K
-10K
-12K
-14K
-16K
-18K
-20K
SERIES 1330 PHENOLIC CORE
0.10
40
25.0
680.0
0.12
40
25.0
640.0
0.15
38
25.0
600.0
0.18
35
25.0
550.0
0.22
33
25.0
510.0
0.27
33
25.0
430.0
0.33
30
25.0
410.0
0.39
30
25.0
365.0
0.47
30
25.0
330.0
0.56
30
25.0
300.0
0.68
28
25.0
275.0
0.82
28
25.0
250.0
1.00
25
25.0
230.0
0.08
0.09
0.10
0.12
0.14
0.16
0.22
0.30
0.35
0.50
0.60
0.85
1.00
1380
1300
1230
1120
1040
975
830
710
660
550
500
420
390
Actual Size
Physical Parameters
Inches
A
0.300 to 0.325
B
0.105 to 0.125
C
0.125 to 0.145
D
0.020 Min.
E
0.040 to 0.060
F
0.190 (Ref. only)
G
0.070 (Ref. only)
Weight Max
(Grams) 0.30
Millimeters
7.62 to 8.26
2.67 to 3.18
3.18 to 3.68
0.508 Min.
1.02 to 1.52
4.83 (Ref. only)
1.78 (Ref. only)
-22K
-24K
-26K
-28K
-30K
-32K
-34K
-36K
-38K
-40K
-42K
-44K
-46K
-48K
-50K
-52K
-54K
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.00
12.0
15.0
18.0
22.0
27.0
SERIES
25
28
30
30
37
45
45
45
50
50
55
55
45
45
45
45
45
1330 IRON CORE
7.9
150.0
7.9
140.0
7.9
125.0
7.9
115.0
7.9
100.0
7.9
90.0
7.9
80.0
7.9
75.0
7.9
65.0
7.9
60.0
7.9
55.0
7.9
50.0
2.5
40.0
2.5
35.0
2.5
30.0
2.5
25.0
2.5
20.0
0.18
0.22
0.30
0.40
0.55
0.85
1.00
1.20
1.80
2.00
2.70
3.30
2.70
2.80
3.10
3.30
3.50
620
560
480
415
355
285
263
239
195
185
160
144
160
157
149
144
140
Operating Temperature Range
Phenolic: –55°C to +125°C
Iron and Ferrite: –55°C to +105°C
Current Rating at 90°C Ambient
Phenolic: 35°C Rise
Iron and Ferrite: 15°C Rise
Maximum Power Dissipation at 90°C Ambient
Phenolic: 0.210 W
Iron: 0.090 W
Ferrite: 0.073 W
Marking
Delevan; dash number; date code (YYWWL).
Note: An R before the date code indicates a RoHS
component.
Example: 1330-42K
DELEVAN
42
0218A
Packaging
Tape & reel (16mm): 7" reel, 500 pieces max.;
13" reel, 2200 pieces max.
Made In the U.S.A.
-56K
-58K
-60K
-62K
-64K
-66K
-68K
-70K
-72K
-74K
-76K
-78K
-80K
-82K
-84K
-86K
-88K
-90K
-92K
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
680.0
820.0
1000.0
SERIES 1330 FERRITE CORE
35
2.5
24.0
35
2.5
22.0
35
2.5
20.0
35
2.5
18.0
35
2.5
15.0
35
2.5
14.0
35
2.5
13.0
30
0.79
12.0
30
0.79
11.0
30
0.79
10.0
30
0.79
9.0
30
0.79
8.0
30
0.79
7.0
30
0.79
6.5
30
0.79
6.0
30
0.79
5.0
30
0.79
4.2
30
0.79
3.8
30
0.79
3.4
3.40
3.60
4.50
5.70
6.70
7.30
8.00
13.00
15.00
17.00
21.00
25.00
28.00
35.00
42.00
46.00
60.00
65.00
72.00
130
125
110
100
92
88
84
66
61
57
52
47
45
40
36
35
30
29
28
Optional Tolerances: J = 5% H = 3% G = 2% F = 1%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
