Solid-state Multi-functional Timer
Timers
3. Output
None: Relay output (DPDT)
S:
Transistor output (NPN/PNP universal use)
E:
Relay output (SPDT) with instantaneous relay output (SP-
DT)
4. Suffix
300: Dual mode models (signal ON/OFF-delay and one-shot)
301: Double time scale (range) models (0.1 s to 600 h)
H3CR-A
DIN 48 x 48-mm State-of-the-art
Multifunctional Timer
• A wider power supply range reduces the number of timer mod-
els kept in stock.
• A wide range of applications through six or four operating
modes.
• Reduced power consumption.
(Except for H3CR-A8E)
• Enables easy sequence checks through instantaneous outputs
for a zero set value at any time range.
• Length, when panel-mounted with a Socket, of 80 mm or less.
• Time Setting Rings enable consistent settings and limit the set-
ting range.
• Panel Covers enable various panel designs.
• PNP input models available.
• Rich variety of inputs: Start, reset, and gate functions (11-pin
models and -AP models)
Model Number Structure
I
Model Number Legend
H3CR-A@@@-@
1 2 3
4
1. Number of Pins
None: 11-pin models
8:
8-pin models
2. Input Type for 11-pin Models
None: No-voltage input (NPN type)
P:
Voltage input (PNP type)
Solid-state Multi-functional Timer
H3CR-A
B-109
Ordering Information
I
List of Models
11-pin Models
Output
Contact
Supply voltage
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
Transistor (Photocou-
pler)
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
0.05 s to 300 h
H3CR-AS
No-voltage input
0.1 s to 600 h
H3CR-A-301
Voltage input
Six multi-modes: A, B,
B2, C, D, E
H3CR-AP
Dual-modes: G, J
H3CR-A-300
Input type
No-voltage input
Time range
0.05 s to 300 h
Operating mode (see
note 2)
Six multi-modes: A, B,
B2, C, D, E
Model
H3CR-A
8-pin Models
Output
Contact
Supply voltage
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
100 to 240 VAC (50/60 Hz)/
100 to 125 VDC
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
Transistor (Photocou-
pler)
24 to 48 VAC (50/60 Hz)/
12 to 48 VDC
0.05 s to 300 h
H3CR-A8S
H3CR-A8E
0.1 s to 600 h
Input type
Time range
Operating mode (see
note 2)
Four multi-modes: A,
B2, E, J
(Power supply start)
Model
H3CR-A8
No-input available 0.05 s to 300 h
H3CR-A8-301
Time-limit contact and
100 to 240 VAC (50/60 Hz)/
instantaneous contact
100 to 125 VDC
24 to 48 VDC/VAC (50/60 Hz)
Note:
1. Specify both the model number and supply voltage when ordering.
Example: H3CR-A 100 to 240 VAC (50/60 Hz)/100 to 125 VDC
Supply voltage
2. The operating modes are as follows
A: ON-delay
D: Signal OFF-delay
B: Flicker OFF start
E: Interval
B2: Flicker ON start
G: Signal ON/OFF-delay
C: Signal ON/OFF-delay
J: One-shot
B-110
Solid-state Multi-functional Timer
H3CR-A
I
Accessories (Order Separately)
Name/specifications
Flush Mounting Adapter
Y92F-30
Y92F-73
Y92F-74
Mounting Track
50 cm (l) x 7.3 mm (t)
1 m (l) x 7.3 mm (t)
1 m (l) x 16 mm (t)
End Plate
Spacer
Protective Cover
Track Mounting/
Front Connecting Socket
8-pin
8-pin, finger safe type
11-pin
11-pin, finger safe type
Back Connecting Socket
8-pin
8-pin, finger safe type
11-pin
11-pin, finger safe type
Time Setting Ring
Panel Cover (see note 2)
Setting a specific time
Limiting the setting range
Light gray (5Y7/1)
Black (N1.5)
Medium gray (5Y5/1)
Hold-down Clip (see note 3)
For PL08 and PL11 Sockets
For PF085A Socket
PFP-50N
PFP-100N
PFP-100N2
PFP-M
PFP-S
Y92A-48B
P2CF-08
P2CF-08-E
P2CF-11
P2CF-11-E
P3G-08
P3G-08 with Y92A-48G (see note 1)
P3GA-11
P3GA-11 with Y92A-48G (see note 1)
Y92S-27
Y92S-28
Y92P-48GL
Y92P-48GB
Y92P-48GM
Y92H-7
Y92H-8
Models
Timers
H3CR-A8E
Relay output (SPDT)
Relay output (SPDT)
Note: 1.
Y92A-48G is a finger safe terminal cover which is attached to the P3G-08 or P3GA-11 Socket.
2.
The Time Setting Ring and Panel Cover are sold together.
3.
Hold-down Clips are sold in sets of two.
Specifications
I
General
Item
Operating mode
H3CR-A/-AS
H3CR-AP
H3CR-A8/-A8S
A: ON-delay
B: Flicker OFF start
B2: Flicker ON start
C: Signal ON/OFF-delay
D: Signal OFF-delay
E: Interval
G: Signal ON/OFF-delay (Only for H3CR-A-300)
J: One-shot (Only for H3CR-A-300)
11-pin
No-voltage input
Voltage input
H3CR-A/-A8/-AP:Relay output (DPDT)
H3CR-AS/-A8S: Transistor output (NPN/PNP universal)*
---
DIN track mounting, surface mounting, and flush mounting
UL508, CSA C22.2 No.14, NK, Lloyds
Conforms to EN61812-1 and IEC60664-1 (VDE0110) 4kV/2.
Output category according to EN60947-5-1 for Timers with Contact Outputs.
Output category according to EN60947-5-2 for Timers with Transistor Outputs.
A: ON-delay (power supply start)
B2: Flicker ON start (power supply start)
E: Interval (power supply start)
J: One-shot (power supply start)
Pin type
Input type
Time-limit output type
Instantaneous output
type
Mounting method
Approved standards
8-pin
---
*The internal circuits are optically isolated from the output. This enables universal application as NPN or PNP transistor.
Solid-state Multi-functional Timer
H3CR-A
B-111
I
Time Ranges
Note:
When the time setting knob is turned below “0” until the point where the time setting knob stops, the output will operate instantaneously at
all time range settings.
Standard (0.05-s to 300-h) Models
Time unit
Full scale set-
1.2
ting
3
12
30
0.05 to 1.2
0.3 to 3
1.2 to 12
3 to 30
s (sec)
min (min)
0.12 to 1.2
h (hrs)
3 to 30
12 to 120
30 to 300
x10 h (10 h)
1.2 to 12
Double (0.1-s to 600-h) Models
Time unit
Full scale set-
2.4
ting
6
24
60
0.1 to 2.4
0.6 to 6
2.4 to 24
6 to 60
s (sec)
min (min)
0.24 to 2.4
h (hrs)
6 to 60
24 to 240
60 to 600
x10 h (10 h)
2.4 to 24
I
Ratings
Rated supply voltage (see note 1)
Operating voltage range
Power reset
Input
100 to 240 VAC (50/60 Hz)/100 to 125 VDC, 24 to 48 VAC (50/60 Hz)/12 to 48 VDC (24 to 48 VAC/VDC for H3CR-
A8E) (see note 2)
85% to 110% of rated supply voltage (90% to 110% at 12 VDC)
Minimum power-opening time: 0.1 s
No-voltage Input
ON impedance:
1 kΩ max.
ON residual voltage:
1 V max.
OFF impedance:
100 kΩ min.
Voltage Input
Max. permissible capacitance between inputs lines (terminals 6 and 7): 1,200 pF
Load connectable in parallel with inputs (terminals 6 and 7).
•
100 to 240 VAC/100 to 125 VDC
High (logic) level: 85 to 264 VAC/85 to 137.5 VDC
Low (logic) level:
0 to 10 VAC/0 to 10 VDC
•
24 to 48 VAC/12 to 48 VDC
High (logic) level: 20.4 to 52.8 VAC/10.8 to 52.8 VDC
Low (logic) level:
0 to 2.4 VAC/0 to 1.2 VDC
H3CR-A/-A8
•
100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON: approx. 2.0 VA (1.6 W)
•
24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Relay ON: approx. 0.8 W
H3CR-AP (see note 3)
•
100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON: approx. 2.5 VA (2.2 W)
•
24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Relay ON: approx. 0.9 W
H3CR-A8E
•
100 to 240 VAC/100 to 125 VDC
(When at 240 VAC, 60 Hz)
Relay ON/OFF: approx. 2 VA (0.9 W)
•
24 to 48 VAC/VDC
(When at 24 VDC)
Relay ON/OFF: approx. 0.9 W
H3CR-AS/-A8S
•
24 to 48 VAC/12 to 48 VDC
(When at 24 VDC)
Output ON: 0.3 W Output OFF: 0.2 W
Time limit contacts:
Transistor output:
Instantaneous contact:
Power consumption
Relay OFF: approx. 1.3 VA (1.1 W)
Relay OFF: approx. 0.2 W
Relay OFF: approx. 1.8 VA (1.7 W)
Relay OFF: approx. 0.3 W
Control outputs
5 A at 250 VAC/30 VDC, 0.15 A at 125 VDC, resistive load (cosφ = 1)
Open collector (NPN/PNP), 100 mA max. at 30 VDC max.,
residual voltage: 2 V max.
5 A at 250 VAC/30 VDC, 0.15 A at 125 VDC, resistive load (cosφ = 1)
Note: 1.
DC ripple rate: 20% max. if the power supply incorporates a single-phase, full-wave rectifier.
2.
Each 24-to-48-VAC/12-to-48-VDC model causes an inrush current of approximately 0.85 A. Pay careful attention when attempting to turn
ON power to such a model with non-contact output from a device such as a sensor.
3.
The values are for when the terminals 2 and 7 and terminals 10 and 6 are short-circuited, and include the consumption current of the
input circuit.
B-112
Solid-state Multi-functional Timer
H3CR-A
I
Characteristics
Accuracy of operating
±0.2%
FS max. (±0.2%±10 ms max. in a range of 1.2 s)
time
Setting error
Reset time
Reset voltage
Influence of voltage
Influence of tempera-
ture
Insulation resistance
Dielectric strength
±5%
FS
±50
ms (see note 1)
Min. power-opening time: 0.1 s max.
Min. pulse width:
0.05 s (H3CR-A/-AS)
10% max. of rated supply voltage
±0.2%
FS max. (±0.2%±10 ms max. in a range of 1.2 s)
±1%
FS max. (±1%±10 ms max. in a range of 1.2 s)
100 MΩ min. (at 500 VDC)
2,000 VAC (1,000 VAC for H3CR-A@S), 50/60 Hz for 1 min (between current-carrying metal parts and exposed non-
current-carrying metal parts)
2,000 VAC (1,000 VAC for H3CR-A@S), 50/60 Hz for 1 min (between control output terminals and operating circuit)
2,000 VAC, 50/60 Hz for 1 min (between contacts of different polarities)
1,000 VAC, 50/60 Hz for 1 min (between contacts not located next to each other)
2,000 VAC, 50/60 Hz for 1 min (between input and control output terminals and operation circuit) for H3CR-AP
3 kV (between power terminals) for 100 to 240 VAC/100 to 125 VDC, 1 kV for 24 to 48 VAC/12 to 48 VDC
4.5 kV (between current-carrying terminal and exposed non-current-carrying metal parts) for 100 to 240 VAC/100 to
125 VDC, 1.5 kV for 24 to 48 VAC/12 to 48 VDC and 24 to 48 VAC/VDC
±1.5
kV (between power terminals) and
±600
V (between no-voltage input terminals), square-wave noise by noise sim-
ulator (pulse width: 100 ns/1
µs,
1-ns rise)
Malfunction: 8 kV
Destruction: 15 kV
Destruction: 10 to 55 Hz with 0.75-mm single amplitude each in 3 directions for 2 hours each
Malfunction: 10 to 55 Hz with 0.5-mm single amplitude each in 3 directions for 10 minutes each
Destruction: 1,000 m/s
2
3 times each in 6 directions
Malfunction: 100 m/s
2
3 times each in 6 directions
Operating:
Storage:
Operating:
−10°C
to 55°C (with no icing)
−25°C
to 65°C (with no icing)
35% to 85%
Timers
Impulse withstand
voltage
Noise immunity
Static immunity
Vibration resistance
Shock resistance
Ambient temperature
Ambient humidity
Life expectancy
EMC
Mechanical: 20,000,000 operations min. (under no load at 1,800 operations/h)
Electrical:
100,000 operations min. (5 A at 250 VAC, resistive load at 1,800 operations/h) (see note 2)
EN61812-1
EN55011 Group 1 class A
EN55011 Group 1 class A
EN61812-1
IEC61000-4-2:
6 kV contact discharge (level 3)
8 kV air discharge (level 3)
Immunity RF-interference from AM Radio Waves:
IEC61000-4-3:10 V/m (80 MHz to 1 GHz) (level 3)
Immunity RF-interference from Pulse-modulated Radio Waves:IEC61000-4-3:10 V/m (900±5 MHz) (level 3)
Immunity Conducted Disturbance: IEC61000-4-6:
10 V (0.15 to 80 MHz) (level 3)
Immunity Burst:
IEC61000-4-4:
2 kV power-line (level 3)
2 kV I/O signal-line (level 4)
Immunity Surge:
IEC61000-4-5:
1 kV line to line (level 3)
2 kV line to ground (level 3)
Light gray (Munsell 5Y7/1)
IP40 (panel surface)
Approx. 90 g
(EMI)
Emission Enclosure:
Emission AC Mains:
(EMS)
Immunity ESD:
Case color
Degree of protection
Weight
Note: 1.
The value is
±5%
FS +100 ms to
−0
ms max. when the C, D, or G mode signal of the H3CR-AP is OFF.
2.
Refer to the
Life-test Curve.
Solid-state Multi-functional Timer
H3CR-A
B-113
京公网安备 11010802033920号
EEWORLD
