152D
www.vishay.com
Vishay Sprague
Solid-Electrolyte T
ANTALEX
™ Capacitors,
Extended Capacitance Values, Hermetically-Sealed
FEATURES
• Axial through-hole terminations:
tin / lead (SnPb), 100 % tin (RoHS-compliant)
• High capacitance and small size
• Exceptional operating stability
• Hermetically-sealed, cylindrical, metal-case
• Low leakage current and low dissipation factor
• The military equivalent of the 152D is the M39003/03 (style
CSR23) which is qualified to MIL-PRF-39003/3
• Provide proven reliability in a wide variety of high
performance military, industrial and commercial markets
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
Available
Available
PERFORMANCE CHARACTERISTICS
Operating Temperature:
-55 °C to +85 °C
(to +125 °C with voltage derating)
Capacitance Tolerance:
at 120 Hz, +25 °C
± 20 % and ± 10 % standard. ± 5 % available as special
Dissipation Factor:
at 120 Hz, +25 °C
Dissipation factor, as determined from the expression
2fRC, shall not exceed the values listed in the Standard
Ratings table
DC Leakage Current (DCL Max.):
at +25 °C:
leakage current shall not exceed the values listed
in the Standard Ratings table
at +85 °C:
leakage current shall not exceed 10 times the
values listed in the Standard Ratings table
At +125 °C:
leakage shall not exceed 12 times the values
listed in the Standard Ratings table
Life Test:
capacitors shall withstand rated DC voltage
applied at +85 °C for 2000 h or derated DC voltage applied
at +125 °C for 1000 h
Following the life test:
1. DCL shall not exceed 125 % of the initial requirement. In
no case need the leakage current be less than 2 μA
2. Dissipation factor shall meet the initial requirement
3. Change in capacitance shall not exceed ± 5 %
ORDERING INFORMATION
152D
MODEL
106
CAPACITANCE
X0
CAPACITANCE
TOLERANCE
X0 = ± 20 %
X9 = ± 10 %
X5 = ± 5 % *
* Special order
006
DC VOLTAGE RATING
AT +85 °C
This is expressed in
volts. To complete the
three-digit block,
zeros precede the
voltage rating.
A
CASE
CODE
See
Ratings
and Case
Codes
table
2
STYLE
NUMBER
2 = insulated
sleeve
T
PACKAGING
E3
RoHS-
COMPLIANT
E3 = 100 % tin
termination
(RoHS-compliant)
Blank = SnPb
termination
This is expressed
in picofarads. The
first two digits are
the significant
figures. The third
is the number of
zeros to follow.
B = bulk
T = tape
and reel
G = ammo
pack
Revision: 16-Nov-17
Document Number: 40016
1
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
152D
www.vishay.com
Vishay Sprague
DIMENSIONS
in inches [millimeters]
1.500 ± 0.250
[38.10 ± 6.35]
L
-
+
1.500 ± 0.250
[38.10 ± 6.35]
Positive lead
D
dia.
Solid tinned
nickel leads
J max.
0.047 [1.19] max.
0.125 [3.18]
max.
CASE CODE
A
B
R
S
D
L
WITH INSULATING SLEEVE
(1)
0.135 ± 0.016 [3.43 ± 0.41]
0.185 ± 0.016 [4.70 ± 0.41]
0.289 ± 0.016 [7.34 ± 0.41]
0.351 ± 0.016 [8.92 ± 0.41]
0.286 ± 0.031 [7.26 ± 0.79]
0.474 ± 0.031 [12.04 ± 0.79]
0.686 ± 0.031 [17.42 ± 0.79]
0.786 ± 0.031 [19.96 ± 0.79]
J
(MAXIMUM)
0.422 [10.72]
0.610 [15.49]
0.822 [20.88]
0.922 [23.42]
LEAD SIZE
AWG NO.
24
24
22
22
NOMINAL DIAMETER
0.020 [0.51]
0.020 [0.51]
0.025 [0.64]
0.025 [0.64]
Note
(1)
When a shrink-fitted insulation is used, it shall lap over the ends of the capacitor body
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
MAX. DF
AT +25 °C
120 Hz
(%)
6
6
6
6
6
6
8
8
8
10
10
10
10
4
6
6
6
6
6
6 V
DC
AT +85 °C, SURGE = 8 V; 4 V
DC
AT +125 °C, SURGE = 5 V
10
12
15
68
82
100
330
390
470
560
680
820
1000
5.6
6.8
8.2
10
47
56
A
A
A
B
B
B
R
R
R
S
S
S
S
A
A
A
A
B
B
152D106(1)006A2(2)(3)
152D126(1)006A2(2)(3)
152D156(1)006A2(2)(3)
152D686(1)006B2(2)(3)
152D826(1)006B2(2)(3)
152D107(1)006B2(2)(3)
152D337(1)006R2(2)(3)
152D397(1)006R2(2)(3)
152D477(1)006R2(2)(3)
152D567(1)006S2(2)(3)
152D687(1)006S2(2)(3)
152D827(1)006S2(2)(3)
152D108(1)006S2(2)(3)
152D565(1)010A2(2)(3)
152D685(1)010A2(2)(3)
152D825(1)010A2(2)(3)
152D106(1)010A2(2)(3)
152D476(1)010B2(2)(3)
152D566(1)010B2(2)(3)
1.0
1.0
1.0
3.0
3.0
6.0
10.0
10.0
10.0
20.0
20.0
20.0
20.0
1.0
1.0
1.2
1.2
4.0
5.0
10 V
DC
AT +85 °C, SURGE = 13 V; 7 V
DC
AT +125 °C, SURGE = 9 V
Note
• Part number definitions:
(1) For 10 % tolerance specify “X9”; for 20 % specify “X0”; for 5 % “X5” (special order)
(2) Packaging options: B = bulk, T = tape and reel, G = ammo pack
(3) Termination: E3 = 100 % tin, blank = SnPb
Revision: 16-Nov-17
Document Number: 40016
2
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
152D
www.vishay.com
Vishay Sprague
MAX. DF
AT +25 °C
120 Hz
(%)
6
6
8
8
8
8
8
10
10
10
4
4
4
6
6
6
6
6
8
8
8
8
8
8
8
4
4
4
4
4
4
4
6
6
6
6
6
8
8
8
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
10 V
DC
AT +85 °C, SURGE = 13 V; 7 V
DC
AT +125 °C, SURGE = 9 V
68
82
150
180
220
270
330
390
470
560
3.9
4.7
5.6
6.8
27
33
39
82
100
120
150
180
220
270
330
2.7
3.3
3.9
4.7
18
22
27
56
68
82
100
120
150
180
220
B
B
R
R
R
R
S
S
S
S
A
A
A
A
B
B
B
R
R
R
R
R
S
S
S
A
A
A
A
B
B
B
R
R
R
R
R
S
S
S
152D686(1)010B2(2)(3)
152D826(1)010B2(2)(3)
152D157(1)010R2(2)(3)
152D187(1)010R2(2)(3)
152D227(1)010R2(2)(3)
152D277(1)010R2(2)(3)
152D337(1)010S2(2)(3)
152D397(1)010S2(2)(3)
152D477(1)010S2(2)(3)
152D567(1)010S2(2)(3)
152D395(1)015A2(2)(3)
152D475(1)015A2(2)(3)
152D565(1)015A2(2)(3)
152D685(1)015A2(2)(3)
152D276(1)015B2(2)(3)
152D336(1)015B2(2)(3)
152D396(1)015B2(2)(3)
152D826(1)015R2(2)(3)
152D107(1)015R2(2)(3)
152D127(1)015R2(2)(3)
152D157(1)015R2(2)(3)
152D187(1)015R2(2)(3)
152D227(1)015S2(2)(3)
152D277(1)015S2(2)(3)
152D337(1)015S2(2)(3)
152D275(1)020A2(2)(3)
152D335(1)020A2(2)(3)
152D395(1)020A2(2)(3)
152D475(1)020A2(2)(3)
152D186(1)020B2(2)(3)
152D226(1)020B2(2)(3)
152D276(1)020B2(2)(3)
152D566(1)020R2(2)(3)
152D686(1)020R2(2)(3)
152D826(1)020R2(2)(3)
152D107(1)020R2(2)(3)
152D127(1)020R2(2)(3)
152D157(1)020S2(2)(3)
152D187(1)020S2(2)(3)
152D227(1)020S2(2)(3)
6.0
7.0
8.0
8.0
12.0
13.0
16.0
16.0
16.0
20.0
1.0
1.0
1.3
1.3
3.0
5.0
5.0
8.0
10.0
10.0
15.0
15.0
20.0
20.0
20.0
0.8
1.0
1.2
1.2
3.0
3.0
4.0
7.0
8.0
10.0
12.0
12.0
15.0
15.0
15.0
15 V
DC
AT +85 °C, SURGE = 20 V; 10 V
DC
AT +125 °C, SURGE = 12 V
20 V
DC
AT +85 °C, SURGE = 26 V; 13 V
DC
AT +125 °C, SURGE = 16 V
20 V
DC
AT +85 °C, SURGE = 26 V; 13 V
DC
AT +125 °C, SURGE = 16 V
Note
• Part number definitions:
(1) For 10 % tolerance specify “X9”; for 20 % specify “X0”; for 5 % “X5” (special order)
(2) Packaging options: B = bulk, T = tape and reel, G = ammo pack
(3) Termination: E3 = 100 % tin, blank = SnPb
Revision: 16-Nov-17
Document Number: 40016
3
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
152D
www.vishay.com
Vishay Sprague
MAX. DF
AT +25 °C
120 Hz
(%)
4
4
4
4
4
6
6
8
8
4
4
4
4
4
6
6
6
6
6
6
8
8
4
4
4
4
6
6
6
6
6
6
STANDARD RATINGS
CAPACITANCE
(μF)
CASE CODE
PART NUMBER
MAX. DCL
AT +25 °C
(μA)
30 V
DC
AT +85 °C, SURGE = 39 V; 20 V
DC
AT +125 °C, SURGE = 26 V
2.2
2.7
12
15
18
56
68
82
100
1.2
1.5
1.8
8.2
10
27
33
39
47
56
68
82
100
1.2
1.5
5.6
6.8
22
27
33
39
47
22
A
A
B
B
B
R
R
S
S
A
A
A
B
B
R
R
R
R
S
S
S
S
A
A
B
B
R
R
S
S
S
R
152D225(1)030A2(2)(3)
152D275(1)030A2(2)(3)
152D126(1)030B2(2)(3)
152D156(1)030B2(2)(3)
152D186(1)030B2(2)(3)
152D566(1)030R2(2)(3)
152D686(1)030R2(2)(3)
152D826(1)030S2(2)(3)
152D107(1)030S2(2)(3)
152D125(1)035A2(2)(3)
152D155(1)035A2(2)(3)
152D185(1)035A2(2)(3)
152D825(1)035B2(2)(3)
152D106(1)035B2(2)(3)
152D276(1)035R2(2)(3)
152D336(1)035R2(2)(3)
152D396(1)035R2(2)(3)
152D476(1)035R2(2)(3)
152D566(1)035S2(2)(3)
152D686(1)035S2(2)(3)
152D826(1)035S2(2)(3)
152D107(1)035S2(2)(3)
152D125(1)050A2(2)(3)
152D155(1)050A2(2)(3)
152D565(1)050B2(2)(3)
152D685(1)050B2(2)(3)
152D226(1)050R2(2)(3)
152D276(1)050R2(2)(3)
152D336(1)050S2(2)(3)
152D396(1)050S2(2)(3)
152D476(1)050S2(2)(3)
152D226(1)060R2(2)(3)
1.0
1.0
3.0
3.0
3.0
7.0
7.0
10.0
10.0
0.6
0.8
1.0
3.0
3.0
7.0
8.0
10.0
10.0
12.0
12.0
30.0
30.0
0.6
0.8
2.5
2.5
7.0
8.0
10.0
10.0
10.0
7
35 V
DC
AT +85 °C, SURGE = 46 V; 23 V
DC
AT +125 °C, SURGE = 28 V
50 V
DC
AT +85 °C, SURGE = 65 V; 33 V
DC
AT +125 °C, SURGE = 40 V
60 V
DC
AT +85 °C, SURGE = 78 V; 39 V
DC
AT +125 °C, SURGE = 49 V
Note
• Part number definitions:
(1) For 10 % tolerance specify “X9”; for 20 % specify “X0”; for 5 % “X5” (special order)
(2) Packaging options: B = bulk, T = tape and reel, G = ammo pack
(3) Termination: E3 = 100 % tin, blank = SnPb
Revision: 16-Nov-17
Document Number: 40016
4
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
152D
www.vishay.com
Vishay Sprague
TAPE AND REEL PACKAGING
in inches [millimeters]
Meets EIA standard RS-296
13.0 [330.2]
Standard
reel
B
1.126 to 3.07
[28.6 to 78.0]
I. D. reel hub
1.374 to 3.626
[34.9 to 92.1]
0.031 [0.79] max.
Off center (1. a)
0.625 ± 0.0062 dia.
[15.88 ± 1.575]
Thru hole
Label (4. a)
“A”
0.750 [19.05]
Section
“A” to “A”
Both
sides
(3. f)
0.125 [3.18] max.
0.250 [6.35] (3. b)
0.031 [0.79] (3. f)
A
“A”
Tape
spacing
Component
spacing
STANDARD PACKAGING QUANTITY AND DIMENSIONS
in inches [millimeters]
CASE
CODE
A
B
R
S
COMPONENT SPACING
A
0.200 ± 0.015
[5.08 ± 0.38]
0.200 ± 0.015
[5.08 ± 0.38]
0.400 ± 0.015
[10.16 ± 0.38]
0.400 ± 0.015
[10.16 ± 0.38]
TAPE AND REEL
TAPE SPACING
UNITS PER REEL
B
2.500 ± 0.062
1000
[63.5 ± 1.57]
2.500 ± 0.062
1000
[63.5 ± 1.57]
2.875 ± 0.062
500
[73.03 ± 1.57]
2.875 ± 0.062
500
[73.03 ± 1.57]
AMMO PACK
TAPE SPACING
UNITS PER BOX
B
2.063 ± 0.073
500
[53 ± 2]
2.063 ± 0.073
500
[53 ± 2]
2.063 ± 0.073
250
[53 ± 2]
2.063 ± 0.073
250
[53 ± 2]
STANDARD REEL PACKAGING INFORMATION
1. Component Leads
a. Component leads shall not be bent beyond 0.047"
[1.19 mm] maximum from their nominal position when
measured from the leading edge of the component lead
at the lead egress from the component.
b. The “C” dimension shall be governed by the overall
length of the reel packaged component. The distance
between flanges shall be 0.125" to 0.250" [3.18 mm to
6.35 mm] greater than the overall component length.
2. Orientation
All polarized components must be oriented to one
direction. The cathode lead tape shall be a color and the
anode lead tape shall be white.
3. Reeling
a. Components on any reel shall not represent more than
two date codes when date code identification is required.
b. Component leads shall be positioned between pairs of
0.250" [6.35 mm] tape.
c. The disposable reels have hubs and corrugated
fibreboard flanges and core or equivalent.
d. A minimum of 12.0" [304.8 mm] leader of tape shall be
provided before the first and after the last component on
the reel.
e. 50 lb or 60 lb. Kraft paper must be wound between layer
of components as far as necessary for component
protection. Width of paper to be 0.062" to 0.250"
[1.57 mm to 6.35 mm] less than the “C” dimension
of the reel.
f. A row of components must be centered between tapes
± 0.047" [1.19 mm]. In addition, individual components
may deviate from center of component row ± 0.031"
[0.79 mm].
g. Staples shall not be used for splicing. Not more than
4 layers of tape shall be used in any splice area and no
tape shall be offset from another by more than 0.031"
[0.79 mm] non-cumulative. Tape splices shall overlap at
least 6.0" [152.4 mm] for butt joints and at least 3.0"
[76.2 mm] for lap joints and shall not be weaker than
unspliced tape. Universal splicing clips may also be used.
h. Quantity per reel shall be controlled so that tape
components and cover shall not extend beyond the
smallest dimension of the flange (either across flats or
diameter). Once the quantity per reel for each part
number has been established, future orders for that part
number shall be packaged in that quantity. When order or
release quantity is less than the established quantity, a
standard commercial pack is to be used.
i. A maximum of 0.25 % of the components per reel
quantity may be missing without consecutive missing
components.
j. Adequate protection must be provided to prevent
physical damage to both reel and components during
shipment and storage.
4. Marking
Minimum reel and carton marking shall consist of the
following: customer part number, purchase order no.,
quantity, package date, manufacturer’s name, electrical
value, date code, Vishay Sprague part number and
country of origin.
Revision: 16-Nov-17
Document Number: 40016
5
For technical questions, contact:
tantalum@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Domestic Chip Exchange
京公网安备 11010802033920号
EEWORLD
