ECX-2236
SMD CRYSTAL
The miniature ECX-2236 is a compact SMD Crystal. The industry
standard 2.5 x 2.0 x 0.55 mm ceramic package is ideal for
today’s SMD manufacturing environment.
ECX-2236 SMD CRYSTAL
Request a Sample
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency
Mode of Oscillation
Frequency Tolerance*
Frequency Stability*
Shunt Capacitance
Load Capacitance
Drive Level
Operating Temperature*
Storage Temperature
Aging (First Year)
Fundamental
@ +25°C
-20 ~ +70°C
CONDITIONS
MIN
ECX-2236
TYP
MAX
UNITS
80.000
± 50
± 50
5
MHz
ppm
ppm
pF
pF
100
μW
°C
°C
ppm
+70
+125
±5
12.000
Co
Specify in P/N
D
L
T
opr
T
stg
@ +25°C ±3°C
-20
-55
8
Low Profile
2.5 x 2.0 mm Footprint
Extended Temp. Range
IOT/Wearable applications
DIMENSIONS (mm)
Frequency (MHz)
12.000 ~ 15.999
16.000 ~ 19.999
20.000 ~ 29.999
30.000 ~ 34.999
35.000 ~ 80.000
ESR Ω Max.
150
80
60
50
40
Figure 1)
Top, Side, and Bottom
Crystal is symmetrical, pad 1 & 3 are interchangeable.
Chamfer on the bottom pad has no electrical
significance.
Pad Connections
1
In/Out
2
Gnd
3
Out/In
4
Gnd
Figure 2)
Suggested land
pattern
PACKAGING
PART NUMBERING GUIDE: Example ECS-240-8-36-TR
ECS - FREQUENCY ABBREVIATION
LOAD
CAPACITANCE
8 = 8 pF
10=10 pF
PACKAGE
Tolerance
-36 =
ECX-2236
Blank = Std
A = ± 25
ppm
J = ± 20
ppm
R = ± 15
ppm
C = ± 10
ppm
AVAILABLE OPTIONS
Stability
Blank= Std
D= ±100 ppm
E = ± 50 ppm
G = ± 30 ppm
H = ± 25 ppm
T = ± 20 ppm †
W = ±15 ppm †
K = ± 10 ppm †
Temp Range
Blank= Std
L = -10 ~ +70°C
M = -20 ~ +70°C
Y = -30 ~ +85°C
N = -40 ~ +85°C
P = -40 ~ +105°C
S = -40 ~ +125°C
U = -55 ~ +125°C
TR =
Tape
& Reel
1K/Reel
ECS
240 = 24.000 MHz
See P/N Guide
* Specify available options in P/N.
† Contact ECS for availability over extended temp range.
Rev.2017
