HEYCaps, Nylon Finishing Plugs & Venting Solutions
Multiple Locking Steps for Panel Thickness up to .250˝ (6,4 mm)
MOUNTING
HOLE
DIAMETER
in.
3.0
5.0
mm.
76,2
127,0
2442
2444
2443
2445
EDP 3.0
EDP 5.0
PART NO.
Black
White
DESCRIPTION
A
Head
Diameter
in.
mm.
3.22
5.22
81,8
132,6
PART DIMENSIONS
B
Overall
Height
in.
mm.
1.37
1.41
34,8
35,8
C
Inside
Height
in.
mm.
1.26
1.31
32,0
33,3
Heyco Extra Dome Plugs
®
Standard colors black. Consult Heyco for other colors.
A
B
C
•
Extra dome height
for additional
clearance under the top.
•
Consult Heyco for additional sizes.
•
Lock firmly into panels up to
.250˝ (6,4 mm) thick.
•
Locking fingers in fractional
increments up to the maximum
panel thickness.
•
Not UL Recognized.
Multiple Locking Steps for Panel Thickness up to 4,1 mm (.162˝)
Mounting Hole Diameter Range: 13,0 mm (.512˝) to 34,2 mm (1.347˝)
MOUNTING
HOLE
DIAMETER
PART NO.
in.
.512
.630
.787
.866
.984
1.102
1.260
1.347
Black
2203
2128
2131
2205
2133
2215
2135
2218
White
2204
2130
2132
2206
2134
2216
2136
2219
MDP 13
MDP 16
MDP 20
MDP 22
MDP 25
MDP 28
MDP 32
MDP 34
DESCRIPTION
PART DIMENSIONS
A
B
Head Diameter
Overall Height
mm.
in.
mm.
in.
14,2
18,5
22,6
25,9
29,8
31,2
35,3
38,1
.56
.73
.89
1.02
1.17
1.23
1.38
1.50
11,5
.453
10,3
.406
Heyco Snap-In Metric Dome Plugs
®
mm.
NEW!
13,0
16,0
20,0
NEW!
NEW!
NEW!
22,0
25,0
28,0
32,0
34,2
Standard color black. Consult Heyco for other colors.
A
B
•
Multiple sizes for use in
13,0 mm
(.512˝) to 34,2 mm (1.347˝)
diameter holes.
For other metric
sizes, consult Heyco.
•
Close unneeded panel holes.
•
Quick and easy installation.
•
Convex, matte finish head tapers
to a thin edge.
•
Lock firmly into panel up to
4,1 mm (.162˝) thick.
•
Approximate Head Thickness:
1,6 mm (.062˝).
•
For
Threaded
Metric Plugs, see page
6-44.
•
For our complete range of Dome
Plugs, see page 6-25.
Material
Certifications
Flammability Rating
Temperature Range
Nylon 6/6
Recognized under the Component Program of Underwriters’ Laboratories,
File E51579 (MDP’s only)
Certified by Canadian Standards Association, File 8919 (MDP’s only)
94V-2
-40°F (-40°C) to 221°F (105°C)
Quick
Specs
6-30
