REV.
REVISION
DESCRIPTION
DATE
APPROVED
TAPE
C5
3
4 5
6 7
915 ± 30
6 7
4 5
3
8
10
9
17
1
1
2
8
2
1
9
16
24
1
9
17
140 ± 20
P1
24
16
8
P2
3.8 ± 0.3
C5
FRONT
(24+1)P/M ASS’Y TYPE
(24+1)P/M ASS’Y TYPE
FRONT
P1
1
2
3
4
5
9
10
11
12
13
WHITE
ORANGE
DRAIN
DRAIN
WHITE
BROWN
WHITE
BLACK
DRAIN
DRAIN
WHITE
BLUE
P2
1
2
3
4
5
9
10
11
12
13
PIN OUT
P1
17
18
19
20
21
22
23
24
WHITE
YELLOW
DRAIN
DRAIN
WHITE
GREEN
DRAIN
WHITE
RED
P2
17
18
19
20
21
22
23
24
No.
PARTS NAME
DVI (24+1)P/M - CONTACT
DVI (24+1)P/M - SHELL
CAN
DVI (24+1)P/M - COVER
THUMB SCREW
SCREW - MOLD
MINI TIE
POLYBAG
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
Drawn / Date
B. Grubb
12-20-06
Checked / Date
12-20-06
Approved / Date
JJH / 12-20-06
SPECIFICATION STANDARD
BRASS / GOLD PLATED SOLDER TYPE
NICKEL PLATED
STEEL TIN PLATED
45P PVC/BLACK(BK#01)
#4-40 2.8x44mm, NICKEL PLATED
35P PVC / COLOR: BLACK
PE/BLACK
0.08x180x200
QTY REMARKS
50
2
2
2
2
4
4
1
2
1
P1
6
7
14
15
16
SHELL
WHITE
YELLOW
RED
BLACK
BROWN
BRAID
P2
6
7
14
15
16
SHELL
1
2
3
4
5
6
7
8
9
10
DVI (24+1)P/M - INSULATOR THERMOPLASTIC / BLACK UL94V-0
CABLE DVI 24+1 UL 20276 KL 3007ABK01A
NOTES:
1. CABLE: UL20276
28AWGx1P+DW+FOIL)x7+28AWGx3C+28AWGx1P+MYLAR+FOIL+BD
COLOR: BLACK, OD: 8.5 ± 0.3mm
PRINTING: E166307
AWM 20276 28AWG 80˚C VW-1
LOW VOLTAGE COMPUTER CABLE
2. CONNECTORS: DVI(24+1)P/M TO DVI(24+1)P/M
3. HOOD: ASS’Y TYPE, COLOR: BLACK
4. ELECTRICAL TEST:
<1>.100% OPEN SHORT & MISS WIRE TEST
<2>. INSULATION RESISTANCE: DC400V 10M ohm MIN.
<3>. CONDUCTOR RESISTANCE: 3 ohm MAX.
5. PACKING: 1PC/POLYBAG
Qualtek Electronics Corp.
WCI DIVISION
Part Number:
Description:
1321007-03
DVI (24+1)P/M - DVI (24+1)P/M
