HIP1011DCAZA-T: DescriptionHot Swap Voltage Controllers W/ANNEAL DL PCI HOT PLUG PWR CNTRLR; CategoryAnalog mixed-signal IC The signal circuit; File Size346KB，15 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

HIP1011DCAZA-T Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HIP1011DCAZA-T	-	-	View	Buy Now

HIP1011DCAZA-T Overview

Hot Swap Voltage Controllers W/ANNEAL DL PCI HOT PLUG PWR CNTRLR

HIP1011DCAZA-T Parametric

Parameter Name	Attribute value
Brand Name	Intersil
Is it Rohs certified?	conform to
Maker	Renesas Electronics Corporation
Parts packaging code	QSOP
package instruction	SSOP, SSOP28,.25
Contacts	28
Reach Compliance Code	compliant
Other features	ALSO REQUIRES 3.3V AND 5V SUPPLY
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	R-PDSO-G28
JESD-609 code	e3
length	9.905 mm
Humidity sensitivity level	2
Number of functions	1
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SSOP28,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	3.3,5,+-12 V
Certification status	Not Qualified
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	13.2 V
Minimum supply voltage (Vsup)	10.8 V
Nominal supply voltage (Vsup)	12 V
surface mount	YES
Temperature level	COMMERCIAL
Terminal surface	Matte Tin (Sn) - annealed
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	3.895 mm
Base Number Matches	1

Preview

Download Datasheet

View All

HIP1011D, HIP1011E

Data Sheet

November 18, 2004

FN4725.5

Dual Slot PCI Hot Plug Controllers

The HIP1011D, HIP1011E are the first ICs available for

independent control of two PCI Hot-Plug slots. The

HIP1011D has all the features and functionality of two single

PCI Hot-Plug slot controllers such as the HIP1011A but in

the same foot print area. Like the single slot HIP1011B, the

HIP1011E does not monitor output voltage nor respond to

undervoltage conditions.

The HIP1011D, HIP1011E are designed to be physically

placed in close proximity to two adjacent PCI slots thus

reducing layout complexity and placement costs in

assembly. The HIP1011D, HIP1011E provides independent

power control to each slot and the addition of discrete power

MOSFETs and a few passive components creates two

complete power control solutions. The IC integrates the

+12V and -12V current sensing switches for each slot.

Overcurrent (OC) protection is provided by sensing the

voltage across external current-sense resistors. In addition,

on-chip references are used to monitor the +5V, +3.3V and

+12V outputs for undervoltage (UV) conditions *. The two

PWRON inputs control the state of the switches, one each

for slot A and slot B outputs. During an OC condition on any

output, or a UV condition on the +5V, +3.3V or +12V outputs

*, a LOW (0V) is asserted on the associated FLTN output

and all associated switches are latched-off. The outputs

servicing the adjacent slot are unaffected.

The time to FLTN signal going LOW and MOSFET latch off

is user determined by a single capacitor from each FLTN pin

to ground. This added feature enables the HIP1011D,

HIP1011E to ignore system noise transients. The FLTN latch

is cleared when the PWRON input is toggled low again.

During initial power-up of the main VCC supply (+12V), the

PWRON input is inhibited from turning on the switches, and

the latch is held in the Reset state until the VCC input is

greater than 10V.

User programmability of the overcurrent threshold and turn-

on slew rate is provided. A resistor connected to the OCSET

pin programs the overcurrent threshold for both slots.

Capacitors connected to the gate pins set the turn-on rate.

* UV references do not apply to HIP1011E.

Features

• Independent Power Control of 2 PCI Slots

• Turn-Off Delay Time Adjustability

• Internal MOSFET Switches for +12V and -12V Outputs

•

µP

Interface for On/Off Control and Fault Reporting

• Adjustable Overcurrent Protection for All Eight Supplies

• Provides Fault Isolation

• Adjustable Turn-On Slew Rate

• Minimum Parts Count Solution

• No Charge Pump

• 100ns Response Time to Overcurrent

• Pb-Free Available (RoHS Compliant)

Applications

• PCI Hot-Plug

Ordering Information

PART NUMBER

HIP1011DCA*

HIP1011DCAZA*

(See Note)

HIP1011ECA*

HIP1011ECAZA*

(See Note)

TEMP.

RANGE (°C)

0 to 70

PACKAGE

28 Ld SSOP

(Pb-free)

28 Ld SSOP

(Pb-free)

PKG.

DWG. #

M28.15

* Add “-T” suffix for tape and reel option.

NOTE: Intersil Pb-free products employ special Pb-free material sets; molding

compounds/die attach materials and 100% matte tin plate termination finish,

which are RoHS compliant and compatible with both SnPb and Pb-free

soldering operations. Intersil Pb-free products are MSL classified at Pb-free

peak reflow temperatures that meet or exceed the Pb-free requirements of

IPC/JEDEC J STD-020C.

Pinout

HIP1011D, HIP1011E (SSOP)

TOP VIEW

M12VO_2 1

M12VG_2 2

PWRON_2 3

FLTN_2 4

VSS 5

12VG_2 6

12VO_2 7

12VO_1 8

12VG_1 9

OCSET 10

FLTN_1 11

PWRON_1 12

M12VG_1 13

M12VO_1 14

28 M12VIN_2

27 3VISEN_2

26 3VS_2

25 5VISEN_2

24 5VS_2

23 3V5VG_2

22 12VIN_2

21 12VIN_1

20 3V5VG_1

19 5VS_1

18 5VISEN_1

17 3VS_1

16 3VISEN_1

15 M12VIN_1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.
