BAT54AWT1G,
SBAT54AWT1G
Schottky Barrier Diodes
These Schottky barrier diodes are designed for high speed switching
applications, circuit protection, and voltage clamping. Extremely low
forward voltage reduces conduction loss. Miniature surface mount
package is excellent for hand held and portable applications where
space is limited.
Features
http://onsemi.com
Extremely Fast Switching Speed
Low Forward Voltage
−
0.35 V (Typ) @ I
F
= 10 mAdc
AEC Qualified and PPAP Capable
S Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant*
MAXIMUM RATINGS
(T
J
= 125C unless otherwise noted)
Rating
Reverse Voltage
Forward Power Dissipation
@ T
A
= 25C
Derate above 25C
Forward Current (DC)
Non−Repetitive Peak Forward Current
t
p
< 10 msec
Repetitive Peak Forward Current
Pulse Wave = 1 sec,
Duty Cycle = 66%
Junction Temperature
Storage Temperature Range
Symbol
V
R
P
F
Value
30
200
1.6
200 Max
600
300
−55
to 125
−55
to +150
Unit
V
mW
mW/C
mA
mA
mA
30 VOLT
SCHOTTKY BARRIER
DETECTOR AND SWITCHING
DIODES
SOT−323
CASE 419
STYLE 4
ANODE
3
CATHODE
1
2
CATHODE
I
F
I
FSM
I
FRM
MARKING DIAGRAM
B7M
G
G
1
T
J
T
stg
C
C
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
B7
M
G
= Device Code
= Date Code*
= Pb−Free Package
(Note: Microdot may be in either location)
*Date Code orientation may vary depending
upon manufacturing location.
ORDERING INFORMATION
Device
BAT54AWT1G
SBAT54AWT1G
Package
SOT−323
(Pb−Free)
SOT−323
(Pb−Free)
Shipping
†
3,000/Tape & Reel
3,000/Tape & Reel
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
Semiconductor Components Industries, LLC, 2011
November, 2011
−
Rev. 3
1
Publication Order Number:
BAT54AWT1/D
BAT54AWT1G, SBAT54AWT1G
PACKAGE DIMENSIONS
SOT−323 (SC−70)
CASE 419−04
ISSUE N
D
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
DIM
A
A1
A2
b
c
D
E
e
e1
L
H
E
MIN
0.80
0.00
0.30
0.10
1.80
1.15
1.20
0.20
2.00
MILLIMETERS
NOM
MAX
0.90
1.00
0.05
0.10
0.70 REF
0.35
0.40
0.18
0.25
2.10
2.20
1.24
1.35
1.30
1.40
0.65 BSC
0.38
0.56
2.10
2.40
MIN
0.032
0.000
0.012
0.004
0.071
0.045
0.047
0.008
0.079
INCHES
NOM
0.035
0.002
0.028 REF
0.014
0.007
0.083
0.049
0.051
0.026 BSC
0.015
0.083
MAX
0.040
0.004
0.016
0.010
0.087
0.053
0.055
0.022
0.095
e1
3
H
E
1
2
E
b
e
A
0.05 (0.002)
A1
A2
L
c
STYLE 4:
PIN 1. CATHODE
2. CATHODE
3. ANODE
SOLDERING FOOTPRINT*
0.65
0.025
0.65
0.025
1.9
0.075
0.9
0.035
0.7
0.028
SCALE 10:1
mm
inches
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
